40km Optical Fiber Media Converter, Brand Name : GRT

₹ 9,050 / Piece

MOQ1 Piece(s)
Brand NameGRT
Total Carbohydrate3 years
Distance40km
Wavelength1310nm/1550nm
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Company Information

Beijing Guang Run Tong Technology Development Co.Ltd

Member Since 8 Years
Nature of Business Supplier
Year of Establishment 2008

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Brand NameGRT
Total Carbohydrate3 years
Distance40km
Wavelength1310nm/1550nm
Country of OriginBeijing
Sensitivity:≤-24dBm
Data rate:0/100/1000M 1.25G
Interface:SC fiber media converter
Model NumberW8100G-40F-3S fiber media converter
Optical Output Power:-5~0dBm
Port:1*RJ45, 1*SC fiber media converter

101001000base-t single fiber 1310 1550nm sc 40km optical fiber media converter
1. Introduction
w8100g-40f-3s5s is a reliable and cost-effective 101001000m single fiber bidirectional media converter with one sc connector and one rj45 port. It can realize the conversion of 10m100m1000m ethernet copper interface and optical interface effectively. This device operates on singlemode 1310nm and 1550nm in a pair, can reach up to 40km.
various types of fiber media converter are available: 10100m, 10100100m, single modemulti mode, single fiberdual fiber, built-in power supply, external power supply, plug type frame type
protocols:
ieee802.1q
ieee802.3x
ieee802.1d
101001000m fiber media converter
parameters external power supply internal power supply
protocols ieee802.1q, ieee802.3x, ieee802.1d
interface copper rj45: 10100100m
fiber: 1×9sfpfcsc
converting method store and forward
packet forwarding 16000bytes
lfp(failover) support
time delay store and forward:9.6us
mtbf 65,000hour
power supply input: ac90-264v, dc100-380v, output: dc5v 1a input: ac90-264v, dc100-380v
power consumption
