Dongguan Xinwang Package Machine Co. Ltd

Guangdong, China

• MOQ 1 Set(s)
• Brand NameXINWAMG
• ISO9001:2008GOOD quality
• touch screenPLC

We are offering Xw-703d Automatic Tape Cutting Machine. applicable : bopp, pvc, pe, masking paper tape, double side tape, kraft tape, foam tape, cloth tape, electrical tape. feature main driving parts: ac motor with inverter is employed and the acceleration and the deceleration are fast and steady . Central control unit: programmable central control is used and various sizes can be set on the same shaft for automatic transfer and cutting . Operating panel: all functions are operated on the human-computer panel. Cutting roll positioning system: cutting roll positioning is controlled by the servo motor. The imported high precision ball screw is applied to set the size and the linear slide rail is to bear the load of the utter seat . Auto adjusting of the circular blade angle: the servo motor is used to calculate the circular blade angle and the angle change is subject to different materials (the angle change range is +/-80) .the cutting angle is changed directly when the cutting surface is not smooth, so the efficiency is improved. main technical parameters model xw-703d-3 xw-703f work width(mm) 1300/1600 1300/1600 max cut diameter(mm) 250 250 paper core i.d(mm) 76.2 (as customer’s) 76.2 (as customer’s) power supply 3φ, 380v, 50hz ( or as customer’s ) 3φ, 380v, 50hz ( or as customer’s ) brand xinwang xinwang certification iso9001:2008 iso9001:2008 supply capacity 10sets/month 10sets/month safty cover without with patent of outlook yes

• MOQ 1 Set(s)
• Brand NameXNWANG
• CEISO9001:2008

We are offering thermal transfer ribbon slitting machine xw-206e. high speed & good quality & reasonable price & easy operation thermal transfer ribbon slitting machine application: it is suitable for slitting the different colours of thermal transfer ribbons the effective working width: 1000mm the max rewinding diameter: φ100mm the max unwinding diameter: φ600mm the construction of the machine the collect system : manual edge.correct unwinding shaft: 3 inch air shaft the tension system: manual control rewinding shaft: φ12.7mm &φ25.4mm power supply 3 phase 380v 50hz delivery time 40 days after receiving the deposit package wooden package brand xinwang origin china certification iso9001:2008

• MOQ 1 Set(s)
• Brand NameXNWANG
• high speedISO9001:2008
• good pricegood quality

We are offering bopp tape coating machine main parameters： 1.machine speed: max.250m/min production speed max.220m/min 2.coating types: bopp adhesive tape 3. [glue] viscosity: 60-100cps. Solid content: 53-55%. Coating thickness: 13-25µm. Coating series: water glue 4. Raw materials basis heavy range: bopp film thickness :25µm. 5. The original film width: 1300mm wheel face width1450mm 6. Use the heat source: hot blast stoveheating 7. Max unwinding diameter: max. Φ600mm 8. Max rewinding diameter: max. Φ800mm 9. Drying box length: 2m/section，total 18 section，36m 10. Drying box temperature: max.130ºc. temperature deviation±5℃ 11. Electric power specifications: 3φ, 380v, 50hz. Three phase four wire power 12. Electricity consumption: about 140kw. 13. Coating mode: mayer bar（equipped with sixpcs） 14. Tension control: automatic tension control 15. Correction method: epc automatic deviation correcting(end neatness≤2mm delivery time 100 days after receiving the deposit brand xinwang origin china certification iso9001:2008

• MOQ 1 Set(s)
• Brand NameXINWAMG
• ISO9001:2008GOOD quality

We are offering bopp adhesive tape coating machine. range of application: this coating machine is special for producing bopp adhesive tape( opp tape) with high speed & high stability, easy operation techinical parameters： coating width 1300mm/1600mm max.machine speed 250m/min max.coating speed 220m/min unwind diameter 600mm rewind diameter 800mm drying box length 36meters coating mode mayer bar tension control automatic tension control correction method epc automatic deviation correcting electric power specifications 3φ, 380v, 50hz ( or as customer’s ) supply capacity 1set/month delivery time 90days after got the deposit

• MOQ 1 Set(s)
• Brand NameXNWANG
• good pricegood quality

We are offering xw-703f automatic cutting machine. application this model is suitable for stretch cling film bopp pvc pe masking paper tape double side tape kraft tape foam tapecloth tape and electrical tape. 2.parameters effective work width 1300mm/1600mm min cutting width 5mm inner core diameter φ76mm-φ77mm max cutting diameter 180mm diameter can be amplified refer to customer's requirement voltage 3phase 380v 50hz (refer to customer's requirement) delivery time:-30 days after receiving the deposit package :-wooden package brand:xinwang origin:china certification iso9001:2008

• MOQ 1 Set(s)
• Brand NameXINWAMG
• ISO9001:2008CE

We are offering Xw-210 Bopp Tape Slitting Machine. application: suitable for bopp adhesive tape( opp tape) slitting and rewinding. it is a idea slitting machine for bopp tape performance and features： 1. 4 shaft automatic exchange to rewind 2. Unwinding parts locates on the back of the machine , elegant appearance . 3. With automatic labeling and soundproof shiled for customer’s choose 4. Easy operation xw-210 bopp tape slitting machine techinical parameters： type xw-210 effective work width / max. Unwinding width 1300mm / 1600mm unwinding diameter 3inches , φ800mm width of final roll /finished product as customers’ rewinding diameter 3inches, φ150mm power supply 3 phase 380v 50hz ( or as customer’s ) delivery time 35 days after receiving the deposit package wooden package brand xinwang origin china certification iso9001:2008 certification ce supply capacity 10sets/month

• MOQ 1 Set(s)
• Brand NameXNWANG
• high speedlow noise
• good priceISO9001:2008

We are offering high speed and low noise bopp slitting machine xw-210-8. 1.application this machine is suitable for slitting self-adhesive tape such as bopp packing tape. 2.parameters effective working width 1300mm / 1600mm max unwinding diameter 800mm max.rewinding diametter 150mm inside diameter of unwinding and rewinding shaft 76.2mm slitting width as customer’s power supply 3 phase 380v 50hz with automatic labeling and soundproof cover and high speed payment terms: 30% as deposit , 70% paid before loading delivery time 30 days after receiving the deposit package wooden package brand xinwang origin china certification iso9001:2008

• MOQ 1 Set(s)
• Brand NameXINWAMG
• ISO9001:2008PLC
• touch screenGOOD quality

We are offering automatic tape cutting machine. Xw-704e automatic tape cutting machine (double shafts double blades) applicable : bopp, pvc, pe, masking paper tape, double side tape, kraft tape, foam tape, cloth tape, electrical tape. feature main driving parts: ac motor with inverter is employed and the acceleration and the deceleration are fast and steady . Central control unit: programmable central control is used and various sizes can be set on the same shaft for automatic transfer and cutting . Operating panel: all functions are operated on the human-computer panel. Cutting roll positioning system: cutting roll positioning is controlled by the servo motor. The imported high precision ball screw is applied to set the size and the linear slide rail is to bear the load of the utter seat . Auto adjusting of the circular blade angle: the servo motor is used to calculate the circular blade angle and the angle change is subject to different materials (the angle change range is +/-80) .the cutting angle is changed directly when the cutting surface is not smooth, so the efficiency is improved. main technical parameters model xw-704e-3 work width(mm) 1300/1600 max cut diameter(mm) 150mm paper core i.d(mm) 76.2 (as customer’s) power supply 3φ, 380v, 50hz ( or as customer’s ) brand xinwang certification iso9001:2008 supply capacity 10sets/month
