Luminaire housing, cover, and slipfitter are cast aluminum. Luminaire cover provides top access to electrical components and optics. Flat lens with decorative screen-printing is clear tempered glass and bonded to housing with silicone for a weather tight seal. Housing is fitted with stainless steel weather-tight strain relief bushing for power cable exiting rear of the luminaire. Luminaire slip fitter mounts to the pole top tenon, maintaining a consistent outside diameter in the transition to the pole. Luminaire is available in single or twin mount configurations. All hardware is stainless steel.

Luminaire is fabricated from aluminum to form a sealed enclosure which houses the LED light engine and driver. Luminaire housing is mounted semi-regressed into the rectangular profile pole and is accessed with a single captive thumb screw mechanism for tool-less entry. Horizontal flat lens is clear tempered glass. Housing is fitted with stainless steel weather-tight strain relief bushing for the power cable exiting the rear of the luminaire inside the pole. All hardware is stainless steel.

One-piece luminaire base is precision-machined from 6060 billet aluminum, then satin anodized. Cylindrical matte acrylic lens with two guide pins twists and locks onto luminaire base and is secured with two recessed setscrews. One-piece closed cell silicone gasketing provides a weather-tight seal to the housing. Housing fastens to an internal mounting plate in the pole top and is sealed to the pole with a one-piece closed-cell silicone gasket. Electrical components mount to plate on the underside of the housing and are housed in the top of the pole. All hardware is stainless steel.

One-piece cylindrical luminaire housing with integral cooling grooves and lens ring are precision-machined from 6082 billet aluminum, then satin anodized. Lens ring fits flush to the housing and retains the lens with three socket head cap screws. One-piece closed cell silicone gasketing provides a weather-tight seal when closed. Anodized spun aluminum shade is supported by four formed aluminum support struts welded to an attachment ring. Shade assembly mounts to the luminaire housing and is secured with four recessed setscrews. Housing fastens to an internal mounting plate in the pole top and is sealed to the pole with a one-piece closed-cell silicone gasket. Electrical components mount to plate on the underside of the housing and are housed in the top of the pole. All hardware is stainless steel.

Luminaire housing, shroud, and fitter are die-cast aluminum. Luminaire shroud is rotatable 360° for adjustment to site requirements. Clear lens with Fresnel optics is acrylic. Luminaire end cap is polycarbonate and painted to match luminaire on the standard model, or matte translucent on models with optional LED accent. Adjustable fitter allows horizontal adjustment of +- 60° and vertical adjustment from nadir to 120°. Each luminaire may be specified with one of five distributions. All hardware is stainless steel.

One-piece domed oval housing is die-cast aluminum. Tempered glass lens with cast aluminum lens frame is sealed to the housing with one-piece closed cell silicone gasketing. Hinged lens frame with quarter-turn fastener allows tool-less access for easy relamping. Electrical components are tray mounted. Cast aluminum fitter allows luminaire side mounts to 3" OD mounting arm. All hardware is stainless steel. Luminaire fitter side mounts to 3" OD arm with maximum insertion depth of 3.9" and is secured with single recessed setscrew.

One-piece domed housing is heavy cast aluminum. Hinged frameless tempered glass lens opens with single quarter-turn fastener for easy relamping. Lens is sealed to the housing with one-piece closed cell silicone gasketing. Hinged reflector plate, painted with high reflectance white paint, swings down allowing access to ballast components. Housing is fitted with stainless steel weather-tight strain relief bushing for the power cable exiting the rear of the housing. Luminaire installs onto bracket mounting plate with four socket head cap screws. All hardware is stainless steel.

Wedge-shaped housing is cast from high-grade aluminum alloy with integrated cooling fins to enhance heat dissipation. Housing is adjustable to 0°, 10°, 20°, 30°, or 40° above horizontal by means of two precision machined polished stainless steel knobs and locked into place with two regressed locking bolts. Frameless tempered glass lens with two quarter-turn fasteners allows tool-less access to optical compartment and is sealed to the housing with closed cell silicone gasketing when closed. Hot-dip galvanized steel mounting bracket with integral slip fitter has two rows of four stainless steel setscrews to secure luminaire to the pole.

Cylindrical post top luminaire consists of base with shade supported by four stainless steel support rods. Heavy-duty cast aluminum base with integral slip fitter anchors the support rods, and is machined to include groove for gasketing and mounting surface for the lens and ballast enclosure. Shade shall be spun aluminum and free from burrs and sharp edges. Shade and base are gasketed to provide a weather-tight seal to the clear acrylic cylindrical lens. Luminaire slip fits 3" O.D. pole or tenon, and has built-in stop to limit insertion depth to 3". Two offset rows of three 10mm recessed setscrews secure the luminaire to the pole. All hardware is stainless steel.

Luminaire consists of base, lens with decorative ring assembly, and secondary reflector with support struts. Decorative ring assembly surrounding lens is secured to the base with socket head cap screws and consists of aluminum rings separated by spacers. Simple cast aluminum luminaire base with integral slip fitter anchors three cast aluminum indirect reflector support struts with socket head cap screws and provides mounting surface for the optical assembly. Borosilicate glass lens has clear top with etched sidewalls and is sealed by compression to the luminaire base with single piece closed cell rubber gasket when the decorative ring assembly is installed. Top ring of assembly is separated from the glass lens with single piece ''D'' profile silicone gasket to prevent glass to metal contact. Spun aluminum indirect reflector is finished in high-reflectance white paint. Luminaire slip fits pole top tenon and has built-in stop to limit insertion depth to 4.5''. Slip fitter and pole shall have matching diameters to provide a smooth transition to the luminaire. Two offset rows of three 8mm recessed setscrews secure the luminaire to the pole. All hardware is stainless steel.
