Our Products
The MH501L Pneumatic Rock Drill is a winner when it comes to ease of use in tight spaces due to its low-weight and robust rifle bar rotation mechanism. This lightweight drill has been used for years for small jobs and is most suitable for mines with confined operator spaces. The drill allows miners to achieve depths of up to 1.5 meters (5 feet) with minimal air consumption. The T-grip handles along with its low-weight make the experience much more comfortable from the operator point of view. The air flushing system built into the drill rod prevents drill jamming by removing drill chips.
Product Specification is as under
Axis Travel
X axis 900mm
Y axis 520mm
Z axis 835mm
B axis360
Spindle Details
Max spindle speed: 13000 RPM
Spindle Taper: HSK100
Table Details
Machine length: 500mm
Machine width: 500mm
Max weight on Table: 1000 KG
Magazine poket no: 24
Coolant tank Capacity 400 L
Max. Feed rate X , Y, Z: 50 m/min
Machine weight approx: 13000 kg
Machine size Dimensions( L x B x H ): 4900x3100x3000 mm
Don't miss the opportunity to elevate your manufacturing abilities by incorporating this exceptional
machine into your workshop.
For sale is a vertical machining center manufactured by Haas. The Haas VF-3 vertical machining
center is known for its reliability and precision. It is a versatile machine that can handle a wide range
of machining tasks. With its advanced features and capabilities, it is suitable for various industries
and applications.
High-power, direct-drive spindles
Customizable to your needs
More X- and Z-axis travel
Made in the USA
Category: CNC Mill
mindrill has been in the precision engineering industry with a world class production facility comprising cnc and vmc machinery. Cnc grinding, sealed quench heat treatment furnaces. All led by an expert engineering team to ensure customer satisfaction. Since 1971, mindrill has been manufacturing an industry-leading line of top hammers shank adapters including pneumatic and hydraulic drifters and is also home to a variety of shank adapters and coupling sleeves for the best customer experience. Made from the best quality raw materials with state of the art equipment and close tolerances, our shank adapters always offer optimum performance in all top hammer drilling applications while maintaining a long life. Our shank adapters ensure maximum energy transmissibility from the drill rod to the shank adapters and minimize energy losses. Tophammer shank adapters
key features:
made from the highest grade alloy-steels
deliver high performance and long life
Additional Information:
Payment Terms : L/C, T/T
Packaging Details : Wooden box
Delivery Time : 25 days
mindrill striking bars (shank adapters) and couplings are designed to deliver optimum performance at the lowest possible cost. accurate, dependable, and cost-effective, the extensive mindrill line includes striking bars (shank adapters) & couplings for pneumatic and hydraulic drifters.
shank adapters are available to fit all types of drilling machines both pneumatic and hydraulic. shanks are available with most types of popular international thread forms including r22, r32, r38, t38 & t45.
key features of coupling sleeves:
rdtrock drilling coupling sleevesare designed precisely with the aim to minimize the possible danger of an uncontrolled air hose.mindrill coupling sleevesare built with hard alloy steel to ensure durability thereby increasing the productivity.
benefits of sleeve coupling:
rdt sleeve couplingis a customary one-handed operation rock drilling tool, with high air flow performance.
The MH502A pneumatic sinker drill is the first choice for multiple kinds of drilling operations. With the largest-in-class piston diameter and its superior integral oiler lubrication system, the MH502A has very low spare parts consumption. This drill also has low air consumption thereby reducing overall running costs. Combined blower & throttle lever and T-handle increases operator comfort. This pneumatic rock drilling machine with robust construction quality and streamlined design allows high penetration rates over a long period with minimum maintenance costs and downtime.
