Xin Yan Xin Electric Material Ltd

China

• MOQ 12 Piece(s)
• high-applied temperatureanti-oxidization
• little deformationeasy installation and maintenance
• anti-corrosion long uselife

• MOQ 10 Piece(s)
• high-applied temperature anti-oxidization
• top quality long uselife
• anti-corrosioneasy installation and maintenance

We are offering sic heater. 1. Production process:made into blank, silicided under high temperature and re-crystallized. 2.character: high-applied temperature , anti-oxidization , anti-corrosion , long service life , little deformation, easy installation and maintenance. 3.sic heating element . 1) main type :ed (straight ) , db (thin and thick ), sc(single thread), scr(double thread ), u, w, ux . 2)we can provide the dimension as per your requirement . 4. Usage: used in various high temperature electric furnaces and other electric heating devices, such as in the industries of magnet, ceramics, metallurgy , glass, and machinery. 5. Physical properties of element specific gravity 2.6~2.8g/cm³ bend strength >300kg hardness >9 moh′s tensile strength >150kg/cm³ porosity rate.

• MOQ 10 Piece(s)
• Type :U,W,UL,WL,Rodtop quality

We are offering heating elements. rnrn rnrn1.mosi2 heating element is a kind of resistance heating element basically made of high pure molybdenum disilicide. rnrn rnrn2.mosi2 heating element rnrn1) main type :u, w , ul, wl, rod . Material grade :m1700, m1800, m1900. rnrn2) standard dimension (mm):3/6, 4/9, 6/12, 7/14, 9/18, 12/24. rnrn rnrn3.it can be widely used in such applications as sintering and heating treating of ceramic , magnet , glass, metallurgy , refractory, ect. rnrn rnrn4.physical propertyrnrnvolume density 5.5~5.6g/cm³ bend strength 5.5~25kg/cm² rnvickers-hardness (hv)570kg/mm² porosity rate 7.4% rnwater absortion 1.2% hot extensiblity 4% rnrn rnrn5.the max temperature of elements in different atmospheresrnrnatmosphere max rn element temperature rn xyx super ms 17 xyx super ms 18 rnair 1700°c 1800°c rnnitrogen 1600°c 1700°c rnargon helium 1600°c 1700°c rnhydrogen 1100~1450°c 1100~1450°c rnn2/h2 95/5% 1250~1600°c 1250~1600°c rnrn rnrn6.recommend surface load:rnrnfurnace temp(°c) 1400 1500 1600 1650 1700 rnsurface looad of hot zone(w/cm²).

• MOQ 10 Piece(s)
• Type :U,W,UL,WL,Rod .top quality

We are offering furnace heating element. rnrn rnrn1.mosi2 heating element is a kind of resistance heating element basically made of high pure molybdenum disilicide. rnrn rnrn2.mosi2 heating element rnrn1) main type :u, w , ul, wl, rod . Material grade :m1700, m1800, m1900. rnrn2) standard dimension (mm):3/6, 4/9, 6/12, 7/14, 9/18, 12/24. rnrn rnrn3.it can be widely used in such applications as sintering and heating treating of ceramic , magnet , glass, metallurgy , refractory, ect. rnrn rnrn4.physical propertyrnrnvolume density 5.5~5.6g/cm³ bend strength 5.5~25kg/cm² rnvickers-hardness (hv)570kg/mm² porosity rate 7.4% rnwater absortion 1.2% hot extensiblity 4% rnrn rnrn5.the max temperature of elements in different atmospheresrnrnatmosphere max rn element temperature rn xyx super ms 17 xyx super ms 18 rnair 1700°c 1800°c rnnitrogen 1600°c 1700°c rnargon helium 1600°c 1700°c rnhydrogen 1100~1450°c 1100~1450°c rnn2/h2 95/5% 1250~1600°c 1250~1600°c rnrn rnrn6.recommend surface load:rnrnfurnace temp(°c) 1400 1500 1600 1650 1700 rnsurface looad of hot zone(w/cm²).

• MOQ 10 Piece(s)
• top quality long uselife

We are offering heating element. 1.mosi2 heating element rn2.type :u, w, ul, wl, rod . rn3 dia(mm):3/6, 4/9, 6/12, 9/18, 12/24rn4.professional manufacturer rn5top quality rn1.mosi2 heating element is a kind of resistance heating element basically made of high pure molybdenum disilicide. rnrn rnrn2mosi2 heating element rnrn rnrn1) main type :u, w , ul, wl, rod . Material grade :m1700, m1800, m1900. rn2) standard dimension (mm):3/6, 4/9, 6/12, 7/14, 9/18, 12/24. rnrn3.it can be widely used in such applications as sintering and heating treating of ceramic , magnet , glass, metallurgy , refractory, ect. rnrn rnrn4.physical propertyrnrnvolume density 5.5~5.6g/cm³ bend strength 5.5~25kg/cm² rnvickers-hardness (hv)570kg/mm² porosity rate 7.4% rnwater absortion 1.2% hot extensiblity 4% rnrn5.electric property of elementsrnrn1).resistance propertyrnrnthe resistivity of element rapidly rises as the temperature rises, under normal operating conditions , generally the element resistance doesn't change with the service time changing.so the old and new elements can be used mixed. rnrn rnrn2) surface loadrnrn rnrnthe key factor to the optimum service life of the element is to select the surface load of the element correctly according to the furnace construction, atmosphere and temperature.right figure shows the relation between the furnace and the element surface load under the condition that the element radiation isn't obstructed.the shadow part in the figure shows the surface load-temperature range in common use.the figure still shows the reference current. rnrn rnrn rnrn rnrn rnrn5.recommend surface load:rnrnfurnace temp 1400 1500 1600 1650 1700 rnsurface looad of hot zone(w/cm²).
