Surveillance Camera, IP Camera, Brand Name : EasyN

We are offering smart home surveillance cameras wifi cctv security sim card 3g ip camera.
features:
1.image sensor:1/4 inch ov9712 cmos image sensor
2.pixel:megapixel
3.resolution:wxga:1280(h)×720(v)
4.filter switch:auto-switch automatically, without color cast
5.nightvision:3φ13 led lights, ir distance: 10 m
specifications:
model:h8-g10d
3g network parameters (china unicom 3g standard) h8-w-g10d
3g network standard
hsupa/hsdpa/wcdma/edge/gprs/gsm
frequency
gsm/edge:900/1800/850/1900mhz
wcdma:2100/850/1900mhz
transmission rate
hsupa:downstream rate 7.2mbps upstream rate 5.76mbps
hsdpa:downstream rate 7.2mbps upstream rate 384kbps
wcdma:downstream rate 384kbps upstream rate 384kbps
3g video transmission channel
video phone channel(cs)
network flow channel(ps)
call filter and authentication
support password authentication
sms
support sms sending
signal strength detection
support
operators parameter configuration
auto / manual
3g network parameters (china telecom 3g standard) h8-e-g10d
3g network standard
cdma2000 1xevdo
standard
evdo:800/1900mhz
transmission rate
hsdpa: upstream rate 3.1mbps downstream rate 1.8mbps
3g video transmission channel
network flow channel(ps)
call filter and authentication
support password authentication
sms
support sms sending
signal strength detection
support
operators parameter configuration
auto / manual
3g network parameters (china mobile 3g standard) h8-t-g10d
3g network standard
td-hspa/td-hsdpa/td-scdma/edge
frequency
td-scdma:
2010-2025/1880-1920mhz
gsm/gprs/edge 900/1800mhz
transmission rate
td-hspa: downstream rate 2.8mbps upstream rate 2.2mbps
td-hsdpa: downstream rate 2.8mbps upstream rate 384kbps
3g video transmission channel
td-hspa/td-hsdpa/td-scdma/edge
call filter and authentication
support, password authentication
sms
support sms sending
signal strength detection
support
operators parameter configuration
auto / manual
video parameters
image sensor
1/4 inch ov9712 cmos image sensor
pixel
megapixel
resolution
wxga:1280(h)×720(v)
filter switch
auto-switch automatically, without color cast
nightvision
3φ13 led lights, ir distance: 10 m
automatic diaphragm
support
lens characteristics
fixed focal:3.6mm/f1.2
lux
0.1lux/f1.2
snr
≥48db
gain control
auto
wb
auto
electronic shutter
auto
compression standard
h.264 baseline profile 3.1
compression resolution
720p(1280×720)/vga(640×480)/qvga(320×240)
frame rate
main stream maximum frame rate 30fps,time stream fixed 10fps
code rate
64k~2mbps code rate adjustable,can set grade or self-adaptable
ptz
motor
built-in motor control
rotation angle
horizontal: 355° vertical: 80°
audio
compression standard
amr
code rate
12.2kbps
input
one channel,3.5mm jack line in
built-in high sensitivity mic,distance 5m
output
1 channel,3.5mm jack speak out
video
file format
avi file format
storage
interior tf card, file system fat,max 32gb,standard configuration 4gb tf card
external usb hard disk,file system fat32,max 2tb
prefer using external usb hard disk storage
automatic cover
when available storage space is less than 10%(adjustable),automatic delete history video files
24 hours or timing video
support,can set week and time quantum plan, can save video files as every 10 minutes, 15 minutes, 30 minutes and 60 minutes
manual
support,terminal control the open video and end video, record time can be prolong
alarm
support, advance record live video 5 s before the alarm trigger
search
support,according to time, type to search video files
online browse
support, terminal software online browsing video files,can playback,key frame browse,drag time axis,suspend ,etc.
management
support,terminal software download,batch remove,a key to remove the video files
alarm
mobile detection
support,high, medium and low level 3 sensitivity settings
sms alarm
support
3g visual telephone
support
platform
support iphone delivery alarm
video
support
others
lan
10baset/100basetx ethernet,rj45 interface
protocol
http,ntp,vif,dns,dhcp,upnp
wifi
wi-fi 802.11g/n
infrared compensation
built-in ir light, distance 5 ~ 10 meters
led indicator light
red & blue indicator light,system light(red)and network light(blue)
red light slow flash, system operate normally
red light flash three times and blue light flash once,shows 3g network connects normally.
red and blue light flash alternately,shows users are monitoring or upgrading firmware, restoring to the factory settings,should prohibit the interruption of power supply.
reset
press on the reset button for 15s continuously to restore to the factory default settings.
wifi model switch
switch between ap and sta mode,about 5s it takes effect.
sim card socket
support,standard usim card
date & time
rtc real-time clock,support ntp network time calibration and system time remote settings
watchdog
software and firmware watchdog double protection
power supply
5v dc 2a
power consumption
less than 5w
use environment
temperature -10°c~+55°c,humidity 10%~90%
size
item size:120 x 120 x 130mm (l*w*h)
package size:170 x170 x 170mm (l*w*h)
weight
item weight:340g (note: for real products)
package weight:700g
accessories
power adapter, cd, manual, bracket, screws, antenna
material
plastic
installation
indoors, ceiling or hanging