OptionsAdditional Information:
Packaging Details : Wooden Box
Metric | Imperial | |
Length | 575 mm | 23” |
Weight | 25.5 kg | 56 lb |
Stroke Length | 51 mm | 2” |
Impact Rate | 1980 BPM | |
Air Consumption | 48 l/s | 102 cfm |
Working pressure | 6 bar | 87psi |
Revolutions | 215 RPM | |
Penetration Rate | 230 mm/min | 9 in/min |
Piston Diameter | 67 mm | 2 5⁄8” |
Max Drilling Diameter | 50 mm | 2” |
Max Drilling Depth | 3000 mm | 10’ |
The MPD120 pneumatic drifter is a highly versatile yet low-cost drill suitable for both surface and underground applications. This drill can be used with a variety of shank adapters making it highly versatile and it is designed especially for long hole drilling, bench drilling, and drifting with hole diameters of 51-89 mm (2-3.5 in.). It is also easily mountable on a variety of drill rigs. This drill has both water and air flushing options and can be converted easily from one to another based on the operators ever-changing needs. It has a rifle-bar actuated rotation motor which has eight pawl sets, providing four for each direction and thus enabling rotation in either direction. The incoming air hose connection can be made on either side of thedrillto ensure easy of control and operator comfort.
Key Features of Pneumatic Drifter Parts
Multipurpose long-hole drill suitable for both underground and surface applicationsCan be easily mounted on a drill rig and used with a variety of shank adapters for various applicationsBoth-sided reversible rotation mechanism
Options:
Chuck sizes R38 mm (1) & R32 mm (1)
Specification | ||
---|---|---|
Metric | Imperial | |
Length | 780 mm | 30” |
Weight | 70 kg | 152 lb |
Power Rating | 7 kW | 9.4 BHP |
Bore Diameter | 34 mm – 64 mm | 1 1⁄4” – 2 1⁄2” |
Impact Rate | 1980 BPM | |
Air Consumption | 167 l/s | 353 cfm |
Revolutions | 210 RPM | |
Piston Diameter | 120 mm | 4 3⁄4” |
Ordering Part Numbers: | |
---|---|
R38 mm (1 1⁄2”) | 5113 102 000 38 |
R32 mm (1 1⁄4”) | 5113 102 000 32 |
Despite its low weight of about 20 kgs. The MPB1210 is a winner when used for light to medium construction, utility and plant maintenance, bridge deck jobs, light demolition of floors, pavements, road surfaces, and other surface jobs. The tuned valve system and reversible piston with lubrication grooves increase productivity and reduce downtime. It can be used with various shank sizes for different applications.
Key FeaturesAdditional Information:
Payment Terms : T/T
Packaging Details : Wooden Box
Specification | ||
---|---|---|
Part No. – 5112 102 000 | Metric | Imperial |
Length | 540 mm | 21” |
Weight | 20 kg | 44 lb |
Impact Rate | 1400 BPM | |
Air consumption | 26.5 l/s | 56 cfm |
Air Connection Part No. | 3/4″ NPTF | |
Steel Size (HEX) – Chuck End | 25 mm X 108 mm | 1” X 4 1⁄4” |
The MPB1230 is the heavy counterpart of the MPB1210. Concrete breaker and is used for tough construction and plant maintenance work like breaking reinforced concrete, heavy road work, cutting tarmac, frozen ground or non-consolidated rock and general demolition work. They come with an integral oiler and reversible piston mechanism to reduce maintenance costs and minimize downtime.
Key FeaturesAdditional Information:
Packaging Details : Wooden box
Specification | ||
---|---|---|
Metric | Imperial | |
Length | 680 mm | 26 3/4” |
Weight | 29.5 kg | 65 lb |
Impact Rate | 1300 BPM | |
Air Consumption | 32 l/s | 68 cfm |
Steel Size (HEX) – Chuck End | 32 mm X 160 mm | 1 1⁄4” x 6” |
Mindrill always recommends its valued customers to use a lubricator in conjunction with their pneumatic jackhammers to enhance the drill life and performance by protecting against corrosion and machine wear and tear. The ML130lubricatoris a versatile solution which has been a customer favorite since its introduction in the market.
Key Features of ML130 Lubricator
Precise oil regulation controlVersatile and rugged designEnhances drill life and efficiency
Specification | ||
---|---|---|
Part No. – 5231 101 000 | Metric | Imperial |
Weight | 2.6 kg | 6 lb |
Oil Volume | 1.3 ltr | 43 fl. oz. |
Air Flow | 25-130 l/s | 53-275 cfm |
Hose Diameter | 25 mm | 1” |
Max Working Pressure | 20 bar | 290 psi |
Additional Information:
Packaging Details : Wooden box
This model of Pick Hammer is the most common. It can be used by any tradesman but also by a simple handyman. This type of pick hammer also has a pellet distribution. The light metal handle is an innovation.
