Brass Earth Clamp Blue All Conditions Cap

₹ 48 - ₹ 55 / piece

MOQ10000 Piece
MaterialBrass
CertificationISI Certified, ISO 9001:2008 Certified
ApplicationThe Safety Electrical Connection Clamp is designed for reliable and secure earthing/grounding
SizePipe Diameter 12mm – 32mm, 32mm – 50mm,50mm – 75mm
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Company Information

5.0/5

Member Since 5 Years
Nature of Business Exporter
GST No. 24AALFD3133A1Z4

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

ApplicationThe Safety Electrical Connection Clamp is designed for reliable and secure earthing/grounding
CertificationISI Certified, ISO 9001:2008 Certified
MaterialBrass
Number Of FlowerEarth Clamps, Earthing Accessories
Country of OriginIndia
SizePipe Diameter 12mm – 32mm, 32mm – 50mm,50mm – 75mm
AvailabilityYes
GradeBS316
ShapeCustomized
ConnectionFemale, Male
AccessoriesEarthing Electrode Pipe
SurfaceCoated

Code No	Pipe Diameter	Strip Length
EC-14/1	12mm to 32mm	150mm
EC-14/2	32mm to 50mm	220mm
EC-14/3	50mm to 75mm	330mm
EC-15/1	12mm to 32mm	150mm
EC-15/2	32mm to 50mm	220mm
EC-15/3	50mm to 75mm	330mm

Application:

High performance earth clamp is widely used to connect the pipes to conductor for earthing.

Available in three colours - Red for non-corrosive dry atmospheres, Blue or Green for corrosive or humid conditions.Available in three standard band lengths.

Characteristics:

· Clamp Material:	Brass Or Bronze
· Tape Material:	Stainless steel 304
· Screw Material:	Brass
· Label Material:	Aluminum (White/Green/Blue/Red)
· Plating Material:	Nickel Plated
· Standard:	BS-951
· Terminal Sections:	A-D 2.5 – 10mm²
· Mounting:	For indoor & outdoor use only
