SALIENT FEATURES:
1. Dynamic and state-of-the-art machine design
2. Anti-theft fully enclosed type engine compartment
3. Road safety and yellow beacon lights for safety purposes
4. Long durability and reliability
5. Ergonomics design for operator for easy to use.
6. Low fuel consumption and high work productivity
7. Economy maintenance and operation cost
8. Automatic dust separation filter cleaning system powered by PLC
9. Cleaning area 16000 sq. meter per hour
10. Water sprinkle system at rear and each on the top of side brush. (Optional)
| Sweeping Path | 8feet. feet with duel side rotary brushes |
| Sweeping Speed | 0 To 10 Km/hr. Depending on road conditions |
| Power Source | 76 hp/ . water-cooled Diesel engine with all controls on Control panel |
| Diesel Consumption | 6-7 Liters/ hr./ depending on engine hp. |
| Wheels | 7.50*16 two numbers CEAT /MRF |
| Axle | Single axle |
| Suction Blower | High performance multi bladed dynamically balanced vacuum fan at 2000 RMP /1800RMP driven with four V-Belts. Mound on two double Spherical Bearings at 2200 RPM approx. |
| Suction Nozzles | 2 suction nozzles for picking the dust and other material from Road heaving remote control operated openings for large objects Capable of lifting stones upto 35mm,leaves,sand &other Material from road. |
| Sweeping Brushes | One horizontal brush 2100mm long for wide sweeping made have Nylon bristles. Two rotary brushes 440 mm on each side made of Special steel bristles for sweeping debris along the footpath and Central verge. All Brushes are driven directly by hydraulic motors |
| Debris Hopper | Hopper capacity 4 Cu Mt.. Anti Rust Paint inside the Hopper and paint outside of machine. Unloading of waste material by hydraulically tipping controlled Form the control panel (payload depends on the material) |
| Hydraulic System | Purpose: powers hydraulic sweeping system and hopper cylinder. Reservoir capacity 55 Lt. Hydraulic pump belt driven with protection relief valve Control Valve-Solenoid Operated form the control panel. Filtration system 10 micron |
| Water Sprinkle System | Provided at the rear of machine to sprinkle water on the swept path. Water tank capacity 300 Liters. |
| Air Filter System | PLC Controlled air pulse jet filter cleaning system |
| Sweeping Controls | Auxiliary Engine, all sweeping and unloading controls are Provided on control panel. Brushes up down and on off is controlled from the tractor with the help of a remote control |
| Transmission | Machine can be trailed with any tractor |
| Turning Radius | 24 feet With tractor |
| Wondering Hose | A 12 feet long flexible suction hose 5inch. Diameter with nozzle is Provided at the rear of machine for manual cleaning in areas where the machine cannot reach. (This wondering hose can be extended up to 50 feet or so.) This wondering hose is capable of sucking loose material from plant roots |
| TECHNICAL SPECIFICATION CAN BE CHANGED AS PER CAPACITY |
