Metaphase-Technologies, Inc.

United States

• Power Source24VDC
• Cable10 foot (3.05 m) cable with flying leads

High Uniformity both laterally and longitudinally Equipped with reinforced side plates and fixed-rib 50mm focal length cast acrylic lens for increased durability Lens Options for various beam widths and working distances Adjustable lens focusing range of mm to meters Backlight versions for web backlight & silhouetting applications Built-in constant current driver(s) provides consistent illumination output 24V version require no special controllers; simply provide 24VDC

• Power Source24VDC
• Current Draw (max)0.2 amp

The Metabright Series is a high performance and uniform light source for silhouetting and transmissive application. Using a Full Array LED layout, we can pack more LEDs per square inch to provide greater intensity, uniformity and performance. The Metabright Backlight Series is available with a wide variety of LED colors and sizes such as White, Red, Green, Blue, IR, UV (365 nm and 395 nm) and RGB with independent color control with active areas ranging from 1”x1” (25mm x 25mm) to 5’ x 5’ (1.5m x 1.5m).

• Power Source24VDC
• HousingAnodized Aluminu (Stainles Optio Available)

Metaphase Oblique and Wrinkle Line light is designed with unique angled LEDs to project light at a 20 degree angle. The angled light makes the OLL great for creating a dark fieldoff-axis effect for line scan and area scan applications or for wrinkle detection. Using high output LED technology, the ObliqueWrinkle Line light produces high intensity lighting needed for high speed imaging.

• length1” to 120”

The MetaBrightTM Line Light is another product in the Metaphase family of LED lights for line scan. Its narrow, structured beam delivers high intensity and concentrated light for the narrow field of view of a traditional line scan camera. The high intensity and uniformity allows the MetaBrightTM Line Light to be used as front light to inspect for material defects, angled to obtain an off-axis effect to highlight surface defects, or it may be placed beneath the object for a backlight effect to inspect for holes, voids, or contaminants. The MetaBrightTM Line Light is available with a wide variety of LED colors such as white, red, green, blue, IR, UV (395 nm), and even RGB&IR with independent color control up to 150 inches (3.81m) in length for large web applications.

• Power Source24VDC
• IP RatingIP65

Our brand new 2nd generation Exolight builds upon the world renowned, ground breaking technology of the original Exolight Series. Our new molded Lumiform diffuser provides a dramatic increase in uniformity, coverage area, and resistance to impact. With a 130 degree spread of uniform lighting, the Exo v2.0 is perfect for even the most sensitive area scan application and its high level of diffusion makes it a great candidate for transmission or backlight applications; even for Line Scan! Hard molding makes the diffuser extremely durable to impact and can be configured for IP rating with greater water and dust resistance. The Exo v2.0 is just another example of the Best Getting Better!

• Power Source24VDC
• Current Draw (max)1A min @ 5", 22.5A Max @120"

Using Metaphase's proprietary optics, the Collimated Line Light works similar to a traditional line light but can project its light at a lower divergence angle. This helps keep a tight, structured beam of light at longer working distance many meters away while delivering high intensity. This works great for applications where you can't have the light close to the object or web. This is useful creating clearance for robotics, imaging high tunnel ceilings, create distance from hot objects, or applications requiring extremely precise backlight imaging. The Collimated Line Light is a great tool for any line scan or machine vision lighting application.

• Power Source24VDC
• Cable10 foot (3 meter) cable with flying leads

• inch150

The UL Line Light is the latest design in the Metaphase family of LED lights for line scan. Its narrow, structured beam delivers high intensity and concentrated light for the narrow field of view of a traditional line scan camera. The high intensity and uniformity allows the UL Line Light to be used as front light to inspect for material defects, angled to obtain an off-axis effect to highlight surface defects, or it may be placed beneath the object for a backlight effect to inspect for holes, voids, or contaminants. The UL Line Light is available with a wide variety of LED colors such as white, red, green, blue, IR, UV (395 nm), and even RGB&IR with independent color control up to 150 inches (3.81m) in length for large web applications.

• Supply Voltage12-24V+/-10%
• Output3 Channels/0-10 Voltage Control each
• Supply Current1A

• Model No.OARL101-SC2

This MetaLight™ 1" I.D. off-axis ring light (dark field) provides a near horizontal plane of light which is useful for highlighting surface defects, illuminating specular surfaces, and side lighting prominent target features. The half circle ring light allows for inspection applications to keep stationary while utilizing the mobility of the split ring. Our ring lights can be configured for wavelength and other specifications.
