LOW PIM termination load 4.3-10 male DC - 3GHz 50 ohm 10WÂ RF Coaxial fixed AttenuatorsÂ
Â
Coaxial fixed attenuators are used in absorbing energy of transmission line, expanding power range and controlling power level, they are also used in accurately measuring power or spectrum of RF microwave transmitters accompany with small power meter, comprehensive tester or spectrum analyzer.
DTS serial coaxial fixed attenuators' average power 10W-10KW, frequency range DC-26.5GHz and feature wide frequency band, low VSWR, flatness attenuation value, excellent capacity in anti-pulse and anti-burnout.
Â
Specification for attenuator:
All the specification could be changed as your enquirements.
we could offer RF attenuators with frequency 0-3GHz, and we could offer 5W-200W
Â
1. Specification
Â
Frequency Range(MHz) | 698~2700 |
VSWR | ≤1.25 |
PIM(dBc) | ≤-150@2×+43dBm |
Impedance(Ω) | 50 |
Power Handling(W) | 10,Avg |
Connector | 4.3-10,Male/Female |
Operating Temperature(℃) | -40~+60 |
Sealing | Indoor |
Size(mm) | 150×40 (Excluding Connector & Handle) |
Weight(kg) | 0.8 |
