Foshan Vyba Precision Cutting Tools Factory

• MOQ 50 Piece(s)
• Brand NameVYBA
• TechniqueAutomatic welding & grinding
• Packaging TypeOriginal
• Diameter300mm
• kerf thickness2.5mm
• Material75Cr1
• Teeth number24+2
• teeth typeLeft-right bevel
• bore70mm

• MOQ 50 Piece(s)
• Packaging TypeOrginal
• FinishSand-blast
• Material75Cr1
• Carbide tipCeratizit

• MOQ 50 Piece(s)
• Material75Cr1
• FinishingElectroplated
• Packaging TypeOrginal
• TechniqueAutomatic welding & grinding
• Diameter305mm
• Kerf thickness4.0mm
• Teeth number84T

• MOQ 50 Piece(s)
• Packaging TypeOriginal
• Diameter120mm
• Teeth styleATB(left-right)
• Teeth number12+12
• Carbide tipCeratizit
• Material75Cr1

• MOQ 50 Piece(s)
• Material75Cr1

We are offering freud style tct saw blade. the saw blade is applied to the computer controlled tandem slitter.supported by the cone-shaped sub-saw, it can cut various sheet materials, with its processing thickness at more than 100mm, with excellent cutting surface&durability. left/right bevel for solid wood cutting. trapezoidal with flat saw tooth, for mdf, hdf, laminate, melamine with double-veneered face the most comman sizes are 300*96t and 300*72t. advantages: 1.material:steel body in 75cr1 imported from japan, tip ceratizit/k01/taiwanese/top quality made-in-china. a.steel body, laser-cutting, heat treatment to add strength. b.hand hammered to make run-out to minimum. c.dynamic balancing and straightness:to diminish the saw blade "run-out" and vibration enhancing the accuracy. 2.automatic welding and grinding machine. 3.sandwich soldering flake. 4.saw blade can be re-sharpen repeatedly. 5.customized size is also available.any size can be produced as customer required. 6.quality grade:industrial, semi-industrial, professional quality pls refer the common sizes as below. out diameter(φd) tooth width(b)mm tooth thickness(φb)mm inner diameter(d)mm number of teeth(z) cutting angle(a°) tooth type(c) 200 3.2 2.2 30 64 10 trapezoidal flat 250 3.2 2.2 30 80 10 300 3.2 2.2 30 72 10 300 3.2 2.2 30 96 10 350 3.5 2.5 30 84 12 350 3.5 2.5 30 96 12 350 3.5 2.5 30 108 12 400 3.5 2.5 30 96 15 400 3.5 2.5 30 120 15

• MOQ 50 Piece(s)
• Material75Cr1
• Diameter255mm
• Bore25.4mm
• Carbide tipCeratizit
• Teeth number120z

We are offering aluminium circular saw blade. Aluminium cutting circular saw blade, TCT circular saw blade, TCT saw blade, for non-ferrous metal, industrial quality, imported material. Foshan VYBA precision cutting tools factory, is a professional specialized in manufacturing, designing and developing various kinds of TCT saw blades. • The trapezoidal sawtooth with the flat tooth is applied to such saw blade for the cutting of stainless steel and aluminum alloy. •The body is treated in special heat treatment, and the alloy angle is designed for metal cutting. •The processed materials have to be fixed mechanically for such processing. Out diameter(ΦD) Tooth width(B)mm Tooth thickness(Φb)mm Inner diameter(d)mm Number of Teeth(Z) Tooth type(C) Use(U) 205 2.0 1.4 25.4 80 Trapezoidal Flat Cutting for aluminum and copper : 205 2.8 2.2 25.4 80 205 2.0 1.4 25.4 100 205 2.8 2.2 25.4 100 250 3.0 2.4 25.4 80 250 2.6 2.0 25.4 100 250 3.0 2.4 25.4 100 250 2.6 2.0 25.4 120 250 3.0 2.4 25.4 120 300 2.6 2.0 25.4 100 300 3.0 2.4 25.4 100 350 3.0 2.4 25.4 100 350 3.6 3.0 25.4 100 400 3.0 2.4 25.4 100 400 3.6 3.0 25.4 100 400 3.0 2.4 25.4 120 400 3.6 3.0 25.4 120 450 3.6 3.0 25.4 120 450 4.0 3.4 25.4 120 500 4.6 4.0 25.4 100 500 4.6 4.0 25.4 120 550 4.8 4.0 25.4 120 600 4.8 4.0 25.4 144 700 5.2 4.0 25.4 144 800 6.0 5.0 25.4 72 800 6.0 5.0 25.4 160 Othe specifications and sizes are available to the customer's request.
