Cleatech Llc

California, United States

4 Feet Benchtop Overall Dimensions 49.5’’ x 30’’x 45’’ Work area dimensions 46’’ x 27.5’’ x 29 3/4’’ White Polypropylene Material ¼’’ Thickness Available with optional worksurface and stand ( Choice of 304 stainless steel or Polypropylene worksurface and epoxy Power coated steel mobile Stand, 30’’ / 35’’ Height Benchtop Vertical laminar flow hoods provide can be positioned on nearly any bench. Consists of a integrated Fan Filter module Meets IEST recommended practices. Low sound, low watts Measuring only 50 dBA Running at only 240 watts @ 90 fpm 490CFM @ 250 Watts Minihelic gauge ( 0-1m’’ Water Column ) monitors pressure differential when it exceeds the limit , it indicates the need to replace the HEPA filter (s) Choice of HEPA: 99.99% efficient @ 0.3μm particles or ULPA 99.999% efficient @ 0.12μm particles Including Build-in Fluorescent Light for  feet, 24W

• Size30"W x 24"D x 26"H

our 2800 series isolation glove box is constructed from 304-grade stainless steel. One of the easiest materials to maintain and looks great, stainless steel is resistant to a wide range of chemicals, moisture, and heat. A continuous-seam welds designed for removal of oxygen and humidity and backfill with nitrogen or argon. Its front tilt-up window is constructed from clear ar polycarbonate, perfect for transferring large equipment. These glove boxes are esd safe and suitable for electrostatic-sensitive applications if grounded. Providing a clean and controlled atmosphere environment for many applications including semiconductor, pharmaceutical manufacturing, research, and testing.   specifications • overall dimensions (main chamber): 30"w x 24"d x 26"h • overall dimensions (airlock): 12.5"w x 12" d x 12"h • material: 304-grade stainless steel • side door opening: 10" x 10" • front tilt-up window: ar polycarbonate • external mounted led light • two 8" od glove ports • all welded 1/4" npt ports • chamber volume: medium ~ 10 cu.ft. options • transfer chamber • inert-gas ports • purge control with rh or o2 sensor • o2 monitor • rh & temperature monitor • gloves

Polypropylene Transport carts for Chemical transport, Type A, Capacity of 16 Gallon, two levels, Spill containment Design, 40″x18″x37″ White Polypropylene Construction, 1/2″ wall thickness Acid-resistant casters Three standard configurations Modular and removable bottle dividers Spill containment Design Optional Floor-lock brakes

• MaterialPolycarbonate
• Brand NameCleatech
• Size36"
• General UseChemical Handling

Ducted Fume Hood 48’’W x24’’Dx25’’H, Wall and sash material Polycarbonate White Polypropylene worksurface resists acids and other chemicals. Clear top panel to provide enough light in the work area Can put on any available work surface.

stainless steel desiccator overall dimensions: 20’’wx 20’’dx 16’’h usable shelf space: 18 ½’’w x 18 ½’’d bench-top, single chamber desiccator cabinet 304 stainless steel gage 16 heavy-duty construction stainless steel door hinge for maximum door support one chrome plated lift-and-turn compression latch for perfect door seals one-piece non-adhesive door sealing chrome-plated rack allow shelf placement at one-inch increments 304 stainless steel door frame with clear static-dissipative pvc window .

¼’’ thick white polypropylene with a tempered glass front window. high chemical resistance to corrosive agents. internally mounted fluorescent light. Upon request, light can be externally mounted. overall dimensions (main chamber): 35” w x 24” d x 25” h; overall dimensions (airlock): 11.75” w x 10.5” d x 10.5” h two access doors open outwards (or inwards upon request) for negative pressure configuration. If an airlock is included, airlock doors open inwards. Doors include a stainless steel door frame, hinge, one-piece non-adhesive sealing. side door opening 10’’ x 10’’ blower module, adjustable speed, backward curved impeller 480-cfm, permanently lubricated, automatic reset thermal overload protection, 120vac, 60hz, ul listed; csa certified; enclosed in a polypropylene housing. primary hepa filter is 99.97% efficient at trapping particles as small as 0.3 microns. Filter media is ultra-fine glass fiber and is 3″ thick. The maximum temperature is 180° and the filter meets ul class 2 flame retardant requirements.

¼’’ Thick Clear Static-Dissipative Acrylic Static dissipative coating increases the chemical resistance of acrylic when compared to non-coated acrylic. Eliminates static charges and keeps the dry box clean since it does not attract particles from the air. Surface resistivity of 106 – 108 ohms per square. Provides for ESD control without the need for ionization. Excellent optical properties with no color tint. Overall Dimensions (Main Chamber): 27” W x 18” D x 18” H; Overall Dimensions (Airlock): 11.75” W x 10.5” D x 10.5” H A tilt-up window with a stainless steel frame and clear acrylic panel. The 18” x 7.75″ opening allows for parts to be easily placed inside the glovebox. Interior Dimensions: 26.5” W x 17” D x 17.5’’H Removable fully gasketed back wall for operations involving large equipment. (Fixed by screw) Two 8’’ Diameter glove port with Stainless Steel clamp can be used with any 8’’ standard glove. For gloveboxes with an airlock, an internal access door opens inward to transfer parts from the airlock to inside the glovebox. The door uses a stainless steel frame that increases the structural rigidity of the door and the 10” x 10” opening includes a single piece gasket.

4 Feet workstation Overall Dimensions 52’’Wx36’D’x62.5’’H Work area dimensions 46”Wx22”Dx26.75”H Hood construction white Polypropylene Stand construction white epoxy powder coated steel Consists of a Certified Fan Filter module low sound, low watts measuring only 50 dBA. Running at only 240 watts @ 90 fpm 490 CFM @ 250 Watts HEPA Filter rated 99.99% efficient or ULPA FFUs, rated 99.999% efficient @ 0.12μm Pre-Filter: Washable polyurethane foam Magnehelic gauge (0 – 1” m Water Column) monitors pressure differential when it exceeds the limit, it indicates the need to replace the HEPA filter(s) Air slots along the side edges minimize backwash and turbulence in the work area Built-in Fluorescent Light T5, white Air Flow: 650 4-Feet Model  Average airflow velocity: 90 feet/minutes (fpm)

¼’’ Thick Clear Acrylic. Ideal for general purpose processing but can be damaged by alcohol and some cleaning agents. Overall Dimensions: 24” W x 24” D x 48” H Stainless steel door frame and door hinge. Chrome plated wire rack for shelving. A pair of wire racks is needed for each chamber and are optional if there are no shelves. Chrome plated lift-and-turn latch. Single-piece Santoprene seal. Door Opening: 22.375” W x 10.1875” H Internal Usable Space: 22.125” D x 11.75” H
