Metal Cone Pulley Pillar Drill Special Model

As improvements are constantly made in our machines the above specifications and dimensions are subject to modify without any prior notice

Company Information

Ask for more detail from the seller

Report incorrect details

“SHREE” Brand Cone Pulley Pillar Drill Special Model
Specification	CPPD25SP
Capacity
Drilling capacity	25 mm
Spindle
Spindle Travel	180 mm
Spindle Tapper	MT3
No. of Spindle Speed	8
Spindle Speed Range (RPM)	130 to 2600
Working Range
Pillar Diameter	92 mm
Pillar Length	1410 mm
Distance from spindle centre to pillar surface (max)	250 mm
Spindle nose to table distance	660 mm
Distance from spindle nose to base distance	1045 mm
Table travel	480 mm
Table size	330 x 330 mm
Base Size	370 x 580 mm
Motor Belt (V – Belt Nos. 1)	B – 52
Electricals
Electric Motor (HP / RPM)	1 / 1440
Machine Dimension & Weight (Approx.)
Length x Width	850 x 450 mm
Height	1770 mm
Weight	225 kg.
