Hotplate with stainless steel surface or porcelain enamel surface with excellent chemical resistance
Fuzzy logic control microprocessor technology guarantee maximum control accuracy
2 adjustable safety circuits , separateness temperature sensor, protection temperature can be set
Warning display indicating presence of any residual heat when the unit is switched off
Square/Disc optional Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 500
Max.stirring quantity(H2O)[L] 20
Stirring point position quantity[mm] 80
Motor type :brushless motor
Speed range[rpm] 200-1500
Speed and temperature display LCD
Speed display accuracy[rpm] 1
Plate material:Material Ceramic coating surface/Stainless steel
Dimension of Plate[mm] f135 or 155
Heating Temperature Range[C] RT-380
Temperature display accuracy[C] 0.1
Temperature sensor of extra position PT100(Optional)
Packing size:0.37*0.28*0.18cm
Weight:3kg, Permissible ambient temperature[C] 5-40
Permissible ambient humidity 80%
Protection class acc. to DIN EN60529 IP42
Features
Magnetic stirrer suitable for unsupervised operation, with new stir technology
Automatic judgement stirring bar displacement and capture
Hotplate with stainless steel surface
Easy-to-read backlit LCD display
Fuzzy logic control microprocessor technology guarantee maximum control accuracy
Specifications
Square/Disc optional Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 500
Max. stirring quantity(H2O)[L] 20
Stirring point position quantity[mm] 80
Motor type :brushless motor
Speed range[rpm] 200-1500
Speed display LCD
Speed display accuracy[rpm] 1
Plate material:Material Ceramic coating surface/Stainless steel
Dimension of Plate[mm] f135 or 155
Packing size:0.37*0.28*0.18cm
Weight:3kg
Permissible ambient temperature[C] 5-40
Permissible ambient humidity 80%
Protection class acc. to DIN EN60529 IP42
RS232 interface optional
MR-DHP-Pro Digital Hotplate
Specification
Square/Disc optional Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 500
Plate material:Material ceramic surface/Stainless steel
Dimension of Plate[mm] 135X135 or 155X155
Heating power[W] 500
Heating Temperature Range[C] RT-380
Temperature display LCD
Temperature display accuracy[C] 0.1
Control accuracy of heating temperature[C]1
Temperature sensor of extra position PT100(Optional)
Control accuracy of heating temperature with temperature Sensor[C] 0.2
Packing size:0.37*0.28*0.18cm
Weight:3kg
Permissible ambient temperature[C] 5-40
Permissible ambient humidity 80%
Protection class acc. to DIN EN60529 IP42
MR-MSH-2L Analog Magnetic Stirrer(plastic body)
Specification
Packing size:0.37X0.28X0.18cm
Weight:3kg
Work plate shape:Square/Disc optional
Color optional
Stirring point position quantity 1
Max. stirring quantity(H2O)[L] 2
Motor rating input [W] 4
Motor rating output[W] 5
Speed display: Scale
Speed range[rpm] 0 - 2500 rpm
Stirring bar length max: 30mm
Material of top plate :Material Stainless steel(Ceramic surface)
Dimension of Plate[mm] : 160 x 160 mm
Permissible ambient temperature[C] 5-40
Permissible ambient humidity 80%
Protection class acc to DIN EN60529: IP42
MR-DMS-ProNI Digital Magnetic Stirrer (plastic body)
Specification
Packing size:0.37x0.28x0.18cm
Weight:3kg
Voltage[VAC] 110/220
Frenquency[Hz] 50/60
Power[W] 5
Stirring point position quantity 1
Max. stirring quantity(H2O)[L] 2
Stirring point position quantity[mm] 30
Motor type brushless motor
Motor rating input[W] 3
Motor rating output[W] 4
Speed range[rpm] 100-1500
Speed display LCD
Speed display accuracy[rpm] 1
Material Stainless steel
Dimension of Plate[mm] f115
Dimension[mm]280x180x110
MR-MSH-Pro-2A 2-position Magnetic Stirrer
Features
Magnetic stirrer suitable for unsupervised operation, with new stir technology
Automatic judgement stirring bar displacement and capture
Hotplate with stainless steel surface
Every point independently control speed, easy-to-read backlit LCD display
Fuzzy logic control microprocessor technology guarantee maximum control accuracy
Specification
Dimension[mm] 340X240X90
Packing size:45X35X20cm
Weight[kg] 6
Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 5X2
Stirring point position quantity 2
Max. stirring quantity(H2O)[L]5
Stirring point position quantity[mm] 50
Motor type brushless motor
Motor rating input[W] 3
Motor rating output[W] 4
Speed range[rpm] 100-1500
