NINGBOZHENHAIBOLANGMETALPRODUCTFACTORY

Ningbo, China

Ningbo zhenhai bolang metal product factory was established in 2001.  bolang centres high precision cnc machining as our core competence, the company specializes in producing auto parts, agriculture parts, machinery parts, lighting parts, hardware fittings etc. We can provide pressure casting, sand casting, investment casting, gravity casting, the material covers aluminum alloy such as a380, a390, adc12, yl102, a356, aluminum extrusion of 6000 series, zinc alloy, iron, copper etc. Material: a380 cavity number: 1 process technology: high pressure die casting product dimensions:  customized casting general tolerance: grade gb-ct4 surface finish:  polishing, vibratory deburring flow processes:  die casting, trimming, polishing, vibratory deburring, machining, cleaning, packing, shipping control measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality control inspection facility:  cmm, caliper, plug gage application: auto parts certificate: isots16949:2009 lead time 30-35 days trade term: fob ningbo faq q1. when can I get the price? a:  we usually quote within 2-3 days after we receive the rfq or feedback within 2 days if any questions on prints need to be confirmed. Q2. how long is the lead-time for mold? a:  usually it depends on the size and complexity

The Die Casting Hanger Bracket is a part applied to suspension system, with the purpose of improving the driving stability, the driving comfort and the driving safety. The part is automotive part of famous corporation Chrysler-Fiat. The part have very good monthly demand, which is around 30k pieces. In order to increase the production efficiency, and ensure the control on such as the flash, the ejector pin marks, and no appearance defects such as cold shut, short shot, crack, porosity, foreign material, the part is set to die casting automatically, strictly complying with the die casting work instruction, then, trimming to remove the injection biscuit, the slag strap with trim mold on trim machine. Based on such technology processes, the products will have nice consistency, stable quality, avoiding the issues detrimental to safety handling.   The material of this part is ADC12, a kind of material conforming to standard JIS H 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  Material: ADC-12Cavity Number: 1Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT5Surface Finish: Polishing, tumbling deburringFlow Processes: Die casting, Trimming, Deburring, Vibratory Finish, Machining, Cleaning, Packing, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspe

Zinc die casting idler side awning mount,  it is an customized part applied to motor homes, usually zinc die casting parts is by hot chamber die casting machine and cold chamber die casting machine, the part have small wall thickness and feature of big cavity, so the part will have large enclosed strength to the core of the mold, so to release the part from the mold will require large ejecting force which is decided by the ejector pins. Under such large ejecting force, the ejector pins will have potential issue of deformation. In this case, it is very important to set up the location of the ejector pins, the qty of the ejector pins reasonably. Meanwhile, in order to ensure the smooth mold release, the part will need more mold release agent, so in the control plan, the engineer request to apply to automatic agent spray. When die casting, the temperature of the molten metal should be in control, the higher temperature of the molten zinc alloy, the higher temperature of the mold will be, then heat and decompose the agent to plenty of water vapour, it probably will be involved in the part through the runner, leading to the bubble on the part appearance.  so another point to pay attention is to choose agent containing less volatile substance, to avoid more air trapped in the part.  in addition, the design of the venting system will cause potential possibility on resulting in the bubbles to the part.  at last, the demand of this part is very big, the m

High precision cnc machining pressure balancer parts , it is the part of wiper system. for this part, customer have good quantity demand. There are about 40k per month.  but for quality.should focus on the brittleness features: casting metal grain is too large or small, easy to break or fracture of the casting. Causes1. Excessive overheating of alloy liquid or too long holding time.2, the intense cold, .3, aluminum alloy impurities zinc, iron and other content is too much. Exclusion measures 1, alloy should not overheat, avoid alloy long time insulation.2, improve the mold temperature, reduce the pouring temperature.3. Strictly control the chemical composition of the alloy.4. Keep the crucible coating well  during actual production, the operator should work under the process parameters set up by the engineering according to the operation instruction. Visual inspect the condition of the castings at the back surface, no defect such as cold shut is allowed.  the inspector also should attach importance to the color difference from the back area and front area.  for the top area of the part, the two bosses are required to be tapped, so the cnc workshop should take a couple of pcs to have trial machining to observe is there is porosity at this area.  if the filling of the casting is not well, the bosses may happen to be broken, or with careful visual inspection, we may find color difference at the boss, which like weld mark, how it comes? it is

High precision cnc die casting motor housing is a part applied to exhaust system,   with the purpose to improve the stability, the comfort, the safety of driving.in order to increase the production efficiency, and ensure the control on such as the flash, the ejector pin marks, and no appearance defects such as cold shut, short shot, crack, porosity, foreign material,   in the casting process should not only pay attention to the structure of the casting technology, advanced die-casting mould, die casting machine performance and structure quality, normative adaptability and selection of die casting alloy smelting process; more important role parameters attention pressure, temperature and time on the quality of castings. It is important to control these parameters effectively in the die casting process. Based on such technology processes, the products will have nice consistency, stable quality, avoiding the issues detrimental to safety handling.   the material of this part is adc12, a kind of material conforming to standard jis h 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  material: adc-12cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcontrol measure: incoming material te

High precision customized motor housing is a part applied to motor system, with the purpose to make the stability, the comfort, the safety of driving best. The part is auto part for famous motor corporation , so the development is strict, prior to mass production, the customer request to develop proto die to run prototype samples for velidate the reasonability of the design,  the feasibility in practical application and the mechanical property.   for this large part. deformation should be focused on.features: the overall deformation of the casting geometry does not meet the design requirements. Causes1, the casting structure design is bad, cause uneven contraction.2, mold opening too early, casting rigidity is not enough.3, too small casting inclination.4. Improper operation of casting.5. Improper placement of push rod. Exclusion measures1, improve the casting structure, so that the wall thickness uniformity.2, determine the best mold opening time, strengthen the casting rigidity.3. Enlarge the inclination of casting.4, take the casting should be careful, handle with care.5. The application of special box for casting and the way of removing gate should be proper.6. Some deformed castings can be eliminated by shaping.  material: adc-12 cavity number: 2process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, shot peeningflow processes: die casting, trimming, deburring, v

Factory Supply High Precision Aluminum Die casting  Housing  is a part applied to Gearbox system, with the purpose of enhancing the stability, the safety, the comfort while driving. The part is auto part for famous motor corporation . The material for this part is ADC-12, a kind of material with good fluidity, easy for filling the mold in die casting industry.  But should pay close attention to Skin separationFeature: there is a distinct metal layer on the casting. Causes1, the mold rigidity is not enough, in the process of filling metal liquid, the template jitter.2, the pressure chamber punch and pressure chamber coordination is not good, in the pressure shot forward speed is not stable.3. Improper design of gating system. Exclusion measures 1. Strengthen the rigidity of die and fasten the parts of mould.2, adjust the injection punch and press chamber, ensure good coordination.3. Reasonable design of inner gate. Material: ADC-12 Cavity Number: 2Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT5Surface Finish: Polishing, tumbling deburringFlow Processes: Die casting, Trimming, Deburring, vibratory deburring, Machining, Cleaning, Packing, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equipment: CMM, Caliper, Plug GageApplication: Auto PartsCertificate: ISOTS16949:2009Lead Time

Custom Precision CNC die casting Machining Parts,   this part is an adjustable spring seat, which is used on the chassis system, the carried die casting criterion is Grade GB-CT5, this part is produced as cast.  In addition, the part required surface finish of electrophoresis coating, in order to improve the appearance condition of the part, making all the parts more consistent, we choose to develop corresponding trim mold for removing the injection gate, slag trap, overflow gate and flash around the parting line.  this part  have the quality issue of Bad surface. Features: during the filling process due to temperature of liquid or alloy mold temperature is too low, in similar to the small spots under pressure under the condition of the casting surface formed like distribution area. Causes1. When filling, the metal is dispersed into concentrated droplets, and the wall is impacted at high speed.2. The gate thickness is too small. Exclusion measures 1, the correct design of gating system, to avoid metal liquid splash, improve exhaust conditions, to avoid liquid flow into excessive gas, reduce the gate speed and improve the mold temperature.2. Properly adjust the gate thickness. Aluminum Die Castings Electric Motor Parts: Aluminum Castings of Driving Motor HousingDie Casting Machine: 800 ton1 part per dieMaterial: ADC-12Product Dimensions: 387.4mm*379mm*117.83mmCasting Precision: Grade GB-CT4Machining Precision: ±0.04mm Technologica

Medical apparatus part of high accuracy cnc machining,  this part carried die casting standard of grade gb-ct4, the part has small wall thickness, meanwhile, the part have structure of big cavity, which usually easily cause problem of mold sticking, pull mark etc.  the small wall thickness means the part probably happen to deform during production, which will cause actual application issue. What's more, the part surface area is big, but the thickness is small, in this situation, the far end from the location of injection, the melting aluminum will have risk of solid earlier than expected, it will cause short casting at the far end of the part, then while the part is cooled to indoor temperature, the part will have shrinkage porosity inside.  the part has requirement of surface finish of e-coating, which has process of curing in hot thermal oven, the temperature usually be up to 170-200 degree, the porosity mentioned above will expand and get out from the part, result in pits and bubbles on the coating.  so in the inspection work instruction, there is request that the  qc inspector should fracture the part with hammer, then check the section particle with magnifying lens to see if there is problem of porosity on the section. The inspector also will make a record of the part weight, and control through weighing the part. All these action is to avoid batches rejected while e-coating.  medical equipment parts: teeth milling machine connector she

Custom Machining Parts Precision CNC Machining Parts,  this part is very similar to the Aluminum Die Casting Gearbox shell120. In die casting process, The Decorative pattern problem should be considered.Features: smooth stripes, casting presents on the surface visible to the naked eye, but with the hand feel, color is different from the base metal lines, the removal of 0# can slightly wipe cloth. Causes1, filling too fast.2, too much paint.3, the mold temperature is low. Exclusion measures1, reduce the injection speed as much as possible.2, coating dosage is thin and even.3, improve the mold temperature. The part has requirement of surface finish of E-Coating, which has process of curing in hot thermal oven, the temperature usually be up to 170-200 degree, the porosity mentioned above will expand and get out from the part, result in pits and bubbles on the coating.  So for the first article inspection, the operator of die casting work shop and the QC inspector will fracture the part to confirm the status of the section view, to judge if the density is enough or not. The inspector also will make a record of the part weight, then, during routine inspection, they will just need to weigh the part to see if the part weight is offset the standard weight too much, if so, fracture again to look into the section. By such prevention action, the parts can be avoided batches scrap during outsourced e-coating.  Material: ADC-12Cavity Number: 1Process Technolo

High precision cnc reducer machining parts,   this part is used as stator on high precision reducer, the carried die casting criterion for this part is grade gb-ct4,  the mechanical property should at least satisfy tens of thousands of rotation under required load. When the customer receive the initial samples,   when produce this product, shrinkage should be paid close attention to features: in the process of condensation, the shape of the die is irregular due to insufficient internal compensation, and the surface of the die is rough. Causes1, alloy pouring temperature is too high.2, the casting structure wall thickness is uneven, produce hot knot.3, too low pressure.4, overflow tank capacity is not enough, overflow is too thin.5, the pressure chamber fullness is too small, surplus material (cake) is too thin, the final feeding can not play a role.6, the gate is smaller.7, the local temperature of the mold is high.exclusion measures1. According to the alloy smelting standard, the overheating time of alloy liquid is too long, and the pouring temperature is lowered.2, improve the casting structure, eliminate metal accumulation parts, uniform wall thickness, slow transition.3, appropriately increase the specific pressure.4, increase the overflow tank capacity, thickening overflow mouth.5, increase the pressure chamber fullness, adopt quantitative pouring.6, appropriately improve the gating system to transfer the pressure well. What's more, the part require sur

China precision custom aluminum cnc machining partcnc machinery parts with painting is a small part which is used for mounting the mating parts of wiper, this part have deep cavity,   for this product. Carbon or in-cavity build-up is a important quality issue during die casting. The main reason for scaling is diluting the water of the mold release agent. Normally diluted water is recommended for diluted die casting release agents. If hard water is used, the dissolved calcium and magnesium salts will precipitate after evaporation. These components can not be decomposed by molten metal, so it is easy to form deposits in the cavity. Chemical composition analysis of cavity residues usually shows the presence of mold release agent composition, but the fundamental cause of solid salts is dilution of the water content of the mold release agent. The disorder of water softening system leads to solid deposition in the mold cavity. . What's more, the internal cavity has a lot of sharp teeth for locking the mating shaft part, in this situation, the part is easier to stick to the mold during production, so the mold has to set point cooling, and while die casting, the mold release agent should be sprayed enough at the specified areas to ensure the smooth release, otherwise, the teeth will be easily broken, leading to the scrap.  in the inspection instruction, should specify the first article inspection, the routine inspection frequency etc.   material: adc-12

High precision casting agriculture machinery accessories is a part applied to suspension system, with the purpose to improve the stability, the comfort, the safety of driving.  cold shut will take place for this part. The casting surface is sometimes a molten metal flowing through the line left traces of dark lines. In this case, the cross section of magnesium alloy and thin wall casting is especially obvious. In extreme cases, the casting can't even be fully filled. In other cases, there is something similar to cracks on the surface of the casting, which is actually the trace that the two layers of metal surface are not completely fused when solidified. This is sometimes called "cold separation."". This indicates that the casting has started to solidify before the filling has been filled. This may be due to too low mold temperature, too low melting temperature or excessive cooling. The mold release agent can be used to regulate the heat transfer rate of the mold, so as to avoid the possible problems caused by the dissatisfaction of the casting filler the material of this part is adc12, a kind of material conforming to standard jis h 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  material: adc-12cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deb

