Stainless Steel Reinforcement Bar

Supply TypeManufacturer, Exporter, Supplier, Retailer
Preferred Buyer Location All over the world

Elongation : Aj = 100 mm marked before tension measured after tension to fracture measuring point 2.5 x diameter from fracture. A10 = Diameter x 10 marked before tension measured after tension....

View More Details

Send Enquiry

Company Information

Raajratna Metal Industries Limited

Usmanpura, Ahmedabad, Gujarat

View Number

Member Since 12 Years
Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

Elongation :

Aj = 100 mm marked before tension measured after tension to fracture measuring point 2.5 x diameter from fracture.

A10 = Diameter x 10 marked before tension measured after tension to frature measured across fracture.

Approval:

We can also supply Stainless Steel rebars/coils as per ASTM A 955 / 1259 & EN standards.

We are applying for German approved for Stainless steel rebars / Coils as per DIN 488 standard.

The grade of reinforcement steel will depend upon type of corrosive atmosphere

For moderate atmosphere high yield reinforcement steel like 1.4301 (304) can be used.

For more severe corrosive atmospheres 1.4401 (316), 1.4429 (316LN), 1.4436 (316) & 1.457 ( 316Ti) can be used.

For high aggressive atmospheres duplex steel 1.4362, 1.4462 (2205) is recommended.

GRADE	Size In MM	Tensile Strength N/MM	Yield Strength N/MM	% Elongation A5	T.S./ 0.2 % Yield
1.4301 – 304	3 – 16	≥600	≥500	14	1.10
1.4401 – 316	3 – 16	≥600	≥500	14	1.10
1.4429 – 316LN	3 – 16	≥600	≥500	14	1.10
1.4436 – 316	3 – 16	≥600	≥500	14	1.10
1.4571 – 316Ti	3 – 16	≥600	≥500	14	1.10
1.4362 [Duplex]	3 – 16	≥800	≥600	14	1.10
1.4462 [Duplex]	3 – 16	≥800	≥600	14	1.10
1.4301 – 304	16 -25	≥600	≥500	14	1.10
1.4401 – 316	16 -25	≥600	≥500	14	1.10
1.4571 – 316Ti	16 -25	≥600	≥500	14	1.10
1.4462 [Duplex]	16 -25	≥700	≥500	14	1.10
1.4301 – 304	16 -50	≥600	≥500	14	1.10
1.4401 – 316	16 -50	≥600	≥500	14	1.10
1.4429 – 316LN	16 -50	≥600	≥500	14	1.10
1.4436-316	16 -50	≥600	≥500	14	1.10
1.4571 – 316Ti	16 -50	≥600	≥500	14	1.10
1.4362 [Duplex]	16 -50	≥600	≥500	14	1.10
1.4462 [Duplex]	16 -50	≥600	≥500	14
