Features 6" Electronic gauge (indicator) with dial faces available in pounds, kilograms, or dual scale. Includes electronic tension load cell and 100 ft shielded cable Each system can be calibrated on site Available in range: 2, 000, 3, 000, 4, 000, 5, 000, 6, 000, and 10, 000 pounds Calibration and pull certificate is included with the system Can be ordered in either backlit or standard. The gauges can also be used in conjunction with a digital display and data logger Suitable to operate in ambient temperature -40°C to 85°C. Origin: North America Options Zone-2 rated Electronic Load cell Certified for Hazardous location

Features Slickline / Braided Line wraparound Halliburton type measuring device Slickline / Braided Line wraparound measuring device with built-in hydraulic load cell equivalent to ASEP MP16 Braided Line / E-line Straight through measuring device with built-in hydraulic load cell up to 5/16" braided line Cased Hole / Open hole logging application with 2, encoder, load pin and magnetic marker.

Features Skid Mounted Diesel Engine Driven Meets international standard DNV2.7-1, ATEX94/9/EC Ex Group IIA Category 3G T3 for Zone 2 environment Range: 20, 40 , 60, 80 and 100 kVA 50/60Hz 400/230 VAC, 50/60 Hz with 0.8 PF Totally enclosed enclosure Options Rig Safe Weatherproof enclosure Sound enunciated enclosure rated 85dBA @ 1 meter Open consol Stationary installation

Features Hydraulic driven air conditioner Zone-2 rated  Application :  For Skid Mounted Wireline Units / Wire line logging trucks / earth moving equipment / mining / marine Single Piece / Split System Roof top / wall mounted Options 100 % Hydraulic Air Conditioning 18, 000 BTU/hr to 50, 000 BTU’s/hr No electrical power required Works well in ambient temperatures exceeding 55°C / 130°F Designed for hazardous environments Off-the road or offshore application

Features Two Piece skid mounted open console unit Single Drum Power Pack: 80 hp Rig Safe Application: 0.108” Slickline, 0.125” Slickline and braided line up to 7/32" Totally enclosed design to protect from falling objects. Fold-down sun-hood canopy Open Loop hydraulics 16 inch Halliburton type wrap around measuring device Veeder Root Mechanical Depth Counter Options Zone-2 rated Closed loop hydraulics 120 hp power-pack Measuring Device Equivalent to ASEP MP16 Heli-portable Aluminum Construction Electronic Weight Indicator BOP & Stuffing Box Control Auxiliary hydraulics for Mast Re-Spooler Jacking Castors

Features Construction: Square Head, Mill Design Standards: NFPA Heavy Duty Hydraulic, ANSI / (NFPA) T3.6.7R2-1996 Bore Size: 1 1/2" through 14" or metric sizes Strokes: Available in any practical length Piston Rod Diameter: 5/8" to 10" or metric sizes Operating Medium: Hydraulic oil Mounting Styles: 14 Standard Nominal Pressure: 2000 psi (Consult factory for higher pressures) Standard Operating Temperature: -10°F to +165°F Rod Ends: Five standard choices; specials to order Cushions: Optional at either or both ends Ports: SAE "O" ring are standard, others are available Options Removable Rod Gland Assembly with Tri-Lip rod seal Polyurethane Rod Wiper Adjustable Floating Cushions Heavy wall steel tubing cylinder body Chrome plated, medium carbon steel, induction case hardened piston rod One piece nodular iron piston Step cut piston rings or lip seals with backup washers are standard piston seals. Hi Load piston is available with wear rings and bronze-filled PTFE seals. End of stroke sensors

Features Skid Mounted Diesel Engine Driven Screw Compressor Suitable to use in hazardous area Zone-2 80-1000 cfm Working Pressure 150 psi Meets International standard ATEX 94/9/EC and DNV 2.7-1 Options 1000 cfm, 365 psi 1170 cfm, 365 psi

Features 100 % Hydraulic Air Conditioner 18, 000 BTU/hr to 50, 000 BTU’s/hr No electrical power required Works well in ambient temperatures exceeding 55°C / 130°F Designed for hazardous environments Off-the road or offshore application Options Single Piece or Split System Stainless Steel external enclosure Can be built for non hazardous environment

