| Model | Specification | Unit | CNC500 | CNC500 | CNC500 | CNC560 |
|---|---|---|---|---|---|---|
| Capacity | Swing Over Bed | mm | 500 | 500 | 500 | 560 |
| Swing Over Cross Slide | mm | 270 | 270 | 270 | 300z | |
| Distance Between Centers (mm) | mm | 1000/1500/2000 | 1000/1500/2000 | 1000/1500/2000 | 1000/1500/2000 | |
| Guideway width (mm) | mm | 400 | 400 | 400 | 460 | |
| Max. Load Capacity | T | 1 | 1 | 1 | 2 | |
| Spindle | Spindle Bore | mm | 82 | 105 | 160 | 82 |
| Spindle Bore Taper | - | Metric Ø 90/MT5 | - | - | Metric Ø 90/MT5 | |
| Spindle Nose Type | - | C8 | - | - | C8 | |
| Spindle Speed Steps | - | 3 steps | 3 steps | 3 steps | 3 steps | |
| Spindle Speed Range | rpm | 80-1500 | 80-1000 | 80-800 | 80-1500 | |
| Chuck | mm | Ø 250 3-jaw manual | Ø 320 3-jaw manual | Ø 400 3-jaw manual | Ø 250 3-jaw manual | |
| Turret | Turret/Tool Post | - | NC Turret 4 Position | NC Turret 4 Position | NC Turret 4 Position | NC Turret 4 Position |
| Tool Shank Size | mm | 25x25 | 25x25 | 25x25 | 25x25 | |
| Feed | X Axis Travel | mm | 270 | 270 | 270 | 320 |
| Z Axis Travel | mm | 850/1350/1850 | 850/1350/1850 | 850/1350/1850 | 850/1350/1850 | |
| X Axis Rapid Traverse | mm/min | 4000 | 4000 | 4000 | 6000 | |
| Z Axis Rapid Traverse | mm/min | 6000 | 6000 | 6000 | 8000 | |
| Tailstock | Tailstock Quill Diameter | mm | Ø 75 | Ø 75 | Ø 75 | Ø 75 |
| Tailstock Quill Taper | - | MT5 | MT5 | MT5 | MT5 | |
| Tailstock Quill Travel | mm | 150 | 150 | 150 | 150 | |
| Motor | Main Spindle Motor | kw | 7.5 | 7.5 | 7.5 | 7.5 |
| Coolant Pump Motor | kw | 0.125 | 0.125 | 0.125 | 0.125 | |
| Dimension | Width x Height | mm | 1600 x 1600 | 1650 x 1700 | 1650 x 1700 | 1750 x 1850 |