Key FeaturesAdditional Information:
Packaging Details : Wooden Box
Mindrill CD115 crawler drill is a pneumatic crawler drill for drilling with a top hammer (TH). It comes with two independent 5 HP propulsion air motors steered with a piston driven rotary head. Its robust construction, track mounted frame, and mainframe walking beam oscillator assembly is ideal for drilling in confined areas with rough terrain. The strong 7.5 HP air powered hydraulic pump ensures high feed force and supreme productivity. The TH version can drill 46-76 mm wide holes.
Based on the industry-leading design, the Mindrill MPD90 with an integrated silencer is an ideal pneumatic drifter for top hammer applications in dimensional stone industries. Compatible with a wide range of drill rigs, the MPD90 is known for its versatility, performance, and high return on investment. This drill has parts interchangeable with the OSM MP90.
Additional Information:
Packaging Details : Wooden Box
The Mindrill MDEMJ115 Tigerexcavator attachmentis an effective, versatile, and cost-effective solution for the mining and construction industry. The versatile attachment with any excavator yields a powerful drilling rig that can be used for blast-hole mining or construction applications.
Additional Information:
Payment Terms :
Mindrillheavy duty crawler drill YODHA70 is a pneumatic crawler drill for drilling with a DTH hammer. It comes with two independent 5 HP propulsion air motors steered with a piston-driven rotary head. Its robust construction, track-mounted frame, and mainframe walking beam oscillator assembly are ideal for drilling in confined areas with rough terrain. The strong 7.5 HP air-powered hydraulic pump ensures high feed force and supreme productivity. The DTH hammer version can drill 70-90 mm wide holes.
Crawler Drill SPIDER 250 TH is a specially designed crawler drill rig that is perfect for roof bolting applications in narrow underground tunnels or mines. The track chain mounted self-propelled design makes it easy to use, and the pneumatic automatic rod catcher means quick and easy rod changing. Theres also a water flushing option available, and the overhead guard ensures operator safety. This simple and robust solution can be customized to your specific needs.
MindrillYODHA90crawler drill is apneumatic crawler drillfor drilling with a DTH hammer. It comes with two independent 5 HP propulsion air motors steered with a piston-driven rotary head. Its robust construction, track-mounted frame, and mainframe walking beam oscillator assembly is ideal for drilling in confined areas with rough terrain. The strong 7.5 HP air-powered hydraulic pump ensures high feed force and supreme productivity. The DTH hammer version can drill 90-115 mm wide holes.
DTHCrawler Drill YODHA450by Mindrill, is a versatile and rugged drill rig that can handle steep climbs and rough terrain with ease. The crawler drill ensures fast and efficient drilling while servicing is quick and easy requiring just one person. TheYODHA450is suitable for limestone, aggregate quarries, surface mining applications, and construction.
The Mindrill MGP45 piercing tool is designed for reliability and optimal performance in any ground condition. With a heavy-duty one-piece striker and robust body housing, the MGP45 provides better durability and longevity than similar models on the market.
Additional Information:
Payment Terms : L/C
The MH502A series of rock drills are the first choice for multiple kinds of drilling operations. With the largest in-class piston diameter and its superior integral oiler lubrication system, the MH502A has very low spare parts consumption. This drill also has low air consumption thereby reducing overall running costs. Combined blower & throttle lever and T-handle increases operator comfort. Its robust construction quality and streamlined designed allow high penetration rates over a long period of time with minimum maintenance costs and downtime.
Key Features:
Integral oiler provides continuous & efficient lubrication
Graduated ratchet throttle control ensures accuracy in collaring holes
Tough latch retainer provides extra support to collar and reduces wear
T-handle for increased comfort
Blower lever for deep hole cleaning
High speed drilling
Low maintenance
Mindrill has been in the precision engineering industry with a world class production facility comprising CNC and VMC machinery. Tapered button bit CNC grinding, sealed quench heat treatment furnaces, all led by an expert engineering team to ensure customer satisfaction. rock drill tools Since 1971, Mindrill has been manufacturing an industry-leading line of top hammers including pneumatic and hydraulic drifters & tapered button bit are made from premium quality raw materials and are engineered for high penetration rates and long service life. As tapered bits are gaining popularity by the day, Mindrill aims to provide nothing but the best to its customers as always to maximise their profits. sandvik taper bits,
Key Features:
High penetration rate
Long service life
Proven design
High quality raw material
Additional Information:
Payment Terms : L/C, T/T
Packaging Details : WOODEN BOX
Delivery Time : 20 DAYS
Mindrill Drill Tubesare produced using the superior quality seamless pipe. Thesedown the hole drilling toolsare friction welded to give a sturdy and constant welding for long service life.
