Advanced Technocracy Inc. is Manufacturer, Exporter & Supplier of Closed Circuit Kaplan Turbine Test Rig.
Type : Axial Flow Reaction Turbine
Capacity : 5 HP
Rated Speed : 1500RPM
Discharge Capacity : 4500 LitersMinute
Supply Head : 7 Meters
Guide Vanes : Gun Metal Vanes (Aerofoil Blade Shaped)
B. Loading :Rope Brake
Material :Cast Iron
Drum Size :300 mm diameter
C. Supply Pump Set
Size : 10 X 10
Discharge : 5000 LitersMinute
Total Head : 8 Meters
Motor Capacity : 20 HP
Starter for Motor : Star Delta Crompton Make
D. Flow Measurement
Material : C.I Body
Manometer Fluid : Mercury
E. Pressure Measurement Pressure & Vacuum gauge
F. RPM Indicator : Digital
G. Sump Tank:
Material of Constructio : MS Powder Coating M.S. FRP LiningS.S Unit
Service Required : Electrical supply-7.5 HP, 3Phase, 440 Volts, 50HZ AC Supply