High precision aluminum die casting for motor enclosure,  the material for this part is a380, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity. It is commonly applied in home appliance, transmission housing, bracket of engine system etc. For this parts, will have following some issue which should be pay close attention to  the surface roughness of casting should conform to the provisions of gb 6060.1.  casting does not allow cracks,  porosity, bubbles and any penetration defects. No defects such as scratches, dents, defects and mesh burrs are allowed in castings, but the extent and quantity of defects should be consistent with the standards agreed by both suppliers and buyers.the die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning, the section area of the injection gate is not small high pressure die casting is a technology that, inject the molten aluminum under high pressure, high speed into the cavity of the mold to solid to the part. so for this process, there usually to be turbulence flow, leading to air trapped in the part, so the porosity is unavoidable, however, this situation can be improved. Like us, a die casting manufacturer which specialized in die casting industry for more than 16 years, during t

High precision aluminum casting of led lighting,   this part use adc-12 as material, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity. Not only do we produce for customer with an anodized, extruded heatsink with a cnc milled embedded fan pocket, but we produce for customer with matching anodized aluminum cover to slide over the entire fixture. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning. This part is made of high quality aluminum, good thermal conductivity. Can reduce the risk of hardware failure due to overheating. Maximize surface area designed in contact with cooling air. And widely used for computer, power transistor aluminum die casting lamp accessories: aluminum casting of led lighting die casting machine: 200 ton6 parts per diematerial: adc-12product dimensions: diameter 48mm*34.8mmcasting precision: grade gb-ct4machining precision: ±0.02mmtechnological process: die casting, degate, burring, shot blasting, cnc machining, drill holes, cleaning, packing, deliverycontrol measure: first item inspection, routing inspection, final item inspection, incoming test and outgoing quality controlinspection equipment: caliperssurface treatment: shot blasting certificate: isots16949:2009lead time: 30-35 days

Cnc machining aluminum heat sink in black anodizing,   the material of this part is adc-12, a most common  die casting material, having good processability, this material have good thermal conductivity as the physical property.  in the heatsink die casting process.  techique workers and managers are the deciding factor in the quality management of the enterprise, is in the whole process of production and operation, quality function and activity process necessary to achieve product quality management, the function and process are realized by the people, who is in the leading position in quality control and quality management of products and plays the key role. Quality management requirements to ensure product quality and quality of work, quality of work depends largely on the ability and spirit "or" quality ", the relationship between them can be expressed as the quality of work, quality of products, the quality of personnel, personnel can be seen from this relationship (including decision-making, management, staff the quality of the team) is the basis of product quality. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning,   aluminum die casting lamp accessories: aluminum casting of led lightingdie casting machine: 200 ton6 parts per diematerial: adc-12product dimensions: diame

Custom adc12a380a360 die casting heat sink with aluminium,   the part use adc-12 as material,  this aluminum alloy is al-si-cu serial, the chemical composition of adc-12 is: (si)9.6~12.0, (mg)≤0.3, (cu)1.5~3.5,  (zn)≤1.0, (fe)≤1.3, (mn)≤0.5, (ni)≤0.5, (sn)≤0.3, (pb) ≤0.1, (cd) ≤0.005, (al) the remaining. Our heatsink has the following features 1) unique design does not smoke wall, strengthen heat transfer. Thermal conductivity of aluminum 237wmk, iron 80wmk; material of high thermal conductivity and the radiator of the unique design, compared with traditional radiator heat dissipation of each piece not only increased, but not smoked wall, reduce consumer worries, improve the comfort, save the indoor space area. And it's an excellent product for low temperature heating.2) the appearance is simple and elegant; set functional and decorative in one. Compared with the traditional radiator, consumers do not need to install the grille to increase the beauty, reduce the cost of decoration, increase the room area. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning. Aluminum die casting lamp accessories: aluminum casting of led lighting die casting machine: 200 ton 6 parts per diematerial: adc-12product dimensions: diameter 48mm*34.8mmcasting precision: grade gb-ct4machini

Machining die casting lighting parts for heat sink,   our heatsink must have below standard. The heatsink surface has no harmful substance volatilization, and has no harm to environment and human body. According to the test report of the national quality supervision and inspection center with the national radiator radiator committee recommended products of the company, in the company's products, the surface of the radiator is released into the air pollutant limits "of the requirements of formaldehyde is less than 0.03, the actual value is less than or equal to 0.017; benzene requirement is less than 0.04, the actual value is less than or equal to 0.001; for toluene is less than 0.07, the actual value is less than or equal to 0.006; for xylene is less than or equal to 0.07, the actual value is 0.004; total volatile organic compounds (tvoc) is less than or equal to 0.20, the actual value is less than or equal to 0.017. Therefore, we can say that the products produced by the company, in the process of using no harmful substances volatilization. No harm to the human body and the environment, environmental protection and pollution-free green products. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning. This part is made of high quality aluminum, good thermal conductivity. Can reduce the risk of hardware failure due

Aluminum street light housing made by 800 ton die casting machine,   this part use adc-12 as material, it is a japanese aluminum type. The material conforms to criterion of jis h 5302-2000, it is a very common material in high pressure die casting industry. The material is equivalent to chinese aluminum alloy yl113, the corresponding standard is gbt 15115-2009. Our heatsink has the following features 1, light weight, only the same heat loss of cast iron radiator weight of 13.2, safe and reliable, high thermal efficiency, good thermal conductivity, energy saving, environmental protection, long service life.3, the surface after degreasing, oxidation spraying, to ensure that the coating does not fall off for a long time, anti impact.4, the style is simple, beautiful, generous without losing fashion design, small size, light weight, easy installation, passing europe excellent radiator production process. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning. Aluminum die casting lamp accessories: aluminum casting of led lighting die casting machine: 200 ton 6 parts per diematerial: adc-12product dimensions: diameter 48mm*34.8mmcasting precision: grade gb-ct4machining precision: ±0.02mmtechnological process: die casting, degate, burring, shot blasting, cnc machining, drill holes, cleaning, packiwww.blcastings.com

Aluminium LED Lamp die casting Housing,   this part use ADC-12 as material, a Japanese aluminum type. the material is equivalent to Chinese aluminum alloy YL113, the corresponding standard is GBT 15115-2009. And the material is also equal to A383, which carry the criterion of ASTM B85-03 Specification for Aluminum-Alloy Die Castings Aluminum die casting for Heatsink has the following features Compare with other Material, the Aluminum alloy for Heatsink have advantages Such as, energy saving, Material saving, Decoration, Cost, weight and so on. The die casting criterion carried on this part is Grade GB-CT4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on CNC machining, especially the rough turning. Aluminum Die Casting Lamp Accessories: Aluminum Casting of LED Lighting Die Casting Machine: 200 ton 6 parts per dieMaterial: ADC-12Product Dimensions: Diameter 48mm*34.8mmCasting Precision: Grade GB-CT4Machining Precision: ±0.02mmTechnological Process: Die casting, Degate, Burring, Shot blasting, CNC Machining, Drill holes, Cleaning, Packing, DeliveryControl Measure: First item inspection, Routing inspection, Final item inspection, Incoming test and Outgoing quality controlInspection Equipment: CalipersSurface Treatment: Shot Blasting Certificate: ISOTS16949:2009Lead Time: 30-35 daysTrade Term: FOB Ningbo

Auto transimmison die casting mounting .  this part is a auto mounting applied on the transimmison, the die casting part is irregula and duplicated, so, during the actual production, the following problems may be produced after processing a, surface bubble.  when aluminum alloy in the pressure chamber fullness is too low, the volume of air pressure is too fast.the mold exhaust is bad, the aluminum alloy liquid does not exhaust. if the melting temperature is too high, the exhaust tank should be increased, the mold temperature at the bubble point will be reduced, and the degassing and slag removal of the aluminum alloy liquid will be strengthened. If the mold temperature is too low, the aluminum liquid cooling time is too fast, open top products, the need to increase the dwell time, don't be too quick to open, full combustion. Reduce the concentration of mold release agent. B, shape deformation if product structure is unreasonable, will cause uneven contraction, if mold is opened too fast, the product does not have complete solidification cooling,  it is necessary to change the product structure, adjust the mold opening time. Otherwise, will cause shape deformation material: a380cavity number: 1process technology: high pressure die casting, cold chamberproduct dimensions: customizedcasting general tolerance: grade gb-ct4surface finish: polishingflow processes: die casting, degating to remove the residual of the gate, polishing and deburring to remove the

High precision cnc machining elbow is also a part applied to agriculture machine, the monthly demand for this part is wonderful, is up to 25000-30000 pieces. In this case, while developing the tooling, on the premise of ensuring the part quality, we choose to design the mold of two cavities. Why no more cavities?  it is because the part has feature of two boss which require no draft on the surface, so it should be introduced to active slides to realize, which will make the mold bigger.  the machining elbow should comply with following requirements 1, the factory inspection of the surface quality of the die casting should be checked by piece, and    the test result should be in conformity with of this standard. 2, the surface roughness of die casting is carried out according to gbt6060.1. 3, the surface to be polished for castings shall be carried out according to gbt 6060.4. 4, the surface of castings to shot blasting and sand spraying according to  gbt 6060.5. 5, the test methods and inspection rules for the internal quality of die castings can include: x ray photograph, ndt test, metallographic picture and die casting profile, and the test results should comply with the requirements of this standard 3.4.6. 6, other test methods and inspection rules shall be carried out in accordance with gbt15114 regulations. Material: a380 cavity number: 2process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grad

Aluminum die casting communication equipment parts is a part applied to communication equipment, with the purpose to improve the stability, the comfort, the safety of driving. The part is auto part for famous motor corporation. Below is the detail of this casting die casting machine: 800 ton1 part per diematerial: adc-12product dimensions: 270mm*200mm*76mmcasting precision: grade gb-ct4machining precision: ±0.05mmtechnological process: die casting, degate, burring, shot blasting, machining center (a process machining), four axis machining center (b process machining), cleaning, packing, deliverycontrol measure: first item inspection, routing inspection, final item inspection, incoming test and outgoing quality controlinspection equipment: cmm and screw gaugesurface treatment: shot blasting cavity number: 1surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcertificate: isots16949:2009lead time: 30-35 daystrade term: fob ningbo

Aluminium alloy precision cnc die casting gear reducer parts with competitive price,   the material for this part is adc-12, a kind of material, having good fluidity, which is good for filling while die casting. This material is a good material to produce end cover, housing, gearbox, bracket etc. The composition of adc-12 is:(cu)1.5~3.5, (si)9.6~12.0, (mg)≤0.3, (zn)≤1.0, (fe)≤1.3, (mn)≤0.5, (ni)≤0.5, (sn)≤0.3, (pb) ≤0.1, (cd) ≤0.005, (al) the remaining. The cavity number for this part is 2, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, the wall thickness is small, not much machining allowance left. The part is a kind of motor housing, the bore is used to assemble the bearing, so the concentricity requirement is higher than the other parts. Meanwhile, as the housing for bearings, the part has definite mechanical property requirement.  for this product, we should pay close attention to deformationfeatures: the overall deformation of the casting geometry does not meet the design requirements.causes1, the casting structure design is bad, cause uneven contraction.2, mold opening too early, casting rigidity is not enough.3, too small casting inclination.4. Improper operation of casting.5. Improper placement of push rod. Exclusion measures 1, improve the casting structure, so that the wall thickness uniformity.2, determine the best mold opening time, strengthen the casting rigidity.

