Contact SupplierHONDA ENGINE GX 160
| Product Code | GX160 |
| Product Type | General Purpose Engine |
| Engine Type | 4-stroke single cylinder, OHV petrol engine, 25inclined cylinder, Horizontal shaft |
| Cylinder Sleeve Type | Cast iron sleeve |
| Bore X Stroke | 68 x 45 mm |
| Displacement | 163 cm |
| Compression Ratio | 9.0 : 1 |
| Net Power | 3.6 kW ( 4.8 HP ) / 3600 rpm |
| Cont Rated Power | 2.5 kW ( 3.4 HP ) / 3000 rpm, 2.9 kW ( 3.9 HP ) / 3600 rpm |
| Max. Net Torque | 10.3 Nm / 1.05 kgfm / 2500 rpm |
| Ignition System | Transistorised |
| Starter | Recoil (el. start optional) |
| Fuel Tank Capacity | 3.1 Liter |
| Fuel Cons. At Cont. Rated Power | 1.4 L/h – 3600 rpm |
| Engine Oil Capacity | 0.6 Liter |
| Dimensions (L X W X H) | 312 x 362 x 346 mm |
| Dry Weight | 15.1 kg |
