| Model | YLH-20T/YLH-30T/YLH-50T | YLH-20Z/YLH-30Z/YLH-50Z |
|---|---|---|
| Laser Source | Raycus | Raycus |
| Laser Type | Fiber | Fiber |
| Power | 20W/30W/50W | 20W/30W/50W |
| Work Precision | ±0.01mm | ±0.01mm |
| Software | EZCAD 2.12 Professional | EZCAD 2.12 Professional |
| Cooling | Air Cooled | Air Cooled |
| Power Consumption | d"500W | d"500W |
| Work Area | 110x110mm | 110x110mm/175x175mm |
| Maximum Marking Speed | 10000mm/s | 10000mm/s |
| Min Character | 0.15mm X 0.15mm | 0.2mm X 0.2mm |
| Marking Depth | 0.01-1.0mm (Subject to Material) | 0.01-1.0mm (Subject to Material) |
| Wavelength | 1064mm | 1064mm |
| Laser Module Life | 1,00,000 Hours | 1,00,000 Hours |
| Laser Repetition Frequency | 20KHz-80KHz (Adjustable) | 20KHz-80KHz (Adjustable) |
| Power Requirement | AC 220V/50Hz/2A | AC 220V/50Hz/2A |
| Optimum Working Temperature | 10-35° C | 13-28° C |
| Support Format | PLT, DST, AI, DXF, BMP, JPG, CAD, CDR, DWG,PCX | PLT, DST, AI, DXF, BMP, JPG, CAD, CDR, DWG,PCX |
