Metrologic/Honeywell MS9540 Handheld Label Scanner

Features Benefits
Automatic trigger Use scanner as either a hand-held device or a fixed presentation scanner when mounted in
the stand
CodeGate® data transmission Ideal for menu-scanning applications and when combined with the Auto-Trigger, VoyagerCG® is the most intuitive bar code scanning system in the industry
650-nanometer laser Equipped with a high-visibility laser allowing the user to place the line on bar code
FlashROM Update firmware from any PC via MetroSet®2 software provided free from Metrologic
Parsing (data editing) Bar code data can be formatted to meet the requirements of host system
Quick Specs
Depth of Field: 0 mm - 203 mm (0 - 8) for 0.33 mm (13 mil) bar codes
Width of Field: 64 mm (2.5) @ face; 249 mm (9.8) @ 203 mm (8)
Scan Speed: 72 ± 2 scan lines per second
Minimum Bar Width: 0.127 mm (5 mil)
System Interfaces: PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, IBM 468X/469X, Stand Alone Keyboard, USB
Light Source: Visible Laser Diode 650 nm ± 10 nm
