Zhuhai Lingke Company

China

• Packaging Typered

Prescision machine Technique specification type LK1521JM power 3200w frenquency 15kHz output voltage AC 220V horn journey 100mm oscillation time 0.01-9.99s air pressure 1-7bar welding capability diam170/200/405/280 size 650*950*2250mm weight 125kg The features of the machine 1. Imported accessories adopted. 2.Four horizontal screw adopted. 3.The machine head up and down automatically. 4.Sheermetal non-rectangular columns, coattails groove design, welding more precious 5.Two-hand start with EMERGENCY STOP at front, also can be added the external switch. Application fields: Widely used in the automotive industry, electronic industry, medical industry, household appliances, woven apparel, office supplies, packaging industry, toy industry and so on. Such as plastic body parts, car doors, car dashboard, lights, mirrors, sun visor, interior parts, filters, reflective material, reflective spike, bumper, cable, motorcycle plastic filter, radiator , tanks, pallet plates. Plastic electronics: prepaid water meters, communications equipment, atheism phone, mobile phone accessories, cell phone case, battery case, charger, maintenance valve regulated lead-acid batteries, 3-inch floppy disk, U disk, SD card, CF card, USB connectors, Bluetooth. Toys, stationery: folder, album, folding boxes, PP hollow board, pen loops, ink cartridges, toner cartridges. Medical Daily: watches, kitchen utensils, oral liquid bottle, drip caps, mobile phone accessories, gold soft brush, daily necessities, health supplies, children' products, air mattresses, clothes hangers, tool holder, coffee pot, cover and Civil speaker grille metal surface. Widely used in the automotive industry, electronic industry, medical industry, household appliances, woven apparel, office supplies, packaging industry, toy industry and so on.

• Rated Power2000w

20khz Standard machine Quick Details Place of Origin: China (Mainland) Brand Name: LK-sonics LK1521PT Voltage: AC220V Power: 4200W 15kHz Welding Area: Diam50~Diam320 Dimensions: 800*850*2250 mm 340kg Usage: Plastic welding Color: Blue Non-toxic Dwell time 0.01-9.99s Warranty: One year Packaging & Delivery Packaging Details: wooden packing or multiply plywood packing, sutable for ocean shipping Delivery Detail: 5-7 business days after pay the deposit Specifications ultrasonic standard welding machine used for riveting, sealing, marking. non-contaminating. imported accessories adopted 4200W ultrasonic plastic welding machine for car lamps Product Description The features of the Welding equipment from China: 1. Big power, using four balance adjustment, horn-adjustment convenient 2. Sheet metal welding nonrectangular columns, avoid fadeaway 3. Automatic overloading protection device 4. Import converter and steel booster, durable stability 5. Frequency adjustable and automatically compensate the circuit 6. Straight line guide bearing, precision trimming device performance talented 7. PLC control . Technique specification : Model no LK1521PT Power 4200W Frequency 15kHz Input voltage 220V/50HZ/10A/1P Horn journey 100mm Cylinder Oscillation Time mode Bar Scope:1-7bar Switch Tow Hand start, emergency braking, an external switch can be attached Size 800*850*2250 mm Weight 340kg Product Introduction: It is primarily used for secondary connection of thermoplastic. Compared with other welding techniques, plastic welding has the advantages of excellent welding quality, high production efficiency and wide application. By using imported piezoelectric ceramics vibrators and original vertical normal temperature-circulation self-cooled ultrasonic generators, our products enjoy the lowest failure rate among the same industry.

• Frequency25khz

High-frequency welding machine Place of Origin: Guangdong, China (Mainland) Brand LK-sonics Model LK-5000ZH Voltage: AC380V Power: 5000W Frequency: 27.12MHZ Welding Area:Zhuhai 200MM Dimensions: 1000*1730*660mm Weight: 400kg Usage: PVC products welding Color: blure Packaging & Delivery Packaging Details: multiply and plywood packing Delivery Detail: 7 business day after payment Specifications High Frequency Welding Machine For PVC Products 1.slipway working positions 2.for large-area PVC processing 3.with stable, High Frequency Welding Machine For PVC Products 1.Using a high Q value vibration tube in the machine, so it is stable and reliable in output. 2.High sensitive spark depressing circuit is used for preventing mould damage. 3.With the movable table style structure, it can save thime and strength and easy to be operated. 4.With a mechanical cylinder working stable location fixing gadget, it can fix location precisely. 5.It is made of a whole set high-quality imported components
