Shenzhen Sharingtek Communication Co., Ltd

• MOQ 1 Piece(s)

We are offering one click fiber cleaner. Introduction fiber optic cleaner pen is designed to specially work well with the female connectors, this instrument cleans the ferrule end faces removing dust, oil, and other debris without nicking or scratching the end face. Features disposable with 800+ cleanings per unit easy pushing motion engages connector and initiates cleaner made from antistatic resins cleaning micro fibers are densely stranded and debris free extendable tip reaches recessed connectors ordering fcscst cleaner pen, universal 2.5mm; lcmu cleaner pen, universal 1.25mm.

• MOQ 1 Piece(s)

We offer Optic Fiber Fusion Splicer. Optical Fiber Fusion Splicer Descriptions Digital fusion splicer with automatic focus function Fiber core can be display clearly Single X or Y view and X & Y view simultaneously Auto detect cleaved end face fault Display fiber cleaved and offset angle Display core and clad offset 5.6 inch TFT color LCD monitor with clear digital image display USB & VGA interface Software upgrade via USB interface Specifications Model SH-FS150H Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) Fiber cleaved length 10 ~16mm (Coating diameter

• MOQ 1 Piece(s)
• VFLInside
• Dynamic Range32/30dB

We are offering tr300 series handled otdr           descriptions determine fiber optic cable or fiber optic’s failure point, connection point, breakpoint position describe fiber optic cable or fiber’s loss distribution curve, measure cable, fiber’s length and the  loss, attenuation coefficient between two points measure fiber optic cable, optical fiber connector’s insertion loss measure fiber optic cable, optical fiber’s reflection loss specifications model tr300 tr303 tr306 dynamic (1) 2624db 3028db 3230db wavelength (±20 nm) 13101550 display 3.5' tft lcd touch screen light source type ld optical interface fcupc distance range (km) 0.3, 1, 5, 10, 30, 60, 120 pulse width (ns) 5, 10, 20, 40, 80, 160, 320, 640, 1280, 2560, 5120, 10240, 20480, auto measurement duration 15s, 30s, 1min, 2min, 3min attenuation dead zone (2) 15m 10m 10m event dead zone 3m 1.8m 1.8m distance measurement precision ±(1 m + 5 x 10-5 x distance + sampling interval) data storage > 60000 test traces communication interface usb vfl wavelength - 650nm output power (dbm) - ≥ -3 test distance (km) - 3 optical communications test no yes yes note (1) technical specifications describe the guaranteed performance of the otdr when a typical upc connector is used for measurement. The uncertainty caused by the reflection ratio of the optical fiber is not considered. The dynamic range of tr300 is measured when the measuring range is 60 km, the pulse width is 2560 ns, and the average time is 3 min. The dynamic range of tr303 and tr306 is measured when the measuring range is 120 km, the pulse width is 2560 ns, and the average time is 3 min. (2) dead zone measurement conditions: the reflection event occurs within 4 km. The reflection strength is smaller than -45 db. The minimum pulse width is used.

• MOQ 1 Piece(s)

We offer Handheld Optical Power Meter. Sh-m100a optical power meter descriptions sh-m100a handheld optical power meter is a newly designed fiber optic tester, which aims at the installation, engineering acceptance and maintenance of fiber network. Compared with other usual power meters, the sh-m100a has more functions, like automatic wavelength identification, auto wavelength switching, intelligent backlight, data saving via usb port. Combined with sh-s125 handheld optical light source, it offers a quick and accurate testing solution on both sm and mm fibers. Features . wave id auto wavelength identification & switching  . frequency id ---auto frequency identification . 2 types of backlight modes, manual or outside light intensity, which indicated by led light red or blue color. . intelligent backlight  . usb communication port for saved testing records download . reference power level can be set up and stored . user self-calibrating function . auto-off function  . up to 240hrs battery life   specifications model sh-m100a sh-m100b calibration wavelength(nm) 800~1700 detector type ingaas measurement range(dbm) -70+10 -50+26 uncertainty (db) +0.2(5%) linearity (db) 0.01 display resolution(db) 0.03 frequency id hz 270 330 1k 2k wave id nm 850, 980, 1300, 1310, 1490, 1550, 1625 date storage capacity 1000 communication port usb connector fcscst interchangeable alkaline battery 3aaa 1.5v  or li battery (9v) power adapter(v) 8.4 battery operating time (h) 240 without backlight operation temperature(oc) -10(oc) +60 storage temperature(oc) -25(oc)+70 dimension(mm) 172*82*33 weight(g) 310 standard packages model includes all sh-m100 models sh-m100 optical power meter, 3pcs 1.5v batteries, power adapter, user manual, usb cable, cd, cotton stick and soft carrying case.

