Intellitech Electronic Solutions Limited

Shalimar Bagh, Delhi

• Primary :Normal Stepup or Stepdown
• Surge Suppression Time :5 pico second
• Input Frequency Tolerance± 3Hz
• Input Voltage Tolerance  :± 10%
• Break Down Voltage2.5 KV / Per 1 Min
• Output Voltage :1:1 / Stepup / Stepdown or as per the requirement
• Spike suppression Energy :2.0 joules
• Rated Input Voltage  :110v / 230v / 415v
• Coupling Capacitance.01 P.F.
• Insulation Resistence :More then 1000 M Ohms at 500 v DC
• Common Mode NoiseReduces by Over 85 DB
• Load Regulation :Better then 3.5%
• Leakage Current :better then 1 micro Ampere
• Rated Input Frequency  :50Hz

• Protections :Low Battery, Overcharge
• Output Current :0 Amp. -60 Amps. as per the requirement
• Input Frequency Tolerance :± 5Hz
• Rated Input Voltage  :230 VAC
• Indications :Charging & Charged
• Output Voltage (DC) :202.5 V DC
• Secondary rectification :Full Wave Rectifier ( Metallic Diode 100 Amp. OPTIONAL)
• Battery Backup :MCB Protection (OPTIONAL)
• Type :Constant Voltage Constant Current
• Ripple Filtration :30000UF / 50VCap. Ripple Free (Opt.)
• Rated Input Frequency  :50Hz
• Input Voltage Tolerance  :150v to 270v
• D.C. Protection :Reverse Battery Protection (Opt.)
• Recharge Time :<8 hours upto 90%
• Primary :Normal Stepdown

• Type  :Line interactive
• Input Voltage Tolerance  :140v to 270v
• Battery backup :As per the customer requirements
• Protections :Short Circuit, Overload, Low Battery, Fuse Fail.
• Noise Level :<50dB
• AH&V rating of Battery :As per the backup required
• Output Power Factor :0.6
• Transfer Time :<3 MSec.
• Humidity Tolerance :Upto 85% Non Condensing
• Trmprtature Tolerance :0 to 50 Degre centigrade
• Indications (Visual) :Mains Fail, Battery Low, Charging & Charged
• Rated Input Frequency  :50Hz
• Battery type :As per the backup required
• Efficiency :>60%
• Ventilation :LooversType Air Cooled
• Recharge Time :<16 hour
• Output Wave Form :Quasi Sine Wave
• Make of Battery :As per the customer requirements
• Technology  :PWM ( Mosfet Based )
• Output Voltage :230 ± 8% single phase
• Rated Input Voltage  :230 VAC
• Output Frequency :50Hz ± 0.05%
• Physicals Dimensions :As per per the model

• Type  :True Online
• Rated Input Frequency  :50Hz
• Humidity Tolerance :Upto 85% Non Condensing
• Technology  :PWM ( IGBT Based )
• Harmonic Distortion :<4% T.H.D
• Indications (Audio-Visual) :Mains, Charging, Output, Battery Low, Overload
• Recharge Time :<8 hour upto 90%
• Output Frequency :50Hz ± 0.05% free running (Pure Sine Wave)
• Output Voltage :230 ± 2% single phase
• Efficiency :>90%
• Rated Input Voltage  :230 VAC
• Input Voltage Tolerance  :160 v to 260v
• Protections :Short Circuit, Overload, Low Battery, Fuse Fail.
• No. of Battery :As per the model required
• Noise Level :<50dB
• Output Power Factor :0.8
• Make of Battery :As per the customer requirements
• Ventilation :Force Type Fan Cooled
• Input Frequency Tolerance :± 5%
• AH&V rating of Battery :As per the backup required

we are offering electrical control board

we are offering Electrical Distribution Board

we are offering Electrical Panels

we are offering Isolation Transformer
