A short subassembly used to enable two components with different thread types or sizes to be connected. Design & Certification Service : ASME B31.3, API 6A, NACE MR0175, CE / PED : H2S

Separator can be used in well-testing applications as well as cleanup operations. It helps to provide safe and efficient separation for the measurement of oil, gas, and water Working Pressure Vessel Data Design & Certification Service Skid/ Frame : Up to 2160psi : 42in X 15 ft, 42 inX 10 ft & 48 in X 12ft : ASME VIII, Div-1, ASME B31.3, NACE MR0175, DNV 2.7-1, 2.7-3, CE / PED : H2S : 20’ DNV/CSC with slings and shackles.

Pressurized vessel designed for temporary storage and to ensure no gases are vented to the atmosphere near the well testing area. It can be used as a 2nd stage separator. Working Pressure Vessel Data Design & Certification Service Skid/ Frame : Up to 250psi : 50BBL & 100BBL, Single or dual compartments : ASME VIII, Div-1, ASME B 31.3, NACE MR0175, DNV 2.7-1, CE / PED : H2S : 20’ DNV/CSC with slings and shackles.

Burner booms are designed for safe disposal of produced hydrocarbons at a secure distance from the drilling vessel and personnel. The self-contained boom is secured to the rig structure by the use of a king post, vertical suspension, and horizontal wind-stay cables. Modular boom can be easily configured as 60-ft or 90-ft units. Lightweight design reduces crane capacity restrictions and simplifies installation. Design & Certification Service Water curtain : ASME B31.3, NACE MR0175, API-RP 2A, CE / PED : H2S : Water curtain arrangement is based on the results from heat radiation analysis, minimizing the need for rig coolant.

The atmospheric Gauge tank, a non-pressurized vessel used to measure low flow rates and calibrate metering devices on the separator oil lines in a testing system. The tank can be used for temporarily storing the oil. Capacity Design & Certification Service Skid/ Frame Safety Feature : 200BBL Dual Compartment : API 650, ASME B31.3, NACE MR0175, DNV 2.7-1, CE / PED : H2S : 20’ DNV/CSC with slings and shackles. : Flame arrestor

Raising the temperature of the well effluent to prevent hydrate formation, assists in the reduction of viscosity in heavy oil applications, and helps break down emulsions. Automatic temperature control as an integral part of the design and Improves separation of oil/water emulsions Coil Working Pressure Heat Transfer Capacity Design & Certification Service Skid/ Frame : Up to 15000psi : 4mm Btu/Hr : ASME VIII, Div-1, ASME B 31.3, API 6A PSL3, NACE MR0175, DNV 2.7-1, CE / PED : H2S : 20’ DNV/CSC with slings and shackles.

10ft or 20ft Workshop / Tool Containers have been designed, manufactured and certified in accordance with DNV2.7-1 / BS EN 12079. The units are supplied with certified slings and shackles as standard.