 Custom CNC Machining Pressure Die Casting Machinery Parts,   through the review to the geometry and the required dimensions and tolerances from the print, we will all find this part is NOT simple,  the carried die casting criterion for this part is Grade GB-CT4, in application,   For this part, we try to have no oxide inclusion and slag inclusion. Characteristics: there are small particles or blocks of hardness higher than the metal matrix in the casting matrix, which makes the machining difficult, and the tool wear is serious, and the hard spots with different brightness are often displayed on the castings after processing. CausesThe alloy mixed or precipitation than the base metal hard metal or non-metallic materials, such as AL2O3 and free silicon etc..1, alumina (AL2O3).(1) aluminum alloy is not refined.(2) mixed oxide when pouring.2. Complex compounds composed of aluminum, iron, manganese and silicon are mainly formed by MnAL3 in the molten pool at a relatively cold position, then Fe is precipitated at the core of MnAL3, and silicon is involved in the reaction to form compounds.3. Free silicon mixture(1) the silicon content of Al Si alloy is high.(2) free silicon exists in Al Si alloy during semi liquid casting. Exclusion measures1, smelting should be reduced unnecessary agitation and overheating, keep the purity of alloy liquid, aluminum alloy liquid long-term heat preservation in the furnace, should be periodic refining degassing.2, aluminum alloy c

High pressure aluminum die casting part for gear box is a  part which is used as mount head on gearbox system. The technology for this part is high pressure die casting. Our factory specializes in this industry for more than 16 years. the material for this part is adc-12, a most common aluminum alloy in die casting industry.  the part has requirement of powder coating treatment, so the density of the part is very important, unqualified part usually have a lot of void inside. So the mold design is very important, such as the layout of the location of the injection gate, runner, venting system etc. The technology of powder coating has process of curing in oven under about temperature of 200 degree, in this case, the porosity inside of the parts will expand to get out, leading to bubble on the part surface, such defect is unacceptable.  for this product, we should pay close attention to deformationfeatures: the overall deformation of the casting geometry does not meet the design requirements.causes1, the casting structure design is bad, cause uneven contraction.2, mold opening too early, casting rigidity is not enough.3, too small casting inclination.4. Improper operation of casting.5. Improper placement of push rod. Exclusion measures 1, improve the casting structure, so that the wall thickness uniformity.2, determine the best mold opening time, strengthen the casting rigidity.3. Enlarge the inclination of casting.4, take the casting should be car

 oem custom precision machining die cast aluminum parts it is a part applied to suspension system, with the purpose to improve the stability, the comfort, the safety of driving. The part is auto part for famous motor corporation. The part have very good monthly demand, which is around 50k pieces. The products should pay attention to relative displacement feature: a part of the casting is staggered with the other part on the parting surface, and the relative displacement occurs. Causes 1. Die insert displacement.2. Die guide wear.manufacturing error of insert in 3 and half mould. Exclusion measures 1. Adjust the insert and fasten it.2. Change guide pin guide sleeve.3, trim, eliminate errors. The adc12 material  is  a kind of material conforming to standard jis h 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  material: adc-12 cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcontrol measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality controlinspection equipment: cmm, caliper, plug gageapplication: auto partscertificate: isots16949:2009lead time: 30-35 daystrade term: fob ningbo

Factory Custom Aluminum Machinery Die Casting Parts Made in China,  it is a part applied to Reducer system, a housing for Reducer, the technology for this part is section extrusion, the material for this part is A390 Aluminum, the technology decide that such section material have very good density, so the part made from this material don't have concern on the voids or internal porosity, which should be well noted in surface finish of E-coating. For this part, we should focus on FlashFeature: the thin sheet of metal on the edge of the casting. Causes1. The clamping force of the machine is not adjusted well before the injection.2, die and slider damage, locking components failure.3, die insert block and slider wear.4, die strength is not enough to cause deformation.5. The sundries on the parting surface are not cleaned up6, the projection area calculation is not correct, more than the clamping force.7, the injection speed is too high, forming pressure shock peak is too high. Exclusion measures1, check the clamping force or pressurization situation, adjust the injection booster mechanism, reduce the peak pressure injection pressure.2, check the mold slide damage degree and trim, to ensure that locking components play a role.3, check the wear and repair.4. Calculate die strength correctly.5. Remove the sundries on parting surface.6. Correct calculation and adjustment of clamping force.7. Adjust the injection speed appropriately. For this part, there is minimum order qty

High Precision CNC Machining Medical Mounting Bracket,  this part is a assembly part of Medical Machine, the body of the part is produced by high pressure die casting, the carried die casting criterion for this part is Grade GB-CT4, the part is made up of 5 parts, a M8*1.25 nut, a half-height Jam nut, a spring pin, the aluminum mounting head, and the threaded M8*1.25 rod of 140 millimeter length.  For this product, we need to focus on CrackleFeatures: the alloy matrix on the casting is broken or broken to form a thin slit, there are two kinds of penetration and non penetration, there is a trend of development.Cracks can be divided into two types: cold crack and hot crack. The main difference is that the metal is not oxidized at the crack of the cold crack, and the metal is oxidized at the crack of the hot crack. Causes1, the casting structure is unreasonable, shrinkage is hindered, casting fillet is too small.2, the core pulling and ejection device skewed in the work, uneven force.3, low mold temperature.4, mold opening and core pulling time is too late.5, the alloy improper or harmful impurities are too high, so that the plasticity of the alloy drops. Zinc alloy: lead, tin, cadmium, iron, high aluminum alloy: zinc, copper, iron high copper alloy: zinc, silicon, high magnesium alloy: aluminum, silicon, iron on the high side Exclusion measures1, improve the casting structure, reduce the wall thickness difference, increase casting fillet.2. Modify the die structure.3

Aluminum die Casting part of Heat Exchanger,  it is a new part developed, the part is the major housing for the motor . the cavity number for this part is 1, according to the required tolerance and dimensions, the difficult point of this part is the CNC machining work, The CNC machining work is finished on high precision machining center, we used BROTHER machining center, the accuracy can be up to 0.005 mm. The fourth rotary table we used is NIKKEN.  Prior to machining, the part will be shot peeninged, or called shot blasting, shot peening is to make the appearance of the part more consistency, eliminating the mark of deburring more or less. What's more, shot blasting also can make the mechanical property better. In die casting process, should pay attention to gas bulging bubbleFeatures: skin of casting, formed gas bulging bubble. Causes1, mold temperature is too high.2, the filling speed is too high, the metal flow into the gas too much.3, coating gas, excessive amount of unburned, before pouring, the volatile gas enclosed in the surface layer of the casting.4, the exhaust is not smooth.5, premature opening.6, alloy smelting temperature is too high. Exclusion measures1. Cooling mold to working temperature.2, reduce the injection speed, avoid eddy gas inclusion.3, the small air quantity amount of coating, thin and uniform, then die out.4. Cleaning and adding overflow tank and exhaust duct.5, adjust the mold leaving time.6. Dressing smelting process. The ma

Aluminum die Casting of Motor HousingShell  is a part using aluminum alloy of ADC12, which has good liquidity, easy to fulfill the cavity of mold, it is a kind of Customized Aluminum Die Casting, the part is applied to automotive motor system, which is used to decrease the noise of the automotive while running, the part has requirement on the mechanical property. about Sunken, we should pay close attention Feature: a concave part on the smooth surface of a casting, and its surface is naturally cooled. Causes1, the casting structure design is unreasonable, there are local thick parts, produce hot knot.2. High shrinkage of alloy.3, the gate cross section area is too small.4, lower than.5, mold temperature is too high. Exclusion measures1, to improve the casting structure, so that the wall thickness is slightly uniform, the difference between the thickness of the junction should gradually ease the transition, eliminate the hot knot.2. Choose the alloy with small shrinkage.3. Set gating system properly, increase the sectional area of the gate appropriately.4. Increase the shooting force.5. Adjust the mould heat balance condition, adopt the temperature control device and cooling etc.. Aluminum Die Casting Electric Motor Parts: Aluminum Casting of Motor Housing Shell Die Casting Machine: 280 ton1 part per dieMaterial: ADC-12Product Dimensions: 198mm*134mm*112mmCasting Precision: Grade GB-CT4Machining Precision Axle hole: ±0.05mm Technological Process

Customized High Quality Aluminum Die Casting Machine Parts is a part using aluminum alloy of ADC12, which has good liquidity, easy to fulfill the cavity of mold, it is a kind of Customized Aluminum Die Casting,   In the die casting process, should pay attention to the mould sticking Die sticking is the result of adhesion between molten alloy and die steel. High temperature and corrosion will aggravate the problem of mould sticking, especially in the special area of mould. Shielding coating between molten metal and tool steel can prevent mold sticking. Some alloys are more prone to die sticking. we uses advanced technology to develop a variety of die casting lubricants, in order to meet the requirements of different temperature range and alloy materials. The proprietary polymer ensures the excellent die casting effect under high temperature conditions. The silicon free mold release agent can be applied to the mold surface with lower temperature the part is applied to automotive Valve system, the part has requirement on the mechanical property, the processes of this part is not complex, but always auto part has large volumn, to ensure the consistency, for mass production, in process of die casting, the part will apply to automatic mold release agent spray, pick up the part with robot arm, the operator just need to setup the tooling according to the work instruction, and trim the casting with trim machine. In this case, the production efficiency will be higher, andw

 Manufacturer High Pressure Machine Aluminum Die Casting Parts ,   This part is a housing for Transimssion system.The big issue for this part is the porosity problem. Die casting is often used to make lightweight parts using light metals to replace steel or iron parts. Since the inherent strength of light metals is lower than that of steel components, any reduction in the strength of components shall be avoided. The small hole in the cross section of the casting has a great influence on its tensile strength.There are two types of pores, one is stomata. Porosity is the result of the high speed injection of metal melt into the mold. However, the decomposition of any organic compound in the mold or moisture in the mold will aggravate the porosity. Because all molds and punch lubricants may contain water, organic matter, or both, these substances may cause porosity problems. The material of the part is ADC-12, a Japanese aluminum type. The material should conform to standard of JIS H 5302-2000,  a very common material in high pressure die casting. The material is equivalent to Chinese aluminum alloy YL113, the corresponding standard is GBT 15115-2009. And the material is also equal to A383, the criterion is ASTM B85-03 Standard Specification for Aluminum-Alloy Die Castings. Material: ADC-12Cavity Number: 2Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT4Surface Finish: Polishin

 aluminium alloy die casting auto engine parts for machine,  the part is a housing for auto engine system which is applied to bus, the part is a cover.in die casting process. Shrinkage is a serious problem. Should be careful. The reason for shrinkage is that the liquid density of most casting metals is slightly lower than that of solid density. This means that the volume of the metal decreases during the curing process. As long as the liquid metal can enter the casting before curing, it will minimize the shrinkage phenomenon. Unfortunately, because of the many different cross-sections of the casting, the "die hot spot" is inevitable. This part of the casting remains liquid after the other part is solidified, so it shrinks when solidified. The best way to solve the shrinkage problem is to improve the design of cavity, strengthening pressure and metal temperature. The part has request on surface finish of e-coating to satisfy the daily application, so the density of the part is important item to control, in engineering's work instruction, the operator should fracture the part and look into the section of the fracture to see if the particles is good and dense prior to production, ensure there is no big single porosity or a lot of continuous small porosity, or while e-coating, during process of curing in over under 170-200 degree temperature,  the porosity existing internal will expand to get out, leading to big cosmetic issues on this part, such as b

Precision pressure casting agriculture machinery front housing,  the part is a housing for dc motor on agriculture machinery. In manufacturing process, this part probably have "white-spot" .a common concern for die casting mould release agents is the negative effects that may have on the coating or bonding processes. As the main role of mold release agent is to prevent adhesion between the casting and the mold surface, the use of mold release agent may affect the adhesion or coating , and if the mold release agent is not completely removed during the cleaning process, it may cause "white spot" defect. Before using spray or electroplating process, alkaline lotion is used to wash the release agent easily. The part has request on surface finish of e-coating to satisfy the daily application, so the density of the part is important item to control, in engineering's work instruction, the operator should fracture the part and look into the section of the fracture to see if the particles is good and dense prior to production, ensure there is no big single porosity or a lot of continuous small porosity, or while e-coating, during process of curing in over under 170-200 degree temperature,  the porosity existing internal will expand to get out, leading to big cosmetic issues on this part, such as bubble, pits etc.  material: adc-12cavity number: 1process technology: high pressure die casting, cold chamberproduct dimensions: customizedcasting general tolerance: grade

High precision aluminum casting of led lighting,   this part use adc-12 as material, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity.  at present, in die casting process, there are many pores usually die casting surface after machining, resulting in subsequent high processing costs, more importantly, they have more holes .die castings in subsequent processing may also cannot meet the actual work requirements, the defective rate is high. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning,   in order to ensure quality step 1: check whether the mould is in good condition. Step 2: the molten hot alloy is injected into the mould under suitable conditionsstep3: after the molten alloy is solidified,  the part in the mould is pushed out at the right timealuminum die casting lamp accessories: aluminum casting of led lightingdie casting machine: 200 ton6 parts per diematerial: adc-12product dimensions: diameter 48mm*34.8mmcasting precision: grade gb-ct4machining precision: ±0.02mmtechnological process: die casting, degate, burring, shot blasting, cnc machining, drill holes, cleaning, packing, deliverycontrol measure: first item inspection, routing inspection, final item inspection, incoming test an

Aluminum heat sink heatsink module cooler fin for high power transistor semiconductor ,   this part use adc-12 as material, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity. For the heatsink, the radiator assembly requirements are following: 1, in the operation process, must take anti-static measures. 2, before assembly, check the components and radiator should be clean, no sharp feet, burrs and other defects, and to install the radiator and components of the contact surface wipe clean.  3, components and radiator connection fastening, correct, without damage to components.  4, insulation pieces if damaged, stains or can not be used after disassembly. Now, not only do our factory produce for you with an anodized, extruded heatsink with a cnc milled embedded fan pocket, but we produce  for you with matching anodized aluminum cover to slide over the entire fixture. The die casting criterion carried on this part is grade gb-ct4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on cnc machining, especially the rough turning. This part is made of high quality aluminum, good thermal conductivity. Can reduce the risk of hardware failure due to overheating. Maximize surface area designed in contact with cooling air. And widely used for computer, power transistor. Aluminum die casting lamp accessories: al

Stainless anodizing aluminum die casting plating door handling, it is a part applied to cabinet, the part have very good monthly demand, which is around 60k pieces. The hardware handling with variety of finishes to enhance your cabinets' design.find door accessories to enhance not only the look and feel of your cabinets, but also to enhance the function of hang clothes. Zinc alloy is good metal for die casting, making small parts is very economical, suitable for precision die casting products, easy coating, it has high compressive strength, high plasticity, long casting life. The zinc material  is  the material conforming to standard jis h 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  material: zinc cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcontrol measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality controlinspection equipment: cmm, caliper, plug gageapplication: auto partscertificate: isots16949:2009lead time: 30-35 daystrade term: fob ningbo

