TGSS : Bimetallic Temperature Gauge

Get Latest Price

Number Of Flower Bimetallic
Range -50 to 600°C
Wetted Parts SS316
CaseSS304
Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

Omicron Sensing Pvt Ltd

Kalbadevi, Mumbai, Maharashtra

View Number

Member Since 10 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Number Of Flower Bimetallic
Dial Size 2.5" - 6"
Range -50 to 600°C
CaseSS304
Capillary NIL
Wetted Parts SS316

Food & beverage, pharmaceutical, cryogenics, chemical & petrochemical industries, conventional & nuclear power Plants, pumps, hydro-cleaning machines, presses, engine Compressors, turbines, diesel engines & refrigerating plants.

Special Features :

	Stainless steel case & stem
	Bottom / Back / Every Angle Entry
	Standard Followed: EN 13190

Standard Version: 63mm, 100mm, 150mm

	Accuracy	: Class 1 as per EN 13190
	Ambient temperature	: - 25 ^oC to + 65 ^oC
	Process pressure	: 15 kg/cm² (Without Thermowell)
	Over Range Limit	: 115% of the Scale Value or 600 ^oC, whichever is minimum
	Stem Diameter	: 6mm / 8mm / 10mm / 12mm
	Stem Length	Refer Scale Table

	Case	: AISI 304 SS
	Ring	: AISI 304 SS, Bayonet Lock
	Stem	: AISI 316 SS
	Connecion	: AISI 316 SS
	Sensing Element	: Bi-metal strip coiled
	Joints	: Tig Argon Arc Welding

	Protection	: IP 65
	Dial	: Aluminium, black graduation on white background
	Pointer	: Aluminium, black coloured fixed pointer
	Window	: Sheet Glass
	Gasket	: Neoprene
