Alpha Series Manual Monitors

Alpha series manual monitors are economical and yet rugged manual monitors suitable for many fixed applications.
With rugged, corrosion resistant brass construction, the Alpha-E monitor flows up to 1,250 gpm (4,732 Lpm). Yet it is compact - just 16” (406 mm) in height without nozzle and approximately 58 lbs (26 Kg).
It features a 3” NPT female outlet and a choice of 3” or 4” 150 lb ANSI flange.
The tiller bar controls vertical movement 90° above and 45° below horizontal.
The monitor has a full, continuous 360° rotation with rugged, stainless steel lock hardware. Brass balls are used in all swivel joints with grease fittings for easy lubrication. The monitor comes with durable acrylic urethane finish.
