general information | |
order code | lt-200whbl-petra |
make | lightronix technology |
country of origin | india |
lighting source & type | smd 5050 led |
number of led | 40 |
optical parameters | |
led beam angle | 120 degree |
cri (color rendering index) | >80 |
led life span | >60000 hours |
color | white/warm white/cool white (as per order) |
color temperature | 2700-6500k(as per order) |
led voltage/current | 6.2v/750ma |
led make | bridge lux/osram (as per requirement) |
optical lens | na |
luminous efficiency | 170 lm/w |
total lumens | 34000(±5%) |
optical efficiency | >93% |
thermal efficiency | >90% |
electrical parameters | |
wide input voltage range | 90-310vac(with auto cutoff) |
operating frequency | 50/60hz |
power consumption | 200 watt |
power factor | >0.95 |
thd | 90% |
supply phase | single phase supply |
over voltage protection | 440vac protection |
under voltage protection | 90vac |
auto cutoff voltage | lower side310vac |
pcb information | |
pcb thickness | 1.6mm(±5% tolerance) |
pcb material | pure aluminum-copper |
copper layer thickness | standard 0.35 micron |
copper conductivity | >1 watt |
pcb size | 250x250 mm |
mechanical parameters | |
housing material | aluminum pressure die casting |
housing color type | metal powder coated |
housing shape | round |
total luminaries weight | 5.1 kg |
luminaries size | diameter - 370 mm height – 190 mm |
mounting device | bracket |
mounting style | ceiling/roof/hanging |
glass type | 4mm toughened glass |
cable entry option | pg7 cable gland with rubber washer |
screw type | stainless steel screw |
gasket type | silicone rubber gasket |
ip rating | ip65/ip66 |
impact rating | ik08/ik10 |
marking type | laser marking/engraving |
