Ideal Windlass Company

• Weight1 lb. 6 oz. (624 g)
• dimensionsL 26" (660 mm), W 1" (25 mm), T 1/16" (1.5 mm)

Single lifeline stanchion is 26" tall and accepts up to 516" (8mm) diameter coated wire. Works with Schaefer base 36-01. L 26" (660 mm), W 1" (25 mm), T 116" (1.5 mm), Weight 1 lb. 6 oz. (624 g)

• DimensionsL 1-5/8" (41 mm), W 1" (25 mm
• Availability2 oz. (57 g)

Enables a second lifeline to be run on existing 1" stanchions. Accepts up to 516" diameter coated wire. Locks in place with integral set screw. L 1-58" (41 mm), W 1" (25 mm), Weight 2 oz. (57 g)

• Size3/4" (19mm)
• Dimensions, Length 7-1/2" (190mm), Width 1-1/2" (37mm), Height 2-1/8" (54mm), Weight 1.87lb (.85kg)

New Stainless Steel 7-12" Chock. High Quality 316 Stainless Steel with soft internal radius for minimum chafe. Max line size 34" (19mm), Length 7-12" (190mm), Width 1-12" (37mm), Height 2-18" (54mm), Weight 1.87lb (.85kg), Requires (2) 12" Flat Head fasteners.

• Availability200 lbs (91kg)
• DimensionsLine 1/8" - 5/16" (3mm - 8mm), Requires (2) 8 Flat Head Fasteners. 1 1/16" (27mm)

70-07 Fast Entry Cam Cleat. Features Die Cast Aluminum Cams, Delrin(tm) Ball Bearings, Computer Designed High Flare allows for easy entry at various angles. Safe Working Load 200 lbs (91kg) Line 18" - 516" (3mm - 8mm), Requires (2) #8 Flat Head Fasteners. 1 116" (27mm) Centers.

• DimensionsL 3-1/4" (83 mm), W 2" (50 mm), H 2 " (50 mm),
• Availability6.5 oz. (184 g)

Swivel cam base features our Fast Entry cam cleat. Swivel base allows for quick and easy line engagement from a variety of angles. Max Line Size 716" (11 mm), Fastener Size (3), #10 RH (5 mm), CC 1" (25 mm), L 3-14" (83 mm), W 2" (50 mm), H 2 " (50 mm), SWL 300 lbs. (135kg), Weight 6.5 oz. (184 g)

• DimensionsL 5-1/8" (130 mm), Width 2-3/4" (70 mm), T 1" (25 mm)

Rugged SS Base is canted 5 degrees inboard to match most deck cambers. Features a 516" (8mm) welded rod reinforcement which also serves as a bail for snatch blocks and other gear. L 5-18" (130 mm), Width 2-34" (70 mm), T 1" (25 mm), Fastners (4), 14" (6 mm), Weight 14 oz. (397 g) 36-91 Backing Plate Available through Schaefer

• Width1/2" (13 mm),
• DimensionsL 1-3/4" (44 mm), W 5/16" (8 mm)
• Availability5 oz. (14 g)
• Height1/2" (13 mm)

Eye Width 12" (13 mm), Eye Height 12" (13 mm), L 1-34" (44 mm), W 516" (8 mm), Fasteners (2), #10 RH (5 mm), CC 1-516" (33 mm), SWL 400 lbs. (181 kg), Weight .5 oz. (14 g)

• color ]Blue

Plastic Fairlead - Blue for 70-07 Mounts directly to our 70-07 Cam Cleat. Will require (2) #8 RH fasteners.

• ThicknessThickness 3/4
• Series1 Series 3/4"
• DimensionsThickness 15/32

Sheave Dia. Thickness 34" (19mm), Thickness 1532" (12mm), Width78" (22mm), Length 1 1332" (35mm), SWL 750 lbs (340kg), Weight 1 oz. (28g) Max Line 14" (6mm)

• dimensions7/8" or 1"

Handi-Hangers are used in the cockpit or stern pulpit to organize line, fenders, life rings, hose etc. Use on 78" or 1" tubing, coated lifeline or remove the backing to mount on a bulkhead.
