Wuxi ComiX Vulcanization Technology Co.,Ltd.

Wuxi, China

• MOQ 1 Set(s)

Brief Introduction: Our products are mainly applied to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry , , and food automatic line field. Technical Parameters: 1.Vulcanizing Pressure(Mpa): 0.5~:0.8; 2.Vulcanizing Repairing Temperature: 145℃; 3.Temperature Rising Time:＜20min; 4.Total Power:1.96KW; 5.Working Voltage:380V(Customized according to consumers’ requests); 6. Size of Heating Plate:350*350mm(Customized according to consumers’ requests); 7.The Quantity of Heating Plate:2 PCS; 8.Water Pressure:0.8Mpa; 9.The Quantity of Water Pressure Plate:1PC; 10.V Beam: 1 set; 11.Dimension Size:1140*350*560mm; 12.Output Power Of Temperature Controller Box:25KW; 13.The Voltage Of Temperature Controller Box:380V; 14.Manual Pump: S-SY12.54; 15.Pressure Testing Pump Outlet Pressure:4 Mpa; 16.Total Weight: About 120Kg.

• MOQ 1 Set(s)
• Size of Heating Plate830*820mm
• Dimension(L*H*W)1322*830*585mm
• Country of Origin380V
• Weight440KGS
• Belt Width650mm

• MOQ 1 Set(s)

Brief Introduction: Our products are mainly applied to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry , , and food automatic line field. Technical Parameters: 1.Vulcanizing Pressure(Mpa):1.0; 2.Vulcanizing Repairing Temperature: 145�; 3.Temperature Rising Time:�30min; 4.Total Power:3.6KW; 5.Working Voltage:380V(Customized according to consumers� requests); 6. Size of Heating Plate:270*700mm(Customized according to consumers� requests); 7.The Quantity of Heating Plate:2 PCS; 8. Dimension Size;700*410*550mm 9.The Quantity of Water Pressure Plate:1PC; 10.Beams:4 Sets; 11.Output Power Of Temperature Controller Box:25KW; 12.The Voltage Of Temperature Controller Box:380V; 13.Manual Pump: S-SY12.54; 14.Pressure Testing Pump Outlet Pressure:4 Mpa 15.Weight:140kgs

• MOQ 1 Set(s)

Brief Introduction: Our products are mainly applied to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry , , and food automatic line field. Technical Parameters: 1.Vulcanizing Pressure(Mpa):0.8; 2.Vulcanizing Repairing Temperature: 145℃; 3.Temperature Rising Time:＜20mins; 4.Total Power:8KW; 5.Working Voltage:380V(Customized according to consumers’ requests); 6. Size of Heating Plate:350*1000mm(Customized according to consumers’ requests); 7.The Quantity of Heating Plate:2 PCS; 8.Water Pressure:1.2Mpa; 9.The Quantity of Water Pressure Plate:1PC; 10.Beams:6 PCS; 11.Output Power Of Temperature Controller Box:25KW; 12.The Voltage Of Temperature Controller Box:380V; 13.Manual Pump: S-SY12.54; 14.Pressure Testing Pump Outlet Pressure:4 Mpa

• MOQ 1 Set(s)
• Belt Width650mm
• Voltage380V
• Size of heating platen820*800mm

We are offering cmx electrothermal conveyor belt. Brief introduction: our products are mainly applied to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry , , and food automatic line field. Comix advanced touch screen + plc controlled vulcanizing machine is the most advanced and popular with the users all over the world, which is an automatic intelligent touch screen + plc controlled 4.0 belt vulcanizing equipment. All materials used in comix vulcanizing machine, such as the pvc module intelligent control system, heating element, control system, high precision platinum sensors, are derived from germany. Technical parameters: 1.machine maximum size: from 300mm-6000mm; 2.voltage: 220v 380v 415v 660v 50hz; 3.fast cooling time: 15 minutes (from 145 degrees down to 70 degrees or less); 4.time for temperature raise (from normal temperature to vulcanizing temperature) no more than 25 minutes; 5.the temperature difference of sulfide surface: â±2â°c. 6.temperature adjustment range: 0~300â°c. 7.vulcanizing pressure: 0~2.5 mpa(details refer to usersâ�� specifications and factory markings); 8.time of heat preservation for vulcanizing could be adjusted according to thickness of the rubber belts; 9.splicing length of rubber conveyor belt for vulcanizing jointing could be connected together by single or several pieces if necessary; 10.rubber conveyor belt as well as tension in kilogram required for vulcanizing jointing when ordering products. 11.users could order spare electric pumps additionally according to requirements.

• MOQ 1 Set(s)

Technical Parameters 1. Voltage（V）:380V(can be customized according to customers’ requests) 2.Power（KW):0.75 3.Weight（kg）:About 30 4.Application Range:The Joints of EP、NN、Cotton Canvas Conveyor Belt etc. 5.Motor Type:BWY10 6.Speed Ratio:35 7.Machine Size（L*W*H）（cm）:45*23*33 Advantages 1.High working efficiency, low labor strength and light weight. 2.Can be used in different working environment. 3.Original in China, leading in the international.

• MOQ 1 Set(s)
• Belt Width650mm
• Size of Heating Plate830*820mm
• Country of Origincan be customized

Our products are mainly applied to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry , , and food automatic line field. Equipment 1)water fast cooling system; 2)cmx-8*20 electrical pump; 3)cz-cmx temperature control box. Advantages: 1.it is easy to carry; 2.it is simple to operate; 3.it is flexible to assemble. 4.the technology is more advanced.
