RFID Card Reader Tripod Turnstile

We are offering rfid card reader tripod turnstile
tripod turnstile main functions:
(1)tripod turnstile easy to install, use and maintain.
(2)tripod turnstile direction can be set as single-direction or bi-direction.
(3) arms auto drop when power off, complying with fire safety requirements.
(4)tripod turnstile can be integrated with magnetic card, barcode scanner, counter,
swallow card machine, token accepter, and fingerprint machine and so on by
standard electrical interface.
Rfid card reader tripod turnstile
tripod turnstile specifications sheet:
item: description:
framework: 304 (standard).
Thickness of ply: 1.2mm (standard).
Dimensions: (l)1200* (w)280 *(h)990 (mm)
finishing: brushed (standard) fingerprint processing
pass width: ≤510mm (can be customized))
weight: 55kg
operation direction: single direction bi-direction
power voltage: ac220v +- 10v 50hz
ac110v +- 10v 60hz
work environment: indoor outdoor
pass rate: 35person minute
power consumption: 20w24v
operating temp.: -15℃ ~ 60℃
operating humidity: 0 ~ 95% without concretion
emergency: automatic arm drop down
input: 12v dry contact
rfid card reader tripod turnstile
tripod turnstile specific function:
(1) electromagnet lock, photoelectric unlock, long service life, high operation
dependability and fast response.
(2) the whole system runs smoothly, low noise, no mechanical impact.
(3) tripod turnstile self-test function, when power on, system restoration automatic.
(4) tripod turnstile working modes selectable: bi-direction card reading;
one direction cards reading and another no reading; one direction card reading and
another freely. Working modes can be set in the control panel.
(5) when power off, tripod turnstile arms will drop automatically, to meet the
special needs of users and fire safety requirements. While power on later, arm should be lift by hand.