Anodizing aluminum die casting plating drawer handling, it is a part applied to drawer, the part have very good monthly demand, which is around 50k pieces. For this drawer handling, we need to check  1, whether the color difference plating ? 2, whether the hardware has trachoma, rust, spit acid phenomenon? 3, whether polished surface is smooth, is there no obvious uneven? the aluminum material  is  the material conforming to standard jis h 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  material: aluminum cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcontrol measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality controlinspection equipment: cmm, caliper, plug gageapplication: auto partscertificate: isots16949:2009lead time: 30-35 daystrade term: fob ningbo

Custom aluminum office furniture aluminum die cast chair base, it is a part applied to chair, the part have very good monthly demand, which is around 60k pieces.the die casting chair base with variety of finishes to enhance your chairs' design. This part is made of many kinds of high quality materials through advanced equipment. According to the principle of ergonomics, the design is not only novel, but also comfortable and reliable. High quality aluminum material is melted and then molded into special mould. After cooling, sanding, dust removal, pickling, phosphating and other processes, high temperature electrostatic outdoor plastic powder spray treatment, it have corrosion resistance, anti-aging ability. Material: zinc cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcontrol measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality controlinspection equipment: cmm, caliper, plug gageapplication: auto partscertificate: isots16949:2009lead time: 30-35 daystrade term: fob ningbo

Ningbo zhenhai bolang metal product factory was established in 2001.  bolang centres high precision cnc machining as our core competence, the company specializes in producing auto parts, agriculture parts, machinery parts, lighting parts, hardware fittings etc. We can provide pressure casting, sand casting, investment casting, gravity casting, the material covers aluminum alloy such as a380, a390, adc12, yl102, a356, aluminum extrusion of 6000 series, zinc alloy, iron, copper etc. Material: a380 cavity number: 2 process technology: high pressure die casting product dimensions:  customized casting general tolerance: grade gb-ct4 surface finish:  polishing, vibratory deburring flow processes:  die casting, trimming, polishing, vibratory deburring, machining, cleaning, packing, shipping control measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality control inspection facility:  cmm, caliper, plug gage application: auto parts certificate: isots16949:2009 lead time 30-35 days trade term: fob ningbo faq q1. when can I get the price? a:  we usually quote within 2-3 days after we receive the rfq or feedback within 2 days if any questions on prints need to be confirmed. Q2. how long is the lead-time for mold? a:  usually it depends on the size and complexity o

Aluminum die casting housing of pivot side,  the part is a pivot side housing, similar to the pivot housing 421-1034 and 421-1035, this pivot side housing have two long threaded pillars, from these two pillars, there to be two shaft assembled. Then with a mating motor side housing, the dc motor work inside the housings. there are two difficult points, not like the pivot housing 421-1034, this part has a big flat feature at the bottom of the pillar, the wall thickness is only about 3 mm, the same as the pivot housing, the injection gate can only be located on the bottom flat plate feature, or will be significant problem of short casting on the flat feature, then the pillar has rectangularity request to the bottom surface, so for degating, the operator should pay attention to put the part on a platform, then degate using hammer of wooden material or rubber material, to ensure that part won't deform while degating. What's more, the parts have two long pillars, which has big risk of having problem of density, to run a mold flow analysis to decide a proper injection gate, venting system is very important, otherwise, while machining, there will be big porosity exposed from the thread surfaces, what's worse, while e-coating, under high temperature curing in oven, the porosity now seen from the surface but existing internal will also try to expand to get out, leading to big cosmetic issues on this part.  about the surface finish of e-coating, for this part, a

Tubular System Die Casting Bracket,  this part is very similar to the Aluminum Die Casting Mount Bracket 306-1235, another type, the two parts almost have the same characteristics. so the difficult points of Aluminum Die Casting Tubular System Bracket is the same as the 306-1235, the part also implement die casting general standard of Grade GB-CT4, the part has small wall thickness, it means the part probably happen to deform during production, which will cause actual application issue.  After Die Casting, the next process is de-gating, then the workshop will arrange to polish to remove the gate vestige and overflow residual. then drilling the hole, prior to e-coating, the part will be vibratory deburred. with this treatment,  the scratch, the mark after deburring will be improved, the appearance will be much more consistency and beautiful. The part has requirement of surface finish of E-Coating, which has process of curing in hot thermal oven, the temperature usually be up to 170-200 degree, the porosity mentioned above will expand and get out from the part, result in pits and bubbles on the coating.  So for the first article inspection, the operator of die casting work shop and the QC inspector will fracture the part to confirm the status of the section view, to judge if the density is enough or not. The inspector also will make a record of the part weight, then, during routine inspection, they will just need to weigh the par

Aluminum Die Casting Wiper Motor Housing,  it is a new part developed, the part is the major housing for the DC motor of the windscreen wiper. the cavity number for this part is 2, according to the required tolerance and dimensions, the difficult point of this part is the CNC machining work, the wall thickness is very small, at the smallest area, after machining, it is only about 1.5 mm. for the raw material as cast, the wall thickness of the small end is only 2 mm, the die casting criterion carried on this part is Grade GB-CT3, the general tolerance standard for the dimensions unspecified is ISO 2768-MK. What's more, this part has some form and location tolerance requirement, such as the rectangularity, the planeness, positioning degree. For the development of this part, in order to shorten the lead time, shorten the timing of validating, determine the best parameters for die casting process, the engineer kept following the whole die casting process. The main four parameter referred of die casting technology is press, speed, timing, temperature.   The CNC machining work is finished on high precision machining center, we used BROTHER machining center, the accuracy can be up to 0.005 mm. The fourth rotary table we used is NIKKEN.  Prior to machining, the part will be shot peeninged, or called shot blasting, shot peening is to make the appearance of the part more consistency, eliminating the mark of deburring more or less. What's more, shot blastin

Aluminum Die Casting Transmission Housing,  it is an auto part, which is applied to transmission system, it the housing of the automotive gearbox. The estimated annual usage is 250k pieces. Theoretically for such large demand, the cavity number of the mold for this part should be more than 2. However, considering the irregular shape, the part has two slides, what's more, this part has very strict porosity request, also require leak test by air. In order to ensure the density of the part, the cavity number is only 1.  As an experienced die casting manufacturer, we ran solidification analysis to simulate the status of the filling of the melting aluminum to look into if the design of the mold is proper or not, such as the location of the injection gate, runner, overflow gate, slag strap, venting slot, ejector pins etc.  Then, prior to the fabrication of the tooling, the CAD model of the design will be sent to the customer for confirmation, to avoid if any interference to the assembly or application to the customer. Of course, it is also a standard procedure to ask for engineering approval from the customer. The material for this part is ADC-12, a kind of material, having good fluidity, which is good for filling while die casting. This material is a good material to produce end cover, housing, gearbox, bracket etc.  There is high precision tolerance on the machining work, as well as high shape and location tolerance requirement. S

Aluminum Die Casting Walking Motor Housing,  the material for this part is ADC-12, a kind of material, having good fluidity, which is good for filling while die casting. This material is a good material to produce end cover, housing, gearbox, bracket etc. The composition of ADC-12 is:(Cu)1.5~3.5, (Si)9.6~12.0, (Mg)≤0.3, (Zn)≤1.0, (Fe)≤1.3, (Mn)≤0.5, (Ni)≤0.5, (Sn)≤0.3, (Pb) ≤0.1, (Cd) ≤0.005, (Al) the remaining. The cavity number for this part is 2, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on CNC machining, the wall thickness is small, not much machining allowance left. The part is a kind of motor housing, the bore is used to assemble the bearing, so the concentricity requirement is higher than the other parts. Meanwhile, as the housing for bearings, the part has definite mechanical property requirement.  Die Casting is a technology that, press the melting aluminum under high pressure, high speed, usually the shot procedure will be finished in a few seconds. In this case, there probably be air trapped because of turbulence, eddy, so the porosity is unavoidable, but can be decreased or improved. Usually, in die casting factory, visual porosity on machining surface is not allowed, so the solution is to simulate or validate sufficiently by mold flow analysis prior to the building of the tooling, to ensure the density of the casting, by locating the major injection gate, cross

Aluminum Die Casting  Motor Side Housing,  the material of this part is ADC-12, the part is a housing for DC motor on windscreen wiper system which is used on bus, boat after assembly, the part is an end cover, work with a mating pivot housing, the DC motor run in these two housing.  On this part, there are a lot of teeth. the clearance of the teeth is small, what's more, the permissible draft of the teeth is only 1 degree, there will be potential risk for failure of mold release.  The material of this part is ADC-12, it  a Japanese aluminum type. The material should conform to standard of JIS H 5302-2000, a very common material in high pressure die casting. The material is equivalent to Chinese aluminum alloy YL113, the corresponding standard is GBT 15115-2009. And the material is also equal to A383, the criterion is ASTM B85-03 Standard Specification for Aluminum-Alloy Die Castings. The part has request on surface finish of E-Coating to satisfy the daily application, so to test the density of the part is very important. , in engineering's work instruction, the operator should fracture the part and look into the section of the fracture to see if the particles is good and dense prior to production, ensure there is no big single porosity or a lot of continuous small porosity, or while e-coating, during process of curing in over under 170-200 degree temperature,  the porosity existing internal will expand to get out, leading to big c

Zinc Alloy Awning Mount of Motor Side,  it is an customized part applied to motor homes, the technology for this part is high pressure die casting, the difficulty for this part is the wall thickness, it is very small, and the allowed draft angle is very small, only 1 degree.  From the part, we can easily find that the parts have a lot of features of big cavities, so the part will have big potential risk of mold release problem, if so, the part may happen to be deform, sticking to the mold etc, especially when the part sticking to the mold, if no clear in time, while next shot, the mold may be destroyed while clamping.  The material for this part is zamark 3, a kind of material having good fluidity and mechanical property, perform well in die casting. the material is usually applied to lighting part, decoration etc. The chemical composition is: (Al) 3.8~4.3, (Cu)

Aluminum Die Casting Tractor Engine Housing,  this part is used as engine housing on the tractor facility, the part have very big cavity, so on the mold, there will be a big feature protrude from the surface, then while feeding the mold, as the injection gate is located at the bottom of the surface, so when the high-speed molten aluminum is injected, it will hit the big protruded feature, leading to eddy or turbulence, what's more, because of the big round feature, sometimes the molten aluminum will start to be solid at the back area of the feature though not fill sufficiently, leading to cold shut, or shrinkage porosity. Meanwhile, the top of the part will also be a position with high risk of feeding problem, as it is far-distance end on the part, the most difficult area for aluminum to reach. For such problem, the control method is to increase the temperature of the molten aluminum, to supervise the die temperature with infrared thermometer.   Then, during actual production, the operator should work under the process parameters set up by the engineering according to the operation instruction. Visual inspect the condition of the castings at the back surface, no defect such as cold shut is allowed.  The inspector also should attach importance to the color difference from the back area and front area.  For the top area of the part, the two bosses are required to be tapped, so the CNC workshop should take a couple of pcs to have trial machining to

Aluminum and steel alloy auto die casting housing,    the material for this part is a380, this part is big. During the die casting. higher specific pressure is required, so that higher filling speed can be obtained.which is beneficial for alloy to overcome mold filling resistance.and effectively fill each part of the cavity meanwhile, the speed of die casting is also very important.the ejection speed will affect the quality of aluminum and steel alloy die casting housing.   the another key point of affecting the quality of aluminum housing is the pouring temperature the temperature can not be too high or too low. Both of them will cause the shrnkage. The thinner the wall thickness is, the more complex the die casting is and the higher the mould temperature is, which is beneficial to the filling of the alloy liquid. Material: a380cavity number: 1process technology: high pressure die casting, cold chamberproduct dimensions: customizedcasting general tolerance: grade gb-ct4surface finish: polishingflow processes: die casting, degating to remove the residual of the gate, polishing and deburring to remove the burrs, polishing to remove the parting line, flash,  high precision cnc lathe machining, cleaning, packaging, storaging, shippingcontrol measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality controlinspection equipment: cmm, caliper, plug gage, screw gaugeapplication: m

High precision CNC die casting Machining parts,   this part use A380 as  material, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity.  At present, in die casting process, there are many pores usually die casting surface after machining, resulting in subsequent high processing costs, more importantly, they have more holes die castings in subsequent processing may also cannot meet the actual work requirements, the defective rate is high. The die casting criterion carried on this part is Grade GB-CT4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on CNC machining, especially the rough turning,   In order to ensure quality Step 1: check whether the mould is in good condition. Step 2: the molten hot alloy is injected into the Mould Under suitable conditionsStep3: after the molten alloy is solidified,  the part in the mould is pushed out At the right timeMaterial: A380 Cavity Number: 1Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT4Surface Finish: PolishingFlow Processes: Die casting, Degating to remove the residual of the gate, Polishing and Deburring to remove the burrs, Polishing to remove the parting line, flash,  High Precision CNC Lathe Machining, Cleaning, Packaging, Storaging, ShippingControl Measure: Incoming Material

