The motorized model Hydraulic Control Hacksaw Machine is equipped with feed control device, automatic lifting and lowering arrangement of saw frame with mechanical coolant pump, vice and machine belt guard. We offer Hydraulic Control Hacksaw Machine with HP AC Electric motor, on-off Starter, and V belts. The Hydraulic Control Hacksaw Machine is available in different capacities from 175 mm round bar up to 600 mm round bar cutting capacity. We supply higher capacity machines with double cylinder Hydraulic system. We are ranked among the topmost Hydraulic Power Hacksaw Machine Suppliers, offering products at affordable prices.
Features
Standard Accessories
Optional Accessories
» Specifications
| Model | HHM - 175 | CGM - 250 | CGM - 300 | CGM - 400 | CGM - 500 | CGM - 600 |
| Capacity - round bar up to (mm) | 175 | 250 | 300 | 400 | 500 | 600 |
| Capacity - square bar up to (mm) | 150 | 200 | 250 | 325 | 400 | 500 |
| Stroke (mm): | 140 | 140 | 140 | 140 | 150 | 150 |
| Strokes per minute | 100 & 120 | 85 &100 | 85 & 100 | 85 & 100 | 60 & 100 | 60 & 85 |
| Motor (HP) | 1 | 1.5 | 2 | 3 | 5 | 5 |
| Blade Size (mm) | 365 or 406 | 406 or 457 | 457 or 508 | 559 or 610 | 710 or 762 | 813 or 906 |
| Net / Gross Weight (kgs.) | 300 / 400 | 450 / 550 | 500 / 600 | 650 / 700 | 850 / 1050 | 975 / 1200 |
| Dimensions (m) | 1.1 x 0.8 x 1.0 | 1.1 x 0.8 x 1.0 | 1.1 x 0.8 x 1.3 | 1.4 x 0.9 x 1.6 | 1.6 x 1.0 x 2.3 | 1.7 x 1.0 x 2.5 |
| Shipping Volume (m3) | 0.88 | 0.88 | 1.14 | 2 | 3.68 | 4.25 |