Benefits of Drill Tube Accessories:
Drill Tube Accessoriesare available with DTH rods of 76mm, 89mm, 102mm and 114mm. This deep holedrillmachine is fit for rigid and confident drilling. The drill tubes are specifically designed for a range of hole diameters.
MH502AFR pneumatic rock drill, Sinker Drills robust design that makes them easy to handle in quarry-mine and general excavating work. The design also provides a main valve and cylinder porting concept that helpsmaintainconstant drilling speed throughout a long service life. Working parts are constantly protected with an effective lubrication system. Pneumatic rock drillin Industrial Breakers and Demolition Hammers.
Added feature is water flushing system for underground tunneling.
Benefits & Features
Type | Metric | Imperial |
Weight | 26 Kg | 57.3 lb |
Length | 575 mm | 23 inch |
Air Consumption | 48 l/s | 102 cfm |
Air Inlet | 20 mm | 3/4 inch Swivel |
Retainer Type | Latch | Latch |
Revolution | 180 rpm | 180 rpm |
Max Drilling Dia | 50 mm | 1.97 inch |
Max Drilling Depth | 3000 mm | 118 inch |
Shank Size | 22 X 108 mm | 7/8 X 4¼ inch |
Optional Shank Size | 25 X 108 mm | 1 X 4 1/4 inch |
Working Pressure | 6 Bar | |
Blows per minute | 2100 |
The MH501L Pneumatic Rock Drill is a winner when it comes to ease of use in tight spaces due to its low-weight and robust rifle bar rotation mechanism. This lightweight drill has been used for years for small jobs and are most suitable for mines with confined operator spaces. The drill allows miners to achieve depths of up to 1.5 metres (5 feet) with minimal air consumption. The T-grip handles along with its low-weight make the experience much more comfortable from the operator point of view. The air flushing system built into thedrill rodprevents drill jamming by removing drill chips.
At its competitive pricing, the MH501L is the number 1 choice for use in small jobs. Characterised by low pricing and minimal running costs, the MH501L line of drills is the go-tohandheld jackhammerfor small-scale exploration in confined regions and on difficult terrain because of its modest air consumption and low weight.
Key Features:
Additional Information:
Payment Terms : L/C, T/T
Packaging Details : Wooden Box
Part No. | Metric | Imperial |
Length | 510 mm | 20” |
Weight | 19 kg | 42 lb |
Bore Diameter | 28 mm – 34 mm | 1 1⁄8” – 1 3⁄8” |
Stroke Length | 60 mm | 2 3⁄8” |
Impact Rate | 1980 BPM | |
Air Consumption | 39 l/s | 83 cfm |
Revolutions | 190 RPM | |
Penetration Rate | 275 mm/min | 10 3⁄4 in/min |
Piston Diameter | 55 mm | 2 1⁄8” |
Air Supply Hose ID | 19 mm | 3/4” |
Steel Size (HEX) – Chuck End | 22 mm x 108 mm | 7/8” x 4 1⁄4” |
The MD 120F pneumatic drifter is a highly versatile yet low-cost drill suitable for both surface and underground applications. This drill can be used with a variety of shank adapters making it highly versatile and it is designed especially for long hole drilling, benchdrilling, and drifting with hole diameters of 51-89 mm (2-3.5 in.). It is also easily mountable on a variety of drill rigs. This drill has both water and air flushing options and can be converted easily from one to another based on the operators ever-changing needs. It has a rifle-bar actuated rotation motor which has eight pawl sets, providing four for each direction and thus enabling rotation in either direction. The incoming air hose connection can be made on either side of the drill to ensure easy of control and operator comfort. MD 120f drill is low cost drill.