Features Pressurized Module meets international standards DNV 2.7-1, DNV 2.7-2, Atex and NFPA 496. Application: Wireline Logging Cabin, Well Testing Lab, MWD Cabin, LWD cabin Protected with a fully automatic fire and gas detection & shutdown system Fitted with heating, ventilation & air conditioning for ambient temp 50 degree Control pressurization, Fire and Gas detection panel included with all ancillary items. for use up Gas H2S and LEL detection, Smoke detection, pressurization fan, loss of pressure and flow devices Receptacle to accept rig supply or external power source Suitable for operation on 3 phase systems from 380 VAC through to 690 VAC at 50/60Hz Options A60 rated door and windows A60 emergency escape hatch CPFG: microprocessor based Combined Pressurization Fire & Gas control panel Talk-Back System with explosion proof speaker-microphone

Features Winch drum is supplied with 2 two pillow block / Plummer block bearing and sprocket Slickline Drum: different sizes to accept wires 0.092", 0.108", 0.125", 0.140", 0.160" Braided Line Drum: different sizes to accept cables 3/16", 7/32", 5/16" E-line Drums: different sizes to accept e-line 7/32", 5/16", 15/32" Split Drum: different sizes to combine slickline, braided line and e-line Options Single or duel brake band system Disc brake system Direct drive system instead of chain drive Non-Magnetic Core Stainless Steel construction Transport skid open console / totally closed

Features Containerized Wireline Unit in Multiple Skids Zone-2 rated Air-Conditioned Operator Cab Can be lifted in a single lift or in multiple lift Double Drum Mount Power Pack: 120 hp / 200 hp Application: Slickline / Braided Line / Cased Hole / Open Hole Closed Loop hydraulics Equivalent to ASEP MP16 measuring device and or Benchmark straight through measuring device Benchmark / Eztek Winchman panel Options Single Drum / Double Drum / Split Drum Aluminum Light Weight Construction Rig safe Logging Rack and logging system Pressurized cabin

Features Hydraulic power is from truck PTO or external hydraulic power source Screw Compressor Free Air Delivery : 14 cfm to 250 cfm Discharge air pressure: 110 psi nominal Hydraulic Pressure required: 3, 000 psi nominal, 2500 psi minimum Hydraulic flow required: As per application Suitable for 55 degree C ambient temperature Compressor Oil Cooler Suction unloader Automatic hydraulic power cut-off on compressor oil overheat, high outlet air temperature Continuous duty application Skid Mounted / totally enclosed enclosure Options Zone-2 rated Discharge air pressure up to 175 psi

Features Containerized Wireline Unit for mounting on truck-chassis Air-Conditioned Operator Cab Double Drum Mount Power Pack: 80 hp Built for onshore operation Application: 0.108” Slickline, 0.125” Open Loop hydraulics Measuring Device Equivalent to ASEP MP16 Hydraulic Weight Indicator & Veeder Root Mechanical Depth Counter Options Combined slickline and 7/32" mono-conductor application For Slickline up to 0.160" wire Up to 5/16" braided line or Cased Hole Logging application Open Hole Logging 15/32" cable application Zone-2 rated Closed loop hydraulics Single Drum / Double drum / Split Drum 120 hp power-pack Halliburton type 16" wrap around measuring device Digital winchman panel (Data logger) Electronic weight Indicator Digital depth counter Logging Rack and logging system BOP & Stuffing Box Control Hydraulic Driven Air Compressor for grease injection unit

Features Standards: Meets or exceeds JIC and NFPA Standards Nominal Pressure: up to 3, 000 psi (higher pressure on special order) Bore Diameter: 1-1/2” to 12” diameter or metric size Piston Rod Diameter: 5/8” to 8" or metric Mounting: 18 standard NFPA mountings Stroke: up to 120” Connection Port: SAE straight thread standard (ISO 11926-1) other options on request

Features Application: For slickline or braided line Working Height: 35 ft / 45 ft / 60 ft / 75 ft or custom built Hydraulic Telescopic Mast or Aluminum Folding Mast Hydraulic winch with positive fail safe brake Foldable Front and Rear outrigger Hydraulic power from wireline power pack or from auxiliary source Wireline Pull: 80% of the breaking strength of wire or braided line Jacking castor with SS screw Options Auxiliary winch Man-rider Rig-safe or Zone-2 rated power pack

Features CombiLine has integrated swivel operator’s control cab and draw-works compartment 25 degrees rotating cabin and draw works compartment External storage compartments Air-Conditioned operator cabin with thermal & acoustic insulation Ergonomic design control panel Low noise level Rear mount hydraulic telescopic boom crane Four Outriggers Closed Loop Hydraulics PTO driven hydraulics Hydraulic Driven Generator up to 30 KVA Epoxy painted Options Zone-2 certified Atex compliant 80 / 120 hp diesel engine driven on board power pack Open loop hydraulics for Slickline 360 degree swivel cab BOP & Stuffing Box Control with hose reels Hydraulic Driven air compressor Lightweight Aluminum Construction
