obot carries 6 parts from molding machine and then loads them on the automation cell. The part present sensor verifies that parts are seated on the nest.

This manufacturing workstation consists of multi-axis part handling system for precision manufacturing processes. It also has safe-view window and sliding door.

Operator safety work station with automatic sliding door and 2 anti-tie down opto switches. Also includes integrated power-supply, Nitrogen assist for burr-free cutting.

MI -Touch screen with menu driven screen for all aspects of machine operation and diagnostic functions. All screens are customized for user friendliness and best performance.

ully automated system with auto-load, pad printing, drying, sonic welding, and final inspection. Good & bad parts are unloaded at 2 separate stations. Capacity: 15, 000 partsday.

Precision X-Y table with 30” x 72” travel. It is driven by 2 stepper motors for high accuracy and repeatable process. It has safety enclosure and process view window.

owl feeder with in line vibratory feeder track. The parts are fed at the laser drilling station where they are drilled and inspected. Good and bad parts are separated in automatic mode.

Robotic part handling system consists of 6 axes robot, vision system for part orientation and 532nm Nd:Yag laser. HMI with touch screen for all operation and diagnostic functions.

8 station rotary index table with part present sensor, laser etching, automatic part cleaning, 4 color printing and drying processes with Light curtain for operator safety.

6-axes robot for handling wide variation of parts. It also minimizes tooling cost and provides accuracy and precision and highly repeatable positioning.