High Precision Machining Actuator Housing,   this part is an adjustable spring seat, which is used on the chassis system, the carried die casting criterion is Grade GB-CT5, this part is produced as cast.  In addition, the part required surface finish of electrophoresis coating, in order to improve the appearance condition of the part, making all the parts more consistent, we choose to develop corresponding trim mold for removing the injection gate, slag trap, overflow gate and flash around the parting line.  But this part maybe have the quality issue of Bad surface. Features: during the filling process due to temperature of liquid or alloy mold temperature is too low, in similar to the small spots under pressure under the condition of the casting surface formed like distribution area.Causes1. When filling, the metal is dispersed into concentrated droplets, and the wall is impacted at high speed.2. The gate thickness is too small. Exclusion measures 1, the correct design of gating system, to avoid metal liquid splash, improve exhaust conditions, to avoid liquid flow into excessive gas, reduce the gate speed and improve the mold temperature.2. Properly adjust the gate thickness. Material: A380Cavity Number: 2Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT4Surface Finish: Polishing, Vibratory DeburringFlow Processes: Die casting, Degating, Deburring to remove the flash around the eject

CNC Machining Valve Part in High Precision,  through the review to the geometry and the required dimensions and tolerances from the print, we will all find this part is not simple,  the carried die casting criterion for this part is Grade GB-CT4. The part is offered to us for a competitive price,   after our trial production for the samples and submit a few pieces of samples,  the customer will test with their specially designed facility, which can simulate the rotation in actual application on the car or the boat.  In die casting process.Mesh Burrs should be paid close attention to. Characteristic: the reticular protrusion marks and metal spines formed on the casting surface due to thermal fatigue on the mold cavity surface. Causes1, the mold cavity surface cracks caused by traces, the gate region near the heat conduction is the most concentrated, the friction resistance is the biggest, withstand the molten metal erosion is the strongest, hot and cold alternating most, the most likely to produce hot crack, forming crack.2, improper mold material or heat treatment process is not correct.3, mold temperature difference is large.4, alloy liquid pouring temperature is too high, mold preheating is not enough.5, the mold cavity surface roughness Ra is too big.6, excessive metal flow and positive erosion wall. Exclusion measures1. Correct selection of mould material and reasonable heat treatment process.2. The die must be preheated to the working temperature r

High precision Aluminum Casting of LED HousingShell this part use ADC-12 as material.For this part 1, if the drawings are not specified. The setting of the die casting process, such as the position of the ejector pin, the location of parting line, the location of the gate and the overflow port, shall be stipulated by the manufacturer itself; otherwise, the drawings shall be specified or agreed by both 2, die castings need special machined surfaces, such as polishing, shot peening, chrome plating, coating, anodizing, chemical oxidation, etc., must be marked on the drawings or agreed  3, If the die casting can meet its use requirements, the essential defects of the die castings are not the basis for scrapping.  the pressure sealing, hydraulic sealing, heat treatment, high temperature coating, internal defects (porosity, porosity, cold separation and inclusion) of the casting can be agreed. Lamp Accessories: LED Lamp HousingShell Die Casting Machine: 280 ton1 product per dieMaterial: ADC-12Product Dimensions:220mm*170mm*48mmCasting Precision: Grade GB-CT5Machining Accuracy Screw Thread: H6Technological Process: Die casting, Degate, Burring, Machining Center, Polish, Powder Painting, Cleaning, Packing, DeliveryControl Measure: First item inspection, Routing inspection, Final item inspection, Incoming test and Outgoing quality controlInspection Equipment: Calipers and Screw GaugeSurface Treatment: Powder coating(electrostatic powder spraying) Certific

Custom Aluminum High Quality HeatSink, this part use ADC-12 as material. In the process of Heatsink die casting, the correct adoption of die casting process parameters is the decisive factor for obtaining high quality die castings, while the die casting mould is the basis for the correct selection and adjustment of the relevant technological parameters. The casting shape and size precision, surface quality and internal requirements, casting operations smoothly etc., and mould design quality, manufacturing quality, specification, mold quality and maintenance quality has a direct relationship, so as to ensure the quality of die castings, first of all to monitor the quality of die casting mould The next step is Quality control of die casting alloyThe raw materials of should be provided with the quality assurance of chemical composition and mechanical properties, and the chemical composition should be re examinedDuring smelting, operators should follow the operating rules carefully Lamp Accessories: LED Heatsink HousingShell Die Casting Machine: 280 ton1 product per dieMaterial: ADC-12Product Dimensions:220mm*170mm*48mmCasting Precision: Grade GB-CT5Machining Accuracy Screw Thread: H6Technological Process: Die casting, Degate, Burring, Machining Center, Polish, Powder Painting, Cleaning, Packing, DeliveryControl Measure: First item inspection, Routing inspection, Final item inspection, Incoming test and Outgoing quality controlInspection Equipment: Calipers and S

Sales Well Aluminum LED Die Casting Heatsink,   this part use ADC-12 as material, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity. Our Heatsink has the following features 1, beautiful appearance, flexible size. It can be art modeling, also can be customized according to the special requirements of special rooms and users, show individuality; easy to match with the room, coordination, is the preferred product of home decoration.2, die-casting aluminum radiator overall strength, high working pressure, suitable for high-rise buildings3, modular combination, simple installation. The die casting criterion carried on this part is Grade GB-CT4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on CNC machining, especially the rough turning. Aluminum Die Casting Lamp Accessories: Aluminum Casting of LED Lighting Die Casting Machine: 200 ton 6 parts per dieMaterial: ADC-12Product Dimensions: Diameter 48mm*34.8mmCasting Precision: Grade GB-CT4Machining Precision: ±0.02mmTechnological Process: Die casting, Degate, Burring, Shot blasting, CNC Machining, Drill holes, Cleaning, Packing, DeliveryControl Measure: First item inspection, Routing inspection, Final item inspection, Incoming test and Outgoing quality controlInspection Equipment: CalipersSurface Treatment: Shot Blasting Certificate: ISOTS16949:2009Lead Time: 30-35

Zamak Die Casting Handle for Bathroom, It is a part applied to Chair, The part have very good monthly demand, which is around 60k pieces.The die casting chair base with variety of finishes to enhance your chairs' design. This part is made of many kinds of high quality materials through advanced equipment. According to the principle of ergonomics, the design is not only novel, but also comfortable and reliable. High quality aluminum material is melted and then molded into special mould. After cooling, sanding, dust removal, pickling, phosphating and other processes, high temperature electrostatic outdoor plastic powder spray treatment, It have corrosion resistance, anti-aging ability. After years of efforts and development, we have a certain scale and strength, now has a technical service team, with excellent service quality, professional and safe technical service strength, for different groups of users to provide higher quality products and services.  Material: Zinc Cavity Number: 1Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT5Surface Finish: Polishing, tumbling deburringFlow Processes: Die casting, Trimming, Deburring, Vibratory Finish, Machining, Cleaning, Packing, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equipment: CMM, Caliper, Plug GageApplication: Auto PartsCertificate: ISOTS1

Zinc alloy zamak die casting valve parts, it is a part applied to valve, the part have very good monthly demand, which is around 60k pieces.the die casting with variety of finishes to enhance your products' design. Our valves are of high quality and well suited to customer requirements valve is the control part in the fluid transportation system. It has the functions of closing, regulating, guiding, preventing reverse flow, stabilizing voltage, shunting or overflow and releasing pressure. Valves can be used to control air, water, steam, a variety of corrosive media, mud, oil, liquid metal and radioactive media and other types of fluid flow. After years of efforts and development, we have a certain scale and strength, now has a technical service team, with excellent service quality, professional and safe technical service strength, for different groups of users to provide higher quality products and services.  material: zinc cavity number: 1process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct5surface finish: polishing, tumbling deburringflow processes: die casting, trimming, deburring, vibratory finish, machining, cleaning, packing, shippingcontrol measure: incoming material test, first article inspection, routing inspection, final item inspection,  and outgoing quality controlinspection equipment: cmm, caliper, plug gageapplication: auto partscertificate: isots16949:2009lead time: 30-35 daystrade term: f

Aluminum Alloy Drive Arm Crank,  through the review to the geometry and the required dimensions and tolerances from the print, we will all find this part is simple,   the part is used as driven arm crank on the windscreen wiper, the carried die casting criterion for this part is Grade GB-CT4, in application, the part will rotate with the driven structure of the wiper, so the only key characteristic is to pay attention to the mechanical property as the part have to pass at least tens of thousands of rotation under required load.  The part is offered to us for a competitive price,   after our trial production for the samples and submit a few pieces of samples,  the customer will test with their specially designed facility, which can simulate the rotation in actual application on the car or the boat.  Our factory has specialized in high pressure die casting industry for more than 16 years, we have rich experience in the die casting work, usually we can provide a lot of recommendations based on the geometry of the current design during phase of development.  such as enlarge the radius at the corner or edge to prolong the tooling life, to hollow the part by only adding strengthen ribs, not only to save the material cost for the customer, but also to make the part more suitable for die casting work, what's more, the part has functional requirement on the mechanical property, with radius to the corner of the part, will make the part stronger

Aluminum Die Casting Pantograph Adapter,  the part is a small customized part, which is used on the wiper system.  The manufacturing technology for this part is high pressure die casting. We are an OEM die casting factory which specializes in high pressure die casting industry for more than 16 years, we have very rich experience in the precision casting work, usually we will provide a lot of recommendations based on the initial print and CAD data during phase of quotation, if we thought the part will have problem for die casting work, we will produce special powerpoint accordingly, then send to customer to discuss.   We also will put ourselves in the shoes of the customer to save cost, such as hollow the part by only adding strengthen ribs, not only for saving the material cost for the customer, but also to make the part more suitable for die casting process. The key characteristic for the quality control for this part is the steel insert, the material for this insert is 300 series stainless steel, knurl the outer surface, the insert will be overmolded while die casting.  Overmold is a process of setting the insert on the mold prior to the injection, then after die casting, the insert part will be included in the aluminum part. There is a dimension requirement, which says the steel part should be 0.25 mm higher than the surface of aluminum housing.  During our production, we ever found that, after die casting, the steel i

Aluminum Casting Wiper Mount Adapter is a small part which is used as Mount head on windscreen wiper system. The technology for this part is high pressure die casting. Our factory specializes in this industry for more than 16 years. The material for this part is ADC-12, a most common aluminum alloy in die casting industry. This material has very good performance on fluidity, also, this material have very good capability of processability.  It is always used for producing kinds of housing such as transmission system, motor housing, mounting bracket etc. The part has requirement of assembling a spring pin by punching. Punching work is very dangerous to hand operation, so as to avoid any personal injury during production, the engineer will make strict work instruction, especially the request on the machine, the machine can only work when the two buttons are pressed together by the two hands, in this case, the industrial injury can be avoided.  The part has requirement of powder coating treatment, so the density of the part is very important, unqualified part usually have a lot of void inside. So the mold design is very important, such as the layout of the location of the injection gate, runner, venting system etc. The technology of powder coating has process of curing in oven under about temperature of 200 degree, in this case, the porosity inside of the parts will expand to get out, leading to bubble on the part surface, such defect is unacceptable.

Section Aluminum Pivot Housing,  it is a part applied to windscreen wiper system, a housing for pivot shaft, the technology for this part is section extrusion, so it is not a die casting part, the material for this part is 6061 Aluminum, the technology decide that such section material have very good density, so the part made from this material don't have concern on the voids or internal porosity, which should be well noted in surface finish of E-coating.  6061 Aluminum has good property of processability, good performance on welding, and good adhesion for surface finish, the material itself has good anti-corrosion, what's more, the material has better effect of surface finish.   At last, this material can be heat treated. such as T6.  The purpose of heat treatment is to enhance the mechanical property of the part. For this part, there is minimum order qty request, as for section extrusion, the minimum order qty of the 6061 material should be 200 kg, for this part, the weight is only around 200 gram, so the MOQ should be 4000. Material: 6061 aluminumProcess Technology: section extrusionProduct Dimensions: CustomizedSurface Finish: Polishing, Electrophoresis CoatingFlow Processes: Extrusion, Cut off according to the size of the part with some machining allowance, High Precision CNC Lathe Machining, E-coating,  Cleaning, Packaging, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspecti

Aluminum Die Casting Assembled Mounting Head,  this part is a assembly part with a few components, it is used on the windscreen wiper system, the body of the part is produced by high pressure die casting, the carried die casting criterion for this part is Grade GB-CT4, the part is made up of 5 parts, a M8*1.25 nut, a half-height Jam nut, a spring pin, the aluminum mounting head, and the threaded M8*1.25 rod of 140 millimeter length.  Our factory is a die casting factory, the components to be assembled are all steel parts, most of them are standard parts, which just need to purchase from the vendor, we just need to make good control on incoming material inspection according to the prints specification.  Firstly, for the steel parts, the QC inspector should verify the nuts and the spring pin is non-magnetic stainless steel, then, verify the thread rod is stainless steel, by placing it into a glass cup, which is filled with 1 teaspoon of salt and 12 cup of warm water, then check after 24 hours if there is any red rust on the rod.  In addition, for the aluminum housing there is to be a 304 stainless bushing to be overmolded in die casting process. The bushing should be produced according to the detail from the print. On the print, there is surface finish specification that requiring black cathodic electrodeposition coating, for this technology, there is a process of curing in oven at temperature of 170-200 degree. so the density of the part is very impor

