Eddy Current Dynamometers are designed for Universal Application in all Types of Testing like for Engines, Turbines, Motors, Components and PTO testing.

THE APPLICATIONUniversal range of application for examinations on engines and engine assembliesDevelopment of Petrol & Diesel engines for cars and commercial vehiclesDevelopment and testing of engine assemblies, e.g. Pistons, Ignition systems, Sealing, Filters, Carburetor and Fuel Injection equipment, Exhaust gas ducting and catalystsQuality ControlDevelopment and Testing of Fuels and Lubricants

With the years of experience and backed by the team of industrial experts, we are able to offer a huge array of Computerized Engine Test Rigs to our clients. These Engine Test Rigs are aesthetically designed and precision-engineered for their higher functionality and durable work life. Moreover, all these Computerized Engine Test Rigs are rigidly tested on various quality parameters to deliver a flawless range at the client's end.

Kistleroffers both piezoelectric and piezoresistive sensors to measure pressure so we have the right solution for many applications. Piezoelectric pressure sensors are suitable for measuring highly dynamic, dynamic and quasi-static pressure curves or pulsations. Piezoresistive pressure sensors are suitable for measuring static and quasi-static pressure curves.
Piezoelectric Sensors: Model: 601A, 601H, 603B, 6001, 6005, 6031, 7001, 7005, 70031

• Piezoresistive Sensors: Model: 4260, 4262, 4264 & 4080
• High Pressure Sensor: Model: 6229A., 4067, 6052B.
• Engine Monitoring: Model: 6013CA, 6313CA, 6302A, 7013C., 7613C
• High Pressure Sensor, Ballistics Model: 6217
• Low Pressure Sensor, Engine Development, Inlet/ Outlet Measurement, Model: 4005A, 4043A, 4045A, 4073A, 4075A
• High pressure sensor, Engine Development, Injection, Model: 4065A, 4067A, 6229A
• High pressure sensor, Engine Development, Cylinder Pressure, Model: 6052B, 6053BB., 6057A., 6115A, 6067c, 7061B

Accurate acceleration sensors are essential when measuring vibrations that can be heard as noise or felt as oscillations in vehicles or machines (noise, vibration, harshness or NVH for short). In bridge-building and space travel too, vibration measurement is a key factor in verifying safety and cost-effectiveness. Kistler's piezoelectric acceleration sensors always keep precise track of amplitude and frequency when measuring vibrations.

Accelerometers

Low Amplitude, Low Frequency Single Axis, Model: 8310A, 8312A, 8330A etc

General Purpose Vibration Measurement, Single Axis, Model: 8202A10, 8203A50, 8274A5, 8276A5, 8704B, 8720A, 8702B, 8710A

Shock/Impact/Impulse Measurement, Single Axis, Model: 8044, 8743A, 8742A

Miniature, Light Weight, Single Axis, Model: 8614A, 8730A, 8778A

Modal Analysis & Structural Testing, Single Axis, Model: 8772A, 8632C etc

TEDS-Accelerometer, Single Axis, Model: 8704B100T, 8772A50T etc.

Low Amplitude, Low Frequency Triaxial, Model: 8393A10, 8393A2 etc

General Purpose Vibration Measurement, Triaxial, Model: 8792A500, 8793A, 8794A, 8792A100, etc

Miniature, Ultra Light Weight, Triaxial, Model: 8694M1

Modal Analysis & Structural Testing, Triaxial, Model: 8690C50, 8690C10, 8690C5 etc

Cone Penetrometer with force and displacement sensor helps determine the compaction or hardness of soil at various depths.
The force is measured using a U9C Force sensor with a range of 5 kN and depth of the penetromenter is measured with displacement transducer having a range of 200 mm.

Strain gauge technology-based pressure transducers from HBM provide reliable and trustworthy results even with highly dynamic applications at high numbers of load cycles - for minimal pressures up to 15, 000 bar.

Theinductive displacementmeasurement principle has penetrated many sectors of industry and research because it is bothrobust and maintenance-free.

For years, HBM has gained experience in the field of inductive transducer technology and has been buildinginductive displacement transducers, which can be used universally for measuring displacement in conjunction withcarrier frequency amplifiers.

The Soil Bin Test Setup has hydraulic cylinders for height adjustment of soil processing tools i.e. rotavator, leveler & roller and for the implements testing arrangement using EORT, Cone Penetromenter etc. There is hydraulic power pack and manual controls for operating the hydraulic setup.B

Thanks to their rugged design, piezoelectric quartz sensors from Kistler keep precise track of quasi-static and highly dynamic force processes, even when conditions are difficult. Our force sensors can also handle simultaneous measurements of multiple orthogonal force components.

Single Component:

Direct Force Sensor

9001A 9071A, 9101A 9104A, 9130B 9136B, 9130BA 9136BA, 9601A1, 9602A1 , 9602AA1

Force Link:

9173B 9176B, 9301B 9371B

Indirect Force Measurement (Single Component):

Measuring Pin: 9241C, 9243B, 9245B, 9247A

Strain Sensor: 9232A, 9233B, 9234A, 9235B

Multi Component:

Direct Force Sensor: 9017B, 9047B, 9067, 9067B, 9077B, 9251A, 9601A2, 9601A3

Force Link:

9317B, 9327A, 9347B, 9367B & 9377B

Cutting Force Dynamometer:

9272, 9255C, 9257B, 9129A, 9129AA etc, sensors for dynamic and quasi-static measuring of the three orthogonal components of a force, measuring of cutting forces during turning, milling and grinding