Speed display LCD
Speed display accuracy[rpm] 1
Material Stainless steel
Permissible ambient temperature[C] 5-40
Permissible ambient humidity 80%
MR-MSH-Pro-2B 2-Position Magnetic Stirrer with Hotplate
Features
Magnetic stirrer suitable for unsupervised operation, with new stir technology
Automatic judgment stirring bar displacement and capture
Hotplate with stainless steel surface or porcelain enamel surface with excellent chemical resistance
Every point independently control speed, easy-to-read backlit LCD display
Fuzzy logic control microprocessor technology guarantee maximum control accuracy
Multiple modes ensure the stirring function not change due to external factors
With the control of safe temperature , suitable for unsupervised operation
2 adjustable safety circuits , separateness temperature sensor, protection temperature can be set
Temperature sensor for heat transfer fluid and medium available(PT100)
Warning display indicating presence of any residual heat when the unit is switched off
Specification
Dimension[mm] 340X240X90
Packing size:45X35X20cm
Weight[kg] 6
Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 500X2
Stirring point position quantity 2
Max. stirring quantity(H2O)[L] 5
Stirring point position quantity[mm] 30
Motor type brushless motor
Motor rating input[W] 3
Motor rating output[W] 4
Speed range[rpm] 100-1500
Speed display LCD
Speed display accuracy[rpm] 1
Material Stainless steel(Ceramic surface)
Heating power [W] 500X2
Heat rate(1Lwater)[K/min]6
Heating Temperature Range [C] RT-380
Temperature display LCD
Temperature display accuracy[C] 0.1
Control accuracy of heating temperature[C]1
Safety temperature[C] RT-380
Temperature sensor of extra position PT1000(Optional)
Control accuracy of heating temperature with temperature sensor [C] 0.2
MR-MSH-Pro-4A 4-position Magnetic Stirrer
Features
Magnetic stirrer suitable for unsupervised operation, with new stir technology
Automatic judgement stirring bar displacement and capture
Hotplate with stainless steel surface
Every point independently control speed, easy-to-read backlit LCD display
Fuzzy logic control microprocessor technology guarantee maximum control accuracy
Specification
Dimension[mm] 620X240X80
Packing size:72X35X20cm
Weight[kg] 8
Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 5X4
Stirring point position quantity 4
Max. stirring quantity(H2O)[L]5
Stirring point position quantity[mm] 50
Motor type brushless motor
Motor rating input[W] 3
Motor rating output[W] 4
Speed range[rpm] 100-1500
Speed display LCD
Speed display accuracy[rpm] 1
Material Stainless steel
Permissible ambient temperature[C] 5-40
Permissible ambient humidity 80%
MR-MSH-Pro-4B 4-position Magnetic Stirrer
Features
Magnetic stirrer suitable for unsupervised operation, with new stir technology
Automatic judgement stirring bar displacement and capture
Hotplate with stainless steel surface or porcelain enamel surface with excellent chemical resistance
Every point independently control speed, easy-to-read backlit LCD display
Fuzzy logic control microprocessor technology guarantee maximum control accuracy
Multiple modes ensure the stirring function not change due to external factors
With the control of safe temperature , suitable for unsupervised operation
2 adjustable safety circuits , separateness temperature sensor, protection temperature can be set
Temperature sensor for heat transfer fluid and medium available(PT100)
Warning display indicating presence of any residual heat when the unit is switched off
Specification
Dimension[mm] 620X300X100
Packing size:72X42X20cm
Weight[kg] 10
Voltage[VAC] 110/220
Frequency[Hz] 50/60
Power[W] 500X4
Stirring point position quantity 4
Max. stirring quantity(H2O)[L] 5
Stirring point position quantity[mm] 30
Motor type brushless motor
Motor rating input[W] 3
Motor rating output[W] 4
Speed range[rpm] 100-1500
Speed display LCD
Speed display accuracy[rpm] 1
Material Stainless steel(Ceramic surface)
Heating power [W] 500X4
Heat rate(1Lwater)[K/min]6c
Heating Temperature Range [C] RT-340
Temperature display LCD
Temperature display accuracy[C] 0.1
Control accuracy of heating temperature[C]1
Safety temperature[C] RT-350
Temperature sensor of extra position PT1000(Optional)
Control accuracy of heating temperature with temperature[C] 0.2
