Catini Macchine Srl

Fermo, Italy

We are Offering Hydraulic programmable 9 pincers toe lasting machine

The pulling over and lasting machine model K78SZ is suitable for any kind of work from the smallest children sizes to the largest mens, including safety shoes with steel toe cap, and also for all types of ladies shoes regardless the height of heel. The K78SZ comes with wide range of standard features such as rotating pincers, optical projector, movable pincers system, motorized wipers stroke, timers for pincers opening adjustment from work place. In addition, rearward drafting, single pincers opening device, pointed toes working kit and left and right heel rest movement can be fitted as optional extras together with the facility to produce "Goodyear" and "San Crispino" footwear. Special movable wipers parts which extend the lasting over the beginning of the sides allow to make the whole shoe lasting in only two operations. The 9 pincer adjustment allows the operator to feed very tight work with no difficulty thus creating an opportunity for significant leather savings. The machine is hydraulically controlled and consequently offers a high work speed, exact pressure control, easy maintenance and much lower operational cost than comparative pneumatically controlled machines. The machine has been ergonomically designed.

We are Offering Swing arm cutting machine ATOM G 999, 25 tons pow.

We are Offering swing arm cutting machine ATOM SE 20, 20 tons pow.

We are Offering swing arm cutting machine ATOM S 118, 20 tons pow.

BANF has now gone further, equipping the P 76 with attachment devices which guarantee greater safety, both to the worker and to the product. The devices can be assembled both separately and in couples (or even together with the second attachment – as shown on the picture on the side). Anyhow, the machine is also available in the classic version, without attachments. The first device, as shown in the above picture, allows a different pressure on the heel, thus avoiding possible deformations. The second device has been studied in order to make the working easier when it comes to compressing high bootleg footwear soles. For this reason BANF has realized, for P 76, a device which allows the rotation of the pressure arm towards the inside of the machine, as it is shown in the picture. In this case too the device can be assembled, upon request, separately or together wit the other ones. TECHNICAL DATA DIMENSIONS: cm 105x110x205 NET WEIGHT: kg 875 MOTOR POWER: HP 2 HYDRAULIC PUMP: kg/cm² 175

Machine very noiselless, il permits a production higher than any other in trade, for its approach speed of the pistons. The dimension, of the pistons, with large diameter, permit high power in tons without high-pressure working, therefore with a greater safety of employement. Its hydraukic system, easy and pratical, is the better warranty of elimination of any trouble and obstacle. TECHNICAL DATA Weigh without oil: Kg 690 Dimension: mm 120x90x165 Motor: HP 2, 5 Obtainable power: t 32 Pistons diameter: mm 185 Highest port of planes: mm 230 Dimension of planes: mm 230x480

We are Offering double chamber sole press PERRY PS 2005 (with "hole" to press boots too) made in Italy

It is universally known that the good quality of an insole is given by its perfect adhesion to the last, this given by for definite and interdipendent elements as: the pressing strenght, the stamp, the positioning of the insole in the stamp and the upkeeping on such position during the pressing operations. With this machine we have optained something that till now has never been realized: the insole pressing inserted in the stamp in the wanteed position, in order to avoid eventual movings during the pressing operation. This is possible using the belt conveyer which allows: 1) to put the insole on the belt against some indicated points allowing so the repetition of the series. 2) to have the pressing with the insole always stopped in the wanteed position during the same, as, mean while the stamp goes down and begins to press on the insole, the insole it is stopped in the original position through a tightened belt till that there is contact with the counterstamp. Of course, in conseguence of the belt conveyer, during the pressing the operator of the machine must put on the belt another insole in the right position of centering, as when the timer of the pressure time open the stamps, automatically there is the pressed insole discharge and the charge of the new to be pressed. The machine has two oleodynamic autocompensating cylinders on which there are the counterstamps in order to allow the use of couple of stamps which are already used on other machines; as with our press is possible to use each type of stamp even if produced by other firms. The used belt allow to warrentee a medium validity from 1 to 3 months each, this depending from the done work and particularly to the counterstamp preparation which have not to have corners or cutting edges which can damage the belt. The output can vary from 600 to 900 pairs each hour: 1) adjusting the pressing timer from 1 to 6 seconds; 2) raising or reducing the feeding speed. The oleodynamic and pneumatic parts are closed in sure panels and are always ready for an easy checking. The electric plant positioned in the front of the machines has been studied in order to give more guarantee for the during and functionality time, as the electric power of the electrovalve and of the contacts is of 24 Volts each. In the plant there is insereted a safety system with a photoelectric cell barrier which protect the operator against eventual incidents in the case that he puts the hands or something other in the same during the pressing operation. TECHNICAL DATA - DIMENSIONS: cm. 200x100x185 - NET WEIGHT: kg. 1410 - MOTOR POWER: HP. 5 - HYDRAULIC PUMP: kg./cmq. 190 - Tonn. 68 - DIMENSIONS: cm. 200x160x210 - NET WEIGHT: kg. 1560 - MOTOR POWER: HP. 5 - HYDRAULIC PUMP: kg./cmq. 190 - Tonn. 68