Aluminum Die Casting Body Side Hanger is a part applied to Suspension system, with the purpose of making the driving experience more stable, more comfortable, safer. The part is an auto part for famous motor corporation Chrysler-Fiat, so the development is careful, need a lot of tests and verification, so prior to mass production, the customer prefer developing a prototype die to run prototype samples for validating the reasonability of the design,  the feasibility in practical application and the mechanical property. In fact, for this part, it is the second prototype die, the first one it too thin to be strong enough during physical mechanical capacity test. What is prototype die?  Usually it is a kind of die which is much cheaper, in order to reduce some developing cost as possible as can. Usually a mold can run more than 50000+ shots, but for a prototype die, it is good to run hundreds or 1000-2000 shots, then the mold will become crack, it is because the material used for prototype die usually to be #45 steel.  For mass production die, the mold core is made of H13.  The raw material of this part is ADC12, carried with standard JIS H 5302-2000, this material has high content of Si element,  which means good fluidity, good liquidity means good performance on filling the cavity of the mold while die casting.  Material: ADC-12Cavity Number: 2Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolera

Aluminum die casting jack stand,  this part is used for elevating the camper trailer, such tool is very popular in western country, so the demand is large, monthly usage is around 25000 sets, the part consist of a jack housing, a threaded rod for support the camper, which is zinc plated. For such demand, the technology of high pressure die casting will be a good choice as high pressure die casting take very short time for a shot, e.g. This part will only take 30 seconds to run a shot. The process flow diagram for this part is simple, after die casting work, the operator just need to remove the gate vestige, the flash, the burrs, then do shot blasting, the shot blasting can not only make the part appearance more consistent and beautiful, but also can help release the stress inside of the part, improve the mechanical property to some extent.  in order to increase the production efficiency, the engineer design to bring in some automatic work to this part, such as ladle the molten aluminum automatically, fetch the material with robot, mold release agent auto-spray during die casting etc. These application can avoid operational error, making the manufacturing stable. The part had two mating parts, the threaded rod and nut.  the rod is used for loading the weight, the jack stand is required to bear 4.7 ton of weight. so for this part, there is requirement on the proof load test, the frequency is once per hour. For this part, the bottom is the location for t

Aluminum Die Casting Tractor Engine Cover,  the material for this part is A380, a kind of most common material, having good processability, for the physical property, this material have good thermal conductivity. It is commonly applied in home appliance, transmission housing, bracket of engine system etc. The die casting criterion carried on this part is Grade GB-CT4, according to the required tolerance and dimensions in terms of the prints, the part has difficulty on CNC machining, especially the rough turning, the section area of the injection gate is not small, but as the lot demand of this part is only 5000+, to develop a trim mold is uneconomic, which probably not be acceptable for the customer, then as the gate is located at the bottom surface which will require machining work to meet the dimension on the print, so in actual production, the engineer design in the control plan to have a rough turning to the bottom surface to remove the gate vestige, then fine turning on the high precision CNC lathe, then drilling and tapping the holes on the double-table machining center. The part is a functional part, don't have request on the surface finish, such as polishing, tumbling, etc.  High Pressure Die Casting is a technology that, inject the molten aluminum under high pressure, high speed into the cavity of the mold to solid to the part. So for this process, there usually to be turbulence flow, leading to air trapped in the part, so the porosity is unavoida

Aluminum Die Casting Bearing Housing ,  this part is a bearing housing applied on the tractor, the part geometry is reasonable, the thick wall is hollowed,   have very big cavity, so on the mold, there will be a big feature protrude from the surface, then while feeding the mold, as the injection gate is located at the bottom of the surface, so when the high-speed molten aluminum is injected, it will hit the big protruded feature, leading to eddy or turbulence, what's more, because of the big round feature, sometimes the molten aluminum will start to be solid at the back area of the feature though not fill sufficiently, leading to cold shut, or shrinkage porosity. Meanwhile, the top of the part will also be a position with high risk of feeding problem, as it is far-distance end on the part, the most difficult area for aluminum to reach. For such problem, the control method is to increase the temperature of the molten aluminum, to supervise the die temperature with infrared thermometer.   Then, during actual production, the operator should work under the process parameters set up by the engineering according to the operation instruction. Visual inspect the condition of the castings at the back surface, no defect such as cold shut is allowed.  The inspector also should attach importance to the color difference from the back area and front area.  For the top area of the part, the two bosses are required to be tapped, so the CNC workshop

Auto gearbox cnc parts,   it is an auto part, which is applied to auto gearbox system, it is the housing of the automotive gearbox. With large sizes and complex structure.  the die casting process includes the following steps: step 1:  preparation before die casting, including raw material inspection, storage, protection, melting, and aluminum water delivery. Step two:  die casting process, which is the first in the die surface coated with a layer of release agent. And then inserted into the core, then mold after starting injection; after the injection to be completed. And the completion of die casting. Out of core,  take the auto gearbox unmachined parts out, and the ejecting device will live out of the top block. Step three: die casting treatment, including parts gate, parts transport, parts cleaning, parts shot blasting, primary wide product transportation, primary wide product processing, final product inspection, finished product packaging and storage. The die casting process of the automobile gearbox parts has the advantages of replacing the existing black sand casting process by adopting the die-casting process. Material: adc-12cavity number: 2process technology: high pressure die casting, cold chamberproduct dimensions: customizedcasting general tolerance: grade gb-ct4surface finish: polishing, shot blastingflow processes: die casting, degating, deburring to remove the flash around the ejector pins, polishing to remove the parting line, shot pe

Auto Precision CNC Pump parts.   the material of this part is ADC-12, the part is a housing for Pump system which is used on car. About Auto CNC Pump part .It is the irregular and complex  . During the production. not only pay attention to the products' quality. Also should pay attention to staff training in the production process, they should following below steps Step 1: fixing two side platen of fixed mould, then install two sides of the moving die platen. Step 2: When the mold is in place, whether the Mold is locked or not, by adjusting the movement of the mold, the machine can adjust the mould properly so as to achieve the appropriate clamping force Step 3: Attention must be paid to the core pulling before die clamping Material: ADC-12Cavity Number: 1Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT4Surface Finish: Polishing, Nyloy polishing the second timeFlow Processes: Die casting, Degate, De-slag, Deburr to remove the flash around the ejector pins, Polishing to remove the parting line, Nyloy polish to make the part have more beautiful appearance, High Precision CNC Lathe Machining in two times, E-coating,  Cleaning, Packaging, Inland Shipping to the port as the trad term is FOB NINGBOControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equipment: CMM, Caliper

Aluminum Motorcycle Lamp Housing This part consist of three parts, a bracket, an end cover and a body housing. This part is used on the motorcycle, as it is applied to outdoor sport, so the UV-proof property is very important, in the surface specification requirement,  the powder is appointed to be Tiger brand, a global famous powder company. The technology of manufacturing this part is aluminum alloy high pressure die casting. the type of the aluminum material for this part is ADC-12, a most common aluminum alloy in die casting industry, which has very good performance on fluidity, also, this material have very good capability of processability.  It is common to be used to produce housing part. The difficulty of this part is the surface treatment, in order to improve the performance on the ultraviolet resistance, the tiger powder is brought in, then, under the sun for long time, the powder is possible to happen to peel off from the part surface, so we try to improve the adhesion force between the powder and the aluminum housing, by vibratory deburring the housing prior to machining work. What's more, on the print, some areas are required to have no powder, such as the internal cavity, because the part is lamp housing, while working, it will generate plenty of heat, so for the reason of thermal dissipation, it is not allowed to have powder.  What's more, both the housing and end cover have fit thread, the density of the part is important to contr

High precision CNC Maching Mill End Housing ,   this part is used as engine housing on the Agriculture facility, About this part. we should focus on following some quality problems. Problem 1:Appearance cold shut.  if two alunimum alloy liquid flow together, they are not completely fused. The bonding force of alunimum alloy will be very weak, if the pouring temperature and mould temperature are low. should increase the temperature of pouring and mould.   The flowability of alunimum alloy is poor, the runner location is not correct, the flow path is too long, and the filling speed is too low. The injection pressure should be increased, the rapid injection and pressurization should be increased, and the filling time should be shortened Problem 2: Burrs The reason is following: The mould clamping force is not enough, the injection speed is too high, the pressure shock peak is too high, so it is necessary to adjust the appropriate die casting process. The sundries on the parting surface are not cleaned up, and the strength of the mould is not good, resulting in mold parting surface deformation Material: A380Cavity Number: 1Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT4Surface Finish: PolishingFlow Processes: Die casting, Degating to remove the residual of the gate, Polishing and Deburring to remove the burrs, Polishing to remove the parting line, flash,  High Precision CNC

High Precision Aluminum CNC Die Casting Machining parts it is an customized part applied to Machining parts, In the die casting process. Normally, the die clamping force must be greater than the calculated bulging force. Otherwise, when the metal hydraulic injection, the mold parting surface will be expanded, resulting in metal splash, and the pressure in the cavity can not be established, resulting in casting size tolerance is difficult to guarantee, and even difficult to shape. Meanwhile, in order to ensure the smooth mold release, the part will need more mold release agent, so in the control plan, the engineer request to apply to automatic agent spray. When die casting, the temperature of the molten metal should be in control. By the way, as this project is wonderful, so we are much more careful during the development of the tooling, prior to the built of the die, we run mold flow analysis to simulate the situation in die casting, to decrease the risk in actual production. Material: ADC12Cavity Number: 1Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolerance: GBT6414-CT6Surface Finish: PolishingFlow Processes: Die casting, Trimming, Deburring, Drilling and tapping, Cleaning, Packing, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equipment: CMM, Caliper, Plug GageApplication: Home MotorCertificate: ISOTS1694

High Precision CNC Machining Pivot Housing,  this part is used for Machine, such tool is very popular in western country, the part consist of a jack housing, a threaded rod for support the camper, For such demand, the technology of High Pressure Die Casting will be a good choice as high pressure die casting take very short time for a shot, e.g. this part will only take 30 seconds to run a shot. In die casting process. should follow up Metal parts appearance inspection standard. 1, An acceptable defect shall not affect the assembly and function of the part, otherwise it will be rejected. 2,  Defect tolerance defines the maximum allowable number of defects in the region of 900mm2. However, two or more than two distinct defects can not be connected. Defect definition are following: A: rust oxidation: chemical reactions occurring on the surface of metals exposed to air, including yellowing and other anomalies. B: discoloration: background or expected color changes, or parts of the surface color is inconsistent.  C: scratch: shallow trench in parts of the surface, including open at the end. D: indentation: a groove mark on the surface of a part made of a sharp object. The nail can feel it.  E: plating mark flow mark: because of uneven thickness of the coating, the surface of the parts on the surface of corrugated or strip abnormal area F: trace: small pits, bending marks or other marks of matrix materials, but still can not be eliminated after coat

High Precision CNC Machining Differential Housing  It is a part applied to suspension system, with the purpose to improve the stability, the comfort, the safety of driving. The part is auto part for famous motor corporation. The part have very good monthly demand, which is around 50k pieces. The products should pay attention to the Strength If the mechanical strength and elongation of casting alloy are lower than the required standard.the reason is following:1. The chemical composition of the alloy does not conform to the standard.2, there are pores, shrinkage holes, slag inclusion in the casting.3, the sample treatment method is not equal.4, the casting structure is unreasonable, limiting the casting to meet the standard.5. Improper smelting process. Exclusion measures 1. The chemical composition and impurity content should be strictly controlled in the melting process.2, strictly abide by the smelting process.3, according to the requirements of the sample, in the production of regular casting process test.4, strictly control the alloy smelting temperature and pouring temperature, as far as possible to eliminate various factors of alloy oxide formation. The material of this part is ADC12, a kind of material conforming to standard JIS H 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  Material: ADC-12 Cavity Number: 1Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General

High Precision CNC Machining Pressure ,  it is an customized part applied to motor homes, the technology for this part is high pressure die casting, the difficulty for this part is the wall thickness, it is very small, and the allowed draft angle is very small, so, it is easy to have the issue of Bruise. Features: casting surface due to strike against the wounds.Causes1, to the gate, cleaning, correction and handling in the process of careless bumps. Exclusion measures 1, careful cleaning of casting, storage and transportation of castings, should not be stacked or strike against each other, using a special store transport box. This part has very large demand, the daily demand is up to 1000+pcs, so in order to ensure the production efficiency and better control on the quality which may have risk by manual work, we developed trim mold, purchase the trim machine for trimming.  Material: zamark 3Cavity Number: 1Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolerance: GBT6414-CT6Surface Finish: PolishingFlow Processes: Die casting, Trimming, Deburring, Drilling and tapping, Cleaning, Packing, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equipment: CMM, Caliper, Plug GageApplication: Home MotorCertificate: ISOTS16949:2009Lead Time: 30-35 daysTrade Term: FOB Ningbo

High Precision CNC Machining Bearing Housing,  it is a part used on bearing system, the manufacturing technology is High Pressure Die Casting, a kind of cold chamber aluminum die casting, the material for this part is ADC-12, the corresponding standard is GBT 15115-2009. Based on ASTM B85-03 Standard Specification for Aluminum-Alloy, the alternative material is A383. Aluminum Die Casting, During the project developing, the engineer in charge of the samples development will follow on the progress according to the schedule, if any problem found during the flow processes, the engineer will make improvement record and make record, then produce relative documents accordingly, such as the temperature of melting aluminum, the mold in production, the part after die casting etc.  and the slow shot speed, the fast shot speed. the timing of slow shot, fast shot, keep the mold closed etc, of course also the pressure during these areas. About MarkFeatures: casting surface due to the mold cavity insert, knock and push rod, movable block parts  Causes1. Uneven adjustment or end wear of push rod.2, the mold cavity, slider splicing part and its active parts with poor coordination.3, the push rod area is too small. Exclusion measures 1. Adjust the push rod to the correct position.2. Fastening the insert or other movable parts to eliminate the undue concave and convex parts.3, increase the area of the push rod or increase the number. Material: ADC-12 Cavity Number: 1Pr

