STANDARD ACC.: FACE PLATE, CHUCK PLATE, CENTER ADAPTER 2 NOS., DEAD CENTER, TOOL POST KEY, CHANGE GEAR SET OF (INCH & MM) STEADY REST, MOTOR PULLEYEXTRA STANDARD & ELECTRICAL ACC: FOLLOW REST, CHUCK, ELE. MOTOR, NYLONE BELT, RE. SWITCH, MOTOR V-BELT
| LENGTH OF BED | 1675 MM (5' 6") | 2135 MM (7') | 2745 MM (9') | 3045 MM (10') | 3660 MM (12') |
| MAX A.B. CENTER | 508 MM (20") | 965 MM (38") | 1575 MM (62") | 1880 MM (74") | 2490 MM (98") |
| MAX. SWING OVER BED. | 455 MM (18") | 455 MM (18") | 455 MM (18") | 455 MM (18") | 455 MM (18") |
| MAX SWING WITHOUT GAP. | 760 MM (30") | 760 MM (30") | 760 MM (30") | 760 MM (30") | 760 MM (30") |
| MAX SWING OVER CROSS SLIDE | 280 MM (11") | 280 MM (11") | 280 MM (11") | 280 MM (11") | 280 MM (11') |
| HEIGHT OF CENTER OVER FLATE BED WAYS | 254 MM (10") | 254 MM (10") | 254 MM (10") | 254 MM (10") | 254 MM (10") |
| WIDTH OF BED | 324 MM (12.3/4") | 324 MM (12.3/4") | 324 MM (12.3/4") | 324 MM (12.3/4") | 324 MM (12.3/4") |
| WIDTH OF GAP IN FRONT OF FACE PLATE | 178 MM (7") | 178 MM (7") | 178 MM (7") | 178 MM (7") | 178 MM (7") |
| SPINDLE HOLE | 54 MM (2.1/8") | 54 MM (2.1/8") | 54 MM (2.1/8") | 54 MM (2.1/8") | 54 MM (2.1/8") |
| NO. OF SPINDLE SPEEDS | 8 (25 TO 500 RPM) | 8 (25 TO 500 RPM) | 8 (25 TO 500 RPM) | 8 (25 TO 500 RPM) | 8 (25 TO 500 RPM) |
| LEAD SCREW DIA. & PITCH | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI |
| TAPPER OF CENTER IN HEAD AND T.S. | MT.- 4 | MT.- 4 | MT.- 4 | MT.- 4 | MT.- 4 |
| NO. OF METRIC THREADS AND RANGE | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 |
| LEAD SCREW DIA. & PITCH | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI | 38 MM (1.1/2") 4 TPI |
| TAPPER OF CENTER IN HEAD AND T.S. | MT. - 4 | MT. - 4 | MT. - 4 | MT. - 4 | MT. - 4 |
| NO. OF METRIC THREADS AND RANGE | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 | (1 TO 6 MM PITCH) 13 |
| NO. OF INCH THREADS & RANGE | (2 TO 24 TPI) 19 | (2 TO 24 TPI) 19 | (2 TO 24 TPI) 19 | (2 TO 24 TPI) 19 | (2 TO 24 TPI) 19 |
| FLATE BELT SIZE | 50 MM × 2 MTR. | 50 MM × 2 MTR. | 50 MM × 2 MTR. | 50 MM × 2 MTR. | 50 MM × 2 MTR. |
| POWER OF AC MOTOR 3 P.H. (1440 RPM) | 2 HP. | 2 HP. | 2 HP. | 2 HP. | 2 HP. |
| APPROX WEIGHT IN KG. | 1100 KG. | 1100 KG. | 1100 KG. | 1100 KG. | 1100 KG. |
