Frequency0.2MHz to 1MHz b) 0.5MHz to 4MHz c) 0.8MHz-8MHz,2 MHz to 20MHz
Dimension (mm)170x260x110mm (HxWxD)
Temperature (deg. Celsius)0-50 Degree C
Test Range2.5mm to 10 meter (0.100 in to 400 in) (longitudinal waves in steel)
DelayVariable from -10 to 2000mm (-0.3 to 30 inches).
FeaturesIt has TCG (Time Controlled Gain) which compensates for amplitude decay with distance. A very useful feature, Dynamic DAC curves which allow change of Test Range and Gain after plotting them
Weight (kg)2.1kg With Battery
RecordingFree run or with positional encoder for actual location
