Huatao Paper Machine Fabric Manufactory

shijiazhuang, China

• Materialpolyester
• Brand Namehuatao
• Applicationpaper making
• Storage Conditionpolyester

• Place of OriginChina

We are offering cylinder mould wire, huatao paper machine fabric factory specially design and produce polyester shrinks cover fabric used in cylinder mould paper making machine : syc 787 type , 1092 type , 1575 type, 1785type etc. We produce polyester shrinks cover fabric against diameter of cylinder mould. Including : dia 1.25m , dia 1.5m , dia 1.75m, dia2.0m , dia 2.5m . Range of mesh count : from 12meshs upto 100mesh count material : 100% polyester or polyamide . No seam marking and flat surface , not easily cracked . Long life time and good air permeability .

We are offering polyester forming fabric, according to the weaving, polyester forming fabric can be divided into 4-shed, 5-shed, 7-shed, 8-shed, 16-shed, 24-shed etc. According to the category, it can be divided into single layer fabric, double layer fabric, two-and a half layer fabric and three-layer fabric 4-shed single layer polyester forming fabric is standard type of polyester forming fabric in paper making, mainly used for producing cultural paper printing paper, packing paper and so on. 5-shed single layer polyester forming fabric is suitable for making healthy, culture and packing papers etc. 8-shed single layer polyester forming fabric is the most wear-resisting one in the single layer screen, which have long performance life, but mesh print is relatively deep. It is mainly used for copying the papermaking bag, craft paper, cardboard, corrugated paper and so on. 7-shed double layer polyester forming fabric is suitable for quality printing paper and tissue paper etc. 8-shed double layer polyester forming fabric is suitable for quality printing paper, tissue paper and the surface pulp and inner pulp of the board paper etc. 8-shed, 16-shed double and a half layer polyester forming fabric is suitable for making quality printing paper, tissue paper and surface pulp, inner pulp and base pulp of the board paper etc. Multi-shed three-layer polyester forming fabrics suitable for making quality printing paper, tissue paper and paper etc.

We offer steam press belt. Model: Htmillde loop1 Dimensions: w=2650mm x 1=11940 mm with mech.fastener (joining seam wire) W=2650 x 1=5100 mm with mech.fastener (joining seam wire) Material :Polyester 100% Permeability: 360 cfm Thickness: 2.50mm Warp Dia: 0.70mm Weft dia: 0.90mm elongation at failure: 18-20% Apply working temerature(MAX): 150℃

We are offering polyester plain fabric, polyester linear screen the 2-shed and 3-shed plain fabric is mainly used in special lines, such as paper pulps making, sulplate pulp packing and cardboard pulp and fiberboard plants, etc. Other using for linear screen:mining industry, food industry's filtration and dryer. Materail of polyester plain fabric: polyester fiber color: white or blue

We are offering corrugated paper belt. Product features. Products features: tensile strength: warp direction (63-70) mpa. In dry mode; heat resistance: raw materials are polyester synthetic fiber, softening point≥260℃ moisture adsorption: quick absorption and emission of heat, therefore cardboard can be quickly dried air-permeability: up to 2.08m3m2 min, under 40mm water column pressure, through ccep test seams: belt seam part is fabricated with imported steel fasteners and filled with rubber, flat surface, heat-resistance, fastness and non-marking suitbalility: suitable for all types of corrugators, various cardboards and some partcular operation mode geometrical dimension: steady belt dimension, high weaving density, low stretching and contraction and good contact between belt surface and cardboard service life: as long as the same products imported abroad.

We are offering dryer fabric, polyester woven dryer fabric can be divided into 3-shed, 4-shed & 8-shed. Made from high grade flat monofilament and round monofilament polyester yarns.used in the drying section of paper machine to product all kinds of papers. Advantage: strong seam design excellent drying and heat transfer good drainage and permeability long lifetime according to the weaving, polyester dryer fabric can be divided into 3-shed, 4-shed. According to the joining mode, it can be divided into insert, pin, pin ring and spiral ring join. 3-shed one layer and a half polyester dryer fabric suitable for drying papers below 70g. 4-shed double layer polyester dryer fabrics suitable for drying papers above 70g.rectangular wire polyester dryer fabric is suitable for the fore several heating box of the drying zone, quality papers can use all. Features:ease of seamingjoining, fabric stability, drying efficiency sheet runnability, non-marking surface, wear resistance, degradation resistance hydrolysis

We are offering sludge dehydration fabricssludge dewatering beltsludge dewatering fabric sludge dehydration fabrics mainly is used for sludge dehydration in sewage treatment factories. They have the characteristics of good water permeability, air permeability and non-revealed sludge, acid-resisting, alkali-resisting, heat resistance (180℃) .because of their designing structure, the sludge can be peel off easily after pigeonhole filter, so the screen are easily cleaned and have a long working time. Therefore they are designed specially for sludge dehydration. Also mainly used in fruit juice filter pressing industry, color can be white and blue. Also can produce according customer requirment