Multipurpose long-hole drill suitable for both underground and surface applicationsC an be easily mounted on a drill rig and used with a variety of shank adapters for various applicationsBoth-sided reversible rotation mechanism
Options:
Chuck sizes R38 mm (1) & R32 mm (1)
Additional Information:
Payment Terms : L/C, D/P, T/T
Packaging Details : Wooden Box
Specification | ||
---|---|---|
Metric | Imperial | |
Length | 780 mm | 30” |
Weight | 70 kg | 152 lb |
Power Rating | 7 kW | 9.4 BHP |
Bore Diameter | 34 mm – 64 mm | 1 1⁄4” – 2 1⁄2” |
Impact Rate | 1980 BPM | |
Air Consumption | 167 l/s | 353 cfm |
Revolutions | 210 RPM | |
Piston Diameter | 120 mm | 4 3⁄4” |
Ordering Part Numbers: | |
---|---|
R38 mm (1 1⁄2”) | 5113 102 000 38 |
R32 mm (1 1⁄4”) | 5113 102 000 32 |
Mindrill has been in the precision engineering industry with a world class production facility comprising CNC and VMC machinery. Tapered button bit CNC grinding, sealed quench heat treatment furnaces, all led by an expert engineering team to ensure customer satisfaction. rock drill tools Since 1971, Mindrill has been manufacturing an industry-leading line of tophammersincluding pneumatic and hydraulic drifters & tapered button bit are made from premium quality raw materials and are engineered for high penetration rates and long service life. As tapered bits are gaining popularity by the day, Mindrill aims to provide nothing but the best to its customers as always to maximise their profits.
Key features of Tapered Button Bit:Proven DesignHigh Penetration rateLong service lifeDeveloped using high-quality raw material
Mindrill YODHA100 crawler drill is a pneumatic crawler drill for drilling with a DTH hammer. It comes with two independent 5 HP propulsion air motors steered with a piston driven rotary head. Its robust construction, track mounted frame, and mainframe walking beam oscillator assembly is ideal for drilling in confined areas with rough terrain. The strong 7.5 HP air powered hydraulic pump ensures high feed force and supreme productivity. The DTH hammer version can drill 100-121 mm wide holes.
The YODHA100 is a low-cost, effective, and versatile drilling rig that offers great return on investment for a wide range of applications. The compact and lightweight track-mounted frame is ideal for maneuvering over rough terrains and confined areas. It has a versatile feed boom arrangement that allows it to perform drilling in a wide range of angles and orientations.
Additional Information:
Packaging Details : Wooden Box
Carrier | ||
---|---|---|
Tramming speed | 3.2 km/h | 2mph |
Traction force | 17 kN | 3821 lbf |
Track oscilation | ±20° | |
Ground clearance | 225 mm | 8.9″ |
Hill climbing ability | 30° max (W/O compressor) |
Steel Feed | ||
---|---|---|
Pneumatic -driven chain feed | ||
Feed extension | 750 mm | 29.4″ |
Feed rate, max | 0.3 m/s | 59 ft/min |
Feed force, max | 21 kN | 4720 lbf |
Tractive pull, max | 15 kN | 3372 lbf |
Total length | 5130 mm | 202″ |
Travel length | 3565 mm | 104.4″ |
Volumes | ||
---|---|---|
Hydrulic oil tank | 22 l | 5.8 us gal |
Hydrulic system, total | 22 l | 5.8 us gal |
Traction gear | 2 l | 0.53 us gal |
Lubrication tank (HECL) | 7.6 l | 2 us gal |
TRANSPORT DIMENSIONS
Height and length | ||
---|---|---|
Tramming Position | ||
Height | 1720 mm | 68″ |
Length | 5120 mm | 201 1/2″ |
Transportation Position | ||
---|---|---|
Height | 2325 mm | 91 1/2″ |
Length | 5120 mm | 201 1/2″ |
Width | 1940 mm | 76 1/2″ |
WEIGHT
Standard unit excluding all options and drill steel | |
---|---|
2690 kg | 5930 lb |
HOLE RANGE
Pipe size | Recommended hole range | ||
---|---|---|---|
76 mm | 3″ | 102-115 mm | 4″ – 4 1/2″ |