Customized Base Machined Parts CNC Machining ,   the material for this part is ADC-12, a kind of material, having good fluidity, which is good for filling while die casting. This material is a good material to produce end cover, housing, gearbox, bracket etc.  For this part, should pay attention to the loose. Feature: loose and non tight macrostructure on the surface of casting. Causes1, mold temperature is too low.2. The casting temperature is too low.3, small specific pressure.4, too much paint. Exclusion measures 1, to improve the mold temperature to the working temperature.2. Appropriately increase the pouring temperature of alloy.3, increase the specific pressure.4, the coating is thin and uniform. Die Casting is a technology that, press the melting aluminum under high pressure, high speed, usually the shot procedure will be finished in a few seconds. In this case, there probably be air trapped because of turbulence, eddy, so the porosity is unavoidable, but can be decreased or improved. Usually, in die casting factory, visual porosity on machining surface is not allowed, so the solution is to simulate or validate sufficiently by mold flow analysis prior to the building of the tooling, to ensure the density of the casting, by locating the major injection gate, cross gate, runner, the venting system reasonably.  Then, for the machining work of this part, it is a part of high precision machining tolerance,  the tolerance is around ±0

High Accuracy CNC Machining Shaft Sleeve,   About the surface finish of e-coating, for this part, as the flat surface is thin, easy to deform if tumbling, so choose to polish to remove the residual of the gate, the overflow, then use nylon wheel to polish again to enhance the appearance effect.  Colored spot should be paid close attention to for this part Feature: the spot on the surface of casting is different from that of base metal, which is usually formed by coating carbide. Causes1, paint impure or excessive dosage.2. Excessive graphite in coating. Exclusion measures1, the use of paint should be thin and uniform, can not be piled up, compressed air blowing.2, reduce the graphite content in the coating or choose the graphite free water-based coating. Material: ADC-12 Cavity Number: 1Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT3Surface Finish: Polishing, Nyloy polishing the second timeFlow Processes: Die casting, Degate, De-slag, Deburr to remove the flash around the ejector pins, Polishing to remove the parting line, Nyloy polish to make the part have more beautiful appearance, High Precision CNC Lathe Machining in two times, E-coating,  Cleaning, Packaging, Inland Shipping to the port as the trad term is FOB NINGBOControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equi

The aluminum die casting wiper mounting head is a small part which is used for mounting the mating parts of wiper, this part have deep cavity, but the allowed draft angle is only 1.5 degree, what's more, the internal cavity has a lot of sharp teeth for locking the mating shaft part, in this situation, the part is easier to stick to the mold during production, so the mold has to set point cooling, and while die casting, the mold release agent should be sprayed enough at the specified areas to ensure the smooth release, otherwise, the teeth will be easily broken, leading to the scrap.  in the inspection instruction, should specify the first article inspection, the routine inspection frequency etc.   in addition, the part will require powder coating, prior to this finish, the part will have tumbling as pre-treatment to enhance the adhesion property. the material of this part is adc-12, a most common aluminum alloy in life. This material has nice property of fluidity, meanwhile, this material have very good processability. Always used for producing transmission housing, motor housing, mounting bracket etc. Material: adc-12cavity number: 4process technology: high pressure die castingproduct dimensions: customizedcasting general tolerance: grade gb-ct4surface finish: polishing, shot peeningflow processes: die casting, trimming, deburring, shot blasting, machining, cleaning, packing, shippingcontrol measure: incoming material test, first article inspection

The Aluminum Die Casting Wiper Mounting Head is a small part which is used as Mount head on windscreen wiper of bus, boat and car. The technology for this part is high pressure cold chamber die casting, the mold design is very important, like the location of the injection gate, runner, venting system etc. Incorrect design will lead to turbulence while injecting, the result is internal porosity.  The part has requirement of powder coating treatment, so the density of the part is very important, unqualified part usually have a lot of void inside. Technology of powder coating has process of curing in oven in about temperature of 200 degree, in this case, the porosities inside of the parts will expand to get out, leading to bubble on the part surface, such defect is unacceptable.  What's more, for the design of the mold, should attach attention to the parting lines, considering the convenience for operation of deburring, polishing.  The part has high requirement on corrosion prevention, so used the powder of brand of Akzo Nobel. For powder coating, the engineer produced instruction of material flow, in order to ensure no scratch, no damage to the film of powder coating, leading to rejected parts. The material of this part is ADC-12, a most common aluminum alloy in life. This material has nice property of fluidity, meanwhile, this material have very good processability. Always used for producing transmission housing, motor housing, mounting bracket etc. Material: A

The Aluminum Windscreen Wiper Mount Head is a small part which is used as Mount head of  windscreen wiper system on bus, boat and car etc. The technology for this part is high pressure aluminum die casting, the mold design is very important, according to our ISOTS:16949 Certificate,  prior to the mold fabrication, the design such as the location of the injection gate, runner, venting system, cooling system should be approved by the customer production engineering. For us experienced die casting manufacturer, we usually apply to solidification analysis to decide the best design for customized products.  The part is small, but have a big pocket feature, the part is easier to stick to the mold, then if ignored, the material on the mold will lead to more serious sticking and incomplete filling,  in this case, the engineer produced the work instruction with this point as key characteristic, adequate spray of mold release agent, specified cooling point at this deep cavity structure etc.  The part has requirement on assembly of M6*1 set screw, and the set screw has nylon patch on thread, which is very good for locking of the set screw on the aluminum mounting head housing. With such nylon material thread locker, the set screw can be turned off and re-assembled for a couple of times. The part has finish specification on the powder coating treatment, the required powder is CARDINAL BK-08, the thickness is to be 0.05 mm to reach the enough corrosion s

The die casting aluminum mounting head,  the part is small, but similar to the other mounting head parts, it has a deep cavity, which is easier to make the part sticky to the mold, then during production, if the material sticked on the mold is not cleaned,  it will damage the castings newly produced, so in the engineering operation instruction edit by the engineer, the cavity is a key characteristic, while die casting,  proper spray of mold releasing agent, specified cooling point at this deep cavity structure is necessary.  thus,  the mold design is significant, before the mold establishment, we always require the tooling company to provide the cad data of the mold design, and run the mold flow analysis to simulate the die casting of the part, to look into if the design is reasonable or not. Meanwhile, we also will provide the design cad to the customer to confirm with them if everything is okay, so as to avoid any interference problem with the practical application to the customer. The part is machined from another part, the difference is to machining the cavity area into tapered smooth hole. So the density of the cavity is very important, or after machining, there will be porosity exposed on the machining surface, which is unacceptable. It is also relative to the filling of the melting aluminum in the mold, not only because the requirement of powder coating as surface finish. The material of the part is adc-12, a japanese aluminum type.

Aluminum Die Casting Pivot Housing,  our factory have a couple of 280T die casting machines,  the size and the weight of this part is very suitable for the machines. This part is a pivot housing for DC motor on wiper system, the difficulty of this part is the structure of the long threaded pillar, the length is more than 65 mm, as the base of the pivot housing is big and thick, so the injection gate should be located on the base, then it means the top of the pillar will be the end on the mold, which will cause problem of incomplete filling, even defect of short casting. What's more, the part require surface finish of electrophoresis coating, for technology of e-coating, also a process of curing at high temperature of 170-200 degree. In this case, such issues of misrun, inadequate filling will cause internal porosity, then under this high thermal heating, the air will get out from the parts, leading to pits and bubbles on the surface of the castings. so to avoid this problem the long pillar is set to be the key characteristic, the mold design with mold flow analysis is very important and necessary prior to the establishment of mold. Of course, to ensure the design of the ejector pins, the parting line, the pouring gate won't cause any interference problem on practical application of the part,  we will provide the design CAD to the customer to ask for an approval. The material of the part is ADC-12, a Japanese aluminum type. The material s

Aluminum Die Casting Shaft Housing,  This part is a pivot housing for assembling the shaft, which is used on DC motor on wiper system, the part is very similar to pivot housing 421-1034,  the difficulty of this part is the feature of the long threaded pillar, it is even longer than 421-1034,  the length is up to 115 mm, the injection gate can still only be set at the base of the product, so the die casting work of this part is more difficult than that one as this part also require machining the pillar to have thread and surface specification of electrophresis coating. without good design on the injection system, the runner flow system, the venting system, the part will be easy to have problem of incomplete filling, defect like shrinkage porosity, short casting etc. Then lead to the exposed porosity on the surface after machining, and pits or bubbles on the whole pillar surface as e-coating What's more, the part require surface finish of electrophoresis coating, for technology of e-coating technology has a process of curing at high temperature of 170-200 degree like powder coating. In this situation, to run a mold flow analysis on the CAD model of tooling designed prior to the built of mold is necessary and important. Of course, after the design is completed, before the mold flow simulation, we should submitt the CAD model to the customer for confirmation firstly, as we may be not clear how the part is used, whether the design will.

Double Shaft Pivot Housing,  the part is also a kind of pivot housing on windscreen wiper system, which is applied to bigger buses, boat etc. The part is similar to the pivot housing 421-1034 but have two long pins, this pivot side housing have two long threaded pillars, from these two pillars, there to be two shaft assembled. The difficulty of this part is that the structure of the two long threaded pillars, the length is about 65 mm, the key point is to locate the injection gate the runner, the overflow, the cooling system in proper position. Usually, for experienced die casting manufacturer, we will run with solidification analysis to simulate the status of the filling of the melting aluminum, making the final decision on these points. Otherwise, probably the part will have risk of porosity, if so, while machining, there will be big porosity exposed from the thread surfaces, what's worse, while e-coating, during the curing process under 170-200 degree, the porosity will try to expand to get out, leading to pits and bubbles on the part surface, which is serious appearance defects unacceptable. Prior to the finish of e-coating, this part can have tumbling treatment, this part has a big and stable bottom feature, so tumbling won't cause problem of deformation like 429-1040.  Tumbling is a surface finish which usually used for removing the small flashes, chamfering, even minor scratch mark, crash etc. making the parts consistent

Threaded Pivot Housing of Aluminum,  the part is also a kind of pivot housing on windscreen wiper system, which is applied to bigger buses, boat etc. The part looks almost the same to the part number 421-1040 except the length of the two threaded pillar. It is almost 50 mm longer than pivot 421-1040. The most important point to ensure the quality control for this part is the two long pillars, which is decided by the mold design of the location for pouring gate, slag strap, overflow, runner etc. Correct layout of these locations on the mold is the basis to make the part dense enough. Our factory specialize in die casting for more than 15 years, we well understand that the mold flow analysis is important to learn if the part can filling well or not prior to the built of the tooling. This part is big, to ensure the density, the choice for the die casting machine tonnage is 400T. For this part, the pillars is for assembling the shafts from the bore holes. so on both top step holes and bottom step holes, there is one needle bearing each to be pressed in. The needle bearings are a kind of part usually not customized but carried with common criterion.  For the surface specification, the part will have polishing to areas which is hard to be touched by the stones in tumbling, then the e-coating, it is outsourced, the thickness of the e-coating film is only about 0.02 mm.  At last, according to the print, the required material is ADC-12.

Aluminum Die Casting Housing of Motor Side,  the part is a housing for DC motor on windscreen wiper system which is applied to bus, boat in daily life, the part is a cover, the mating part is the pivot housing 429-1040, in this part, there is a feature of rail, which is used for the slide of a mating plastic part, so there is parallelism requirement on the rail, or there will be interference problem when the plastic part move. What's more, the clearance of the rail is small, it means the structure on the mold will be very small, then under condition of 1.5 degree draft and Radius 0.5 mm, there easily to be problem of stress accumulation at the top of the structure on the mold, then happen to be crack, leading to the excess material at the bottom of the rail, cause problem of sliding of the plastic part. and that it is infeasible to add machining work to this rail as it is too small, the machining cost will be very high.  So the solution is to maintain the mold regularly, add nitrogen treatment to the mold timely, and release the stress regularly, all these actions can prolong the tooling life.  The part has request on surface finish of E-Coating to satisfy the daily application, so the density of the part is important item to control, in engineering's work instruction, the operator should fracture the part and look into the section of the fracture to see if the particles is good and dense prior to production, ensure there is no big single porosity

Aluminum Die Casting Arm Channel,  the part is a bracket for passing and fixing the wire of the windscreen wiper, the standard carried for the die casting work of this part is GBT6414-CT4, this part has a lot of hollow-out structure, which need not only one slide to form. This part has a cylinder structure of φ15.7 mm, at the top of this structure,  which is the far end on the injection system, so this structure is easier to have internal porosity because of misrun, what's more, the part request e-coating surface specification, if the part has void or porosity inside, the E-Coating technology have high temperature curing process after water cleaning, because of the thermal expansion the inside air in the casting will expand to the part surface, in the procedure, the air will lead to pinholes or pits which is unacceptable according to cosmetic criterion. So for the die casting process of this part, the engineer consider increasing the pressure during slow shot(it is for filling the casting well). Meanwhile, the inspector and the operator should pay attention to the first article on the density on the section surface, especially the cylinder structure mentioned before. The inspector can use magnifying lens to observe.  After de-gating, the workshop will proceed polishing to remove the parting line, the residual of the injection gate and the overflow gate. As there are too many hollow-out structures, vibratory deburring is not suitable as the stone

