Dynemech Anti Vibration Precision Metrology Table ,for Surfcom 480A-14 P 64

1. Granite base of size L 1100 X B 550 X T 50 mm
2. 60 mm Tubular Structure with cross member to suit 1000 X 450 X 80 mm Granite Base
3. Wrap Around Construction
4. Front pivot jointed heavy duty links with extended horizontal connecting profile and vertical 45 X 45 connecting profile. At top end another horizontal 90 X 45 profile connection with needle thrust bearing supported swiveling assembly with tray to suit display unit with clamping lever at bottom (newly introduced!).
5. 65 X 65 mm AV pads at 9 places
6. 4 No’s DLP3 (AV disc with adjustable screws) at Ground Level
7. 4 No’s – 3” Wheel
8. Drawing Pouch L.H Side and front double door with handles and lock
9. Leveling Ball, Spanner 24/27
10. Powder Coat, structure RAL 9002, side sheets and doors – graphite gray
11. Instrument sticker
12. Overall dimensions: L 1120 X B 570 X H 730 (over granite base) mm
13. Weight: kg
14. Execution in wooden box

Note- GST and Freight Charges are not included.
