Welan Technologies

Paud Road, Pune, Maharashtra

• Human Vibration measurements meeting ISO 8041:2005, ISO 2631-1, 2 & 5 (including VDV and MTVV)and ISO 5349-1 & 2
• Six channels for acceleration and two channels for static force measurements
• Hand-Arm measurements:

SV 105A integrated tri-axial accelerometer including hand straps

SV 105AF integrated tri-axial accelerometer with force sensors including hand straps

SV 150 tri-axial accelerometer with adapter for direct attaching to hand-held power tools

• Whole-Body measurements:

Low power seat accelerometer SV 38V

• A (8) daily exposure automatic calculation

An acoustic calibrator is a device which produces an acoustic pressure of defined level and frequency. In other words, anacoustic calibrator provides a template of acoustic pressure.

By using such a reference we can check the accuracy of the measurements taken by the sound level meter and adjust themif a drift error in the sensitivity is detected.

Features:

• SV 35A & SV 33A class 1 sound calibrators in accordance with IEC 60942:2003
• SV 34A class 2 sound calibrator in accordance with IEC 60942:2003
• Frequency 1 kHz
• 94 dB or 114 dB levels (SV 35A)
• 114 dB level (SV 33A, SV 34A)
• Built-in 1/2 MEMS reference microphone
• Microphone presence detection (SV 35A)
• Built-in temperature and static pressure compensation
• Automatic power off
• Dimensions 65 x 65 x 70 mm

The SV104 instrument is a revolutionary new approach to occupational health and safety noise monitoring offering voice comments and audio events recording functions which are a new concept in an instrument of this size.This personal dosimeter has a robust 1/2 MEMS microphone enabling easy calibration using most commonly available acoustic calibrators. The SV104 is a cable-free dosimeter and is typically attached to the users shoulder, close to the ear using the mounting clips supplied.

1. The SV110 is a hand-held vibration calibrator designed for verification of machine sensors as well as on-site checks of human vibration accelerometers in accordance to ISO 8041. The small size of SV110 enables easy checks of sensors at the machines. Depending on the selected frequency user may select level of calibration from1 m/s2 to 10 m/s2. Accelerometers are conveniently attached using mounting stud, mounting disc or dedicated adapter.
3. The calibrator menu provides selection between both metric systems g and m/s2. The menu is simply operated by three push-buttons and small OLED display.

Features:

• Hand-held vibration field calibrator designed in accordance to ISO 8041 for in-situ checks of hand-arm vibration metersand machine vibration meters
• Three push-buttons for selection of frequency and amplitude and start/stop control.
• The OLED graphical screen displays information on selected frequency and vibrationlevel.
• Two operating frequencies 80 Hz and 160 Hz
• Calibration of sensors with mass up to 300 g at 80 Hz.
• Built-in reference accelerometer for cross-axes / transverse vibration detection.
• Built-in rechargeable battery.
• Automatic fault detection: two LED diodes show the current status during the calibration process.

Wedo complete refurbishment service is flexible enough to accommodate upgrades and adaptations. Refurbishment services include finishes (wall fabrics, carpets and ceilings) air conditioning, rewiring, lighting, replacement walls or roof panels, structurally isolated floors, doors and windows.We do complete advice and design service for upgrading andor adapting existing audiology facilities ensures alignment with all current legal requirements.We also specialise in the refurbishment of facilities not originally built by us. Our in-house design specialists undertake a complete review of the existing facility before ensuring all element of the client brief are tackled expertly.

The SV 104A is a new version of our revolutionary SV 104 personal noise dosimeter, the first noise dosimeter on the market with MEMS microphone resistant to accidental shocks, knocks or even fall-downs. The list of distinguishing features of SV 104A includes a color OLED display that can be easily read even in a full daylight or in the dark.

Features:

• The dosimeter designed to meet requirements of the ANSI S1.25 and IEC 61252 standards for noise dosimetersand the IEC 61672 standard for class 2 sound level meters.
• Measurement range 53 dBA RMS 141 dBA Peak
• Operational time > 50 hours
• Lifetime warranty on MEMS microphone that is resistant to mechanical shocks and accidental drop downs.
• The dosimeter is suitable for noise exposure measurements in accordance with the following standards:ISO 9 612, OSHA, MSHA and ACGIH.
• Long-range Bluetooth interface enables current results preview on a smart-phone or tablet using our Assistantapplication. The smart-phone app also signals an alarm whenset noise limits are exceeded.