Aluminum Die Casting Drive Arm Crank,  this part is used as driven arm crank on the windscreen wiper, the carried die casting criterion for this part is Grade GB-CT4, in application, the part will rotate with the driven structure of the wiper, so the mechanical property should at least satisfy tens of thousands of rotation under required load. When the customer receive the initial samples, they test with specified facility, simulating the rotation in actual application. As an experienced die casting manufacturer in die casting industry more than 16 years, we provided a couple of recommendations during phase of development.  such as enlarge the radius at the corner or edge as far as possible, it is because sharper corner, the more stress accumulated at the sharp area, not only the part will be easier to broken(cannot satisfy the mechanical performance request), but also the structure to form the sharp corner will have issue of stress accumulation, leading to the short tooling life, and that it is also not good for maintenance of the molds. What's more, the part require surface finish of electrophoresis coating, for this technology, there is a process of curing at high temperature of 170-200 degree. so for the die casting work of this part, the QC should pay attention to fracturing the part to look into the section to see if the density is good or not, whether there is mass of small porosity inside of the part, whether the particle of the section looks good etc. or be

Aluminum Die Casting Mounting Bracket,  this part carried die casting standard of Grade GB-CT4, the part has small wall thickness, meanwhile, the part have structure of big cavity, which usually easily cause problem of mold sticking, pull mark etc. The small wall thickness means the part probably happen to deform during production, which will cause actual application issue. What's more, the part surface area is big, but the thickness is small, in this situation, the far end from the location of injection, the melting aluminum will have risk of solid earlier than expected, it will cause short casting at the far end of the part, then while the part is cooled to indoor temperature, the part will have shrinkage porosity inside.  The part has requirement of surface finish of E-Coating, which has process of curing in hot thermal oven, the temperature usually be up to 170-200 degree, the porosity mentioned above will expand and get out from the part, result in pits and bubbles on the coating.  So in the inspection work instruction, there is request that the  QC inspector should fracture the part with hammer, then check the section particle with magnifying lens to see if there is problem of porosity on the section. The inspector also will make a record of the part weight, and control through weighing the part. All these action is to avoid batches rejected while e-coating.  The part is strong enough to proceed tumbling pre-treatment.

Aluminum Die Casting Mount Bracket of Swing Arm,  it is a part used on wiper system, the manufacturing technology is High Pressure Die Casting, a kind of cold chamber aluminum die casting, the material for this part is ADC-12,  a Japanese standard aluminum. this material is supposed to conform to standard of JIS H 5302-2000, it is a very common material in high pressure die casting industry. The equivalent material is of Chinese standard aluminum alloy is YL113, the corresponding standard is GBT 15115-2009. Based on ASTM B85-03 Standard Specification for Aluminum-Alloy, the alternative material is A383. Aluminum Die Casting, is a kind of precision casting. For this technology, to control the process parameters is very important, produce in terms of strict parameters set by the engineering dept. the part will have controllable on the quality and the consistency.  During the project developing, the engineer in charge of the samples development will follow on the progress according to the schedule, if any problem found during the flow processes, the engineer will make improvement record and make record, then produce relative documents accordingly, such as the temperature of melting aluminum, the mold in production, the part after die casting etc.  and the slow shot speed, the fast shot speed. the timing of slow shot, fast shot, keep the mold closed etc, of course also the pressure during these areas. Material: ADC-12Cavity Number: 1Process Technolog.

The Aluminum Die Casting Base Housing,  it is an customized auto part, it is produced by high pressure die casting process, the part is required to be as cast, so during the part development, the engineer should review the drawings very carefully to look into if all the required dimensions and tolerance are within our capability, The part is not difficult to produce, the wall thickness is uniform and continuous. The only thing out of the initial expectation is that the small flash around the ejector pins. As the tooling design, including the injection gate, cross injection gate, the runner, the venting system locations are all confirmed and approved by the customer, we didn't expect that the small flash will cause application issue.  The part has a big pocket structure, at the beginning, consider to ensure the easier mold release, the better location for the ejector pins obviously  should be at the bottom of the pocket feature.  But in application, we are told by the customer the ejector pins are supposed to have not any flash around as it will cause interference to the mating part assembly.  However, as the ejector pins are inside of the cavity, it is not possible to settle by trim mold, also hard to remove by manual work through pneumatic file. So at last, through technical discussion between the engineers of the tooling vendor and our company, they propose the idea of moving the location, changing from the bottom surface to the wall edge.

The Aluminum Die Casting Backbone ,  it is an customized auto part, it is produced by high pressure die casting process, the part is small, the part weight is only about 35 gram, but the length of the part is about 15 cm. what's more, on one end, the part has a feature of cavity, leading to the only option to be realized by secondary slide. in this case, the injection gate can only be on the other end in terms of the geometry. Because the length of the part is long, the part will have potential failure on casting defect, such as internal porosity, chilled layer on the part surface, cold shut, cold flow, and loose grain structure etc. The part has requirement of minimum tensile strength of 300 N*m.  According to the structure of the part, based on your assessment, the part may have potential failure possibility of fracture at the thickest area. It is because the part is long, in order to have an adequate filling, the pressure to inject the melting aluminum into the mold cavity should be very large so that the material won't solid prior to fully fill the cavity. But as the injection gate section area is not big enough, we make modification or adjustment to the gate to ensure the filling reach well. The part is small,  the projection area also is small, theoretically, the tonnage of 200 t is supposed to satisfy the shot of the die casting. By our PQ chart analysis, we learned that the section area of the injection gate should be larger, almost the whole

Aluminum Die Casting Heat Return Bracket,  it is an auto part, it is produced from High Pressure Die Casting technology, the implemented die casting standard is Grade GB-CT4, according to the print, there are a few thread holes on the part, without blind hole, after machining, porosity will be easily exposed to the air, even worse, if the size of the porosity is too big, the thread will happen to be broken after machining, leading to failure of actual assembly. So while developing the mold, we will carefully consider the setup of the location of the injection gate, runner, and venting system etc.  Meanwhile, the engineer always follow on the whole flow processes to determine the die casting process parameters, such as proper press, shot speed etc. to ensure the sufficient filling rate, in this case, to decrease porosity and relief problem of die casting defects. During the developing, the engineer will gather all the information and produce the work instructions accordingly. After die casting, remove the injection gate and deburring, then outsourced for shot peening in method of hanging to make the part beautiful and consistent, meanwhile not deform. Then, flow to next step- High Precision CNC machining, the two φ6.8 mm through hole and M8 thread hole have relative positioning relation, so prior to machining, while debugging, after OP10, the inspector should confirm if the first article is qualified, in this work, the operator and the inspector should make.

Aluminum Die Casting Adjustable Spring Seat,  this part is an adjustable spring seat, which is applied on the chassis system, the carried die casting criterion is Grade GB-CT5, this part require to realize all the dimensions as cast. The part has a feature of cam, requesting to satisfy specified developing curve, so it is very important to make investigation at the initial phase of development after being offered.   In addition, the part required surface finish of electrophoresis coating, in order to improve the appearance condition of the part, making all the parts more consistent, we choose to develop corresponding trim mold for removing the injection gate, slag trap, overflow gate and flash around the parting line.  As there is request of e-coating, so the critical point is to control the part density, without good density, i.e. the part probably has porosity or void problem internal. For technology of e-coating, there is a process of curing the film in oven under about 170-200 degree. Because of thermal expansion, the air inside the part will expand to expose to the outer surface, leading to pits, bubbles, pin holes, which are all not acceptable in e-coating industry. So when the engineer find the proper process parameters during the part development, the parameters will be listed in the die casting work operation, then the parameters should be strictly observed by the operator according to the instruction. For this part, the draft permissiblty.

Aluminum Die Casting Adjustable Spring Seat,  this part is an adjustable spring seat, which is used on the chassis system, the carried die casting criterion is Grade GB-CT5, this part is produced as cast. And it has a feature of cam, requesting to meet specified developing curve, so when offered for this project, we spend much time to make investigation at the beginning, with the purpose of EDM the material of the mold correctly.   In addition, the part required surface finish of electrophoresis coating, in order to improve the appearance condition of the part, making all the parts more consistent, we choose to develop corresponding trim mold for removing the injection gate, slag trap, overflow gate and flash around the parting line.  As there is request of e-coating, so to control the density of the part is very important, if not dense, the part probably has porosity or void inside. For technology of e-coating, there is a process of curing the film in oven under about 170-200 degree. Because of thermal expansion, the air inside the part will expand to expose to the outer surface, leading to pits, bubbles, pin holes, which are all not acceptable in e-coating industry.  For this part, the permissible draft is only 1 degree, meanwhile, the internal cavity of the part is deep, which will cause problem of thermal stress accumulation easily, leading to hot tear, you know, the film thickness of e-coating is only 0.015-0.02 mm.

Aluminum Die Casting Adjustable Spring Seat,  this part is also an automotive adjustable spring seat, which has a mating spring seat part 130600379, the part is setup with die casting criterion of Grade GB-CT5, this part is request to produce as cast as the required tolerance and dimensions are all easy to reach. The part also has a corresponding feature of cam, similar to the mating part, which request on specified developing curve, so with the purpose of EDM the material of the mold correctly,  while being offered with this project, we spend a few days to make out the data by scanning from ZEISS CMM.  In addition, the part required surface finish of electrophoresis coating, in order to improve the appearance condition of the part, making all the parts more consistent, we choose to develop corresponding trim mold for removing the injection gate, slag trap, overflow gate and flash around the parting line.  As there is request of e-coating, by this technology, there is a process of curing the film in oven under about 170-200 degree. In this case, as for thermal expansion, the air trapped in the part will expand to expose to the outer surface, leading to pits, bubbles, pin holes, which are all not acceptable in e-coating industry.  so during developing of tooling, at the beginning, we will run mold flow analysis to simulate the molten metal filling. With this work, we can produce parts with very good grain structure inside the part, as long as

Zinc Alloy Awning Mount of Motor Side,  it is an customized part applied to motor homes, the technology for this part is high pressure die casting, the accuracy of specified dimensions and tolerance on the print is not high, the carried criterion for die casting is GBT6414-CT7, the average wall thickness of this part is 2-3mm, it is small, but as the material is zinc alloy, it is feasible for die casting process. However, the main feature of the part is the deep, big cavity, what's more, usually the allowed draft for zinc die casting will be small, in this case, the enclosed strength to the moving die generated will be very large, leading to potential risk of mold release. In order to get the parts out successful, the qty and the location of the ejector pins should be distributed very well, Meanwhile, in order to make the parts out from the mold successful, there should be enough release agent sprayed to the mold.  In die casting process, the operator should supervise the temperature of the molten metal, the higher temperature, the die temperature also will increase, then result in generating a lot of water from the mold release agent, the technology of this part is high pressure, high speed the air from the water rush into the part, then trapped. As the wall thickness is small, so such porosity will easily exposed to the outer surface.  At last, the engineer also look into the composition of the mold release agent, so the option for the mold release agent

 Customized Zinc Alloy Die Casting for Lock Set, It is a part applied to Door, The part have very good monthly demand, which is around 50k pieces. The characteristics of various metal die casting are as follows: Zinc is Good Metal for die casting, making small parts is very economical, suitable for precision die casting products, easy coating, it has high compressive strength, high plasticity, long casting life.Aluminum has the advantages of light weight, complex manufacturing and thin wall castings, high stability, strong corrosion resistance, good mechanical properties, high thermal conductivity and electrical conductivity, and high strength at high temperature. The Zinc material  is  a kind of material conforming to standard JIS H 5302-2000, this material has good fluidity, which is good for filling the mold while die casting.  Material: Zinc Cavity Number: 1Process Technology: High pressure die castingProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT5Surface Finish: Polishing, tumbling deburringFlow Processes: Die casting, Trimming, Deburring, Vibratory Finish, Machining, Cleaning, Packing, ShippingControl Measure: Incoming Material Test, First Article inspection, Routing inspection, Final item inspection,  and Outgoing quality controlInspection Equipment: CMM, Caliper, Plug GageApplication: Auto PartsCertificate: ISOTS16949:2009Lead Time: 30-35 daysTrade Term: FOB

CNC Machining Auto Bracket of High Precision,  it is an auto part, which is applied to transmission system, it the housing of the automotive gearbox. The estimated annual usage is 250k pieces.  About The part, shoud pay attention to the foreign Matter Features:alloy element does not meet the requirements or impurities too much. Causes1, incorrect ingredients.2, raw materials and scrap without analysis shall not be put into use.Exclusion measures1, the Furnace burden should be chemically analyzed before it can be used.2, the burden should be strictly managed, the old and new materials should be allocated in a certain proportion.3, strictly abide by the smelting process.4, the melting tool should brush paint. There is high precision tolerance on the machining work, as well as high shape and location tolerance requirement. So the stability of the fixture, the rigidity of the cutter are all very important, or there will be deviation on the dimension during production. Material: ADC-12Cavity Number: 2Process Technology: High pressure die casting, Cold ChamberProduct Dimensions: CustomizedCasting General Tolerance: Grade GB-CT4Surface Finish: Polishing, shot blastingFlow Processes: Die casting, Degating, Deburring to remove the flash around the ejector pins, Polishing to remove the parting line, Shot peening to make the part more consistency, High Precision CNC Lathe Machining, E-coating,  Cleaning, Packaging, ShippingControl Measure: Incoming Material Test, First Art