• MOQ 1 Piece(s)

We offer Fusion Splicer. Descriptions Digital fusion splicer with automatic focus function Fiber core can be display clearly SingleX or Y view and X & Y view simultaneously Auto detect cleaved endface fault Display fiber cleaved and offset angle Display core and clad offset 5.6 inch TFT color LCD monitor with clear digital image display USB & VGA interface Software upgrade via USB interface Specifications Model SH-FS150 Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) Fiber cleaved length 10 ~16mm (Coating diameter

• MOQ 1 Piece(s)
• Fiber TypeSM, MM

We are offering optical time-domain reflectometer, tr600 series handled otdr sh-tr600 series otdr, which meet the needs on the wide range of measurement byfttx, metropolitan area network, backbone network and other optical networks. Technical specifications1 wavelength (nm) 8501300 13101550 131014901550 1625 dynamic range (db)2 2321 3230 3836 323030 344 365 pulse width (ns) 5, 20, 40, 80, 160, 320, 640, 1280 5, 20, 40, 80, 160, 320, 640, 1280, 2560, 5120, 10240, 20480 event blind zone (m)3 3m 3m attenuation blind zone (m)3 13m 13m linearity (dbdb) ±0.05 db db loss threshold (db) 0.05 loss resolution ratio (db) 0.01 sampling resolution ratio (m) 0.125 to 8 sampling point 32k distance uncertainty (m) ±(1 m + 5×10-5× distance + sampling interval) distance scope (km) 0.3 to180 typical real-time refreshing duration (s) 0.2 memory capacity of trace sd card (4g), > 10000 pieces duration of measurement defined by user; 5sec, 10sec, 15sec, 30sec, 1min, 2min, and 3min are selectable general specification interface category dimension (h×w×d) 150×235×66 optical interface fcupc (pc, and apc are selectable) weight 1.5kg data interface usb interface, sd card interface temperature running temperature -10℃ to 50℃

• MOQ 1 Piece(s)

We are offering fiber fusion splicer specifications item fusion splicer applicable fiber type sm, mm, ds, nzds applicable fiber count single applicable fiber diameter cladding diameter of 125um, coating diameter 250 ~ 900umm splice mode stored 40 groups, 80 groups of user-defined average splice loss 0.01db(sm), 0.005db(mm), 0.04db(ds), 0.04db(nzds) return loss more than 60db connecting time 9 sec(typical time) splice loss evaluation it has tensile test 2n screen 4.3 in. Color lcd, english, chinese, french, spanish, portugal, russian etc. Optical magnification x y: 115 times, x, or y: 230 times power supply 11.1v lithium battery, 13.5v5a power adapter, 12v vehicle power supply battery typical operating 220 (splice heat shrink thermal stripping) on a single charge 3h, can be reused 500 times maximum storage 5000 set of the latest record storage data interface usb2.0 operating environment altitude 0 ~ 4000m, 0 to 95% relative humidity, temperature -10 ~ 55degree, the maximum wind speed 15m s storage conditions 0 to 95% relative humidity, -40 ~ 80°c (except battery), -10 ~ 30°c (battery) weight 1.54kg (without battery), 1.82kg (including battery), including attachments packing gross weight: 5.38kg corrosion resistance device components, spare parts and materials used meet corrosion requirements, fluid contamination from erosion size 150d*130w*126h(mm) packing new waterproof, drop, more than can be heavy 300kg

• MOQ 1 Piece(s)
• Splicing Time8S
• Records StorageStore 8000 groups of splice results
