Accurate Engineering

Ayanambakkam, Chennai, Tamil Nadu

we are able to offer a superior quality range of semi automatic double column band saw machine. to manufacture these machines, our engineers make sure that high quality components are brought into use. to make sure that the offered machinery is free from defects, the quality controllers hired by us inspect these on certain well-defined parameters. features : low maintenance cost high performance high efficiency simple compact structure reliable performance high precision longer working life steel industry forging company semi automatic band saw machine

TECHNICAL FEATURES
1. Square Column with Heavy Duty Linear Rail and Block Assembly.

 2. Cutting Capacity   Round                : 450 mm

                                   Flat                  : 450x450 mm

3. Blade Speed                                     : Variable through Step Pulley

4. Drive Motor Rating                          : 7.5 HP

5. Hydraulic Motor                               : 2 HP

6. Coolant Motor                                 : 1/6HP

7. Cutting Feed                                   : Regulated by infinitely Variable by flow control valve

8. Blade Width                                    :  41mm
9.Gear Box                                          : Heavy duty Helical Bevel Gear box

10. Height Adjustment                        : Automatic

11. One side moving blade guide box.

12. Heavy duty Stress relieved Fabrication.

13. Movable blade guides with Tungsten Carbide wear plates &Bearing
14 Hydraulic tank Capacity -60 Liters

15. Hydraulic Oil grade -68

16. One side moving blade guide box

17. Friction type Rotating Cleaning Wire Brush Arrangements

18. Inbuilt Hydraulic Power Pack

19. All Hydraulic Cylinders are double acting type, all functions through hydraulic Cylinder.

20. Extra Cylindrical Roller bearing support for Gearbox output shaft.

21. Coolant Tank Capacity-80-100 Liters.

22. Automatic Bow return after cutting.

23. Control Panel with Relay Logic Control

24. Automatic saw off & Coolant off after every cutting

25. Fully Heavy duty welded torsion Proof Structure.

26. Hydraulic Pump & Valves

27. Rexroth make Flow control valve

28. Interlocking arrangement for Blade breakage.

29. Electrical Supply Voltage—3Phase, 415V, 50Hz.

Being a customer focused organization, we are engaged in manufacturing and supplying technologically advanced Automatic Bandsaw Machine. The experts we have employed use high quality components and advanced technology to manufacture the offered machines.

ADDITIONAL SPECIFICATIONS:
1.Heavy duty Twin square Column with High quality Linear guide2. Heavy Duty Helical Bevel Triple reduction Gear Box3.Automatic Height Adjustment4.Friction Type rotating cleaning wire brush5.Heavy Duty Cylindrical Roller Bearing Housing Arrangement for gear box output shaft6.One side moving blade guide box with carbide tips& bearings7.Infinitely Variable Cutting Feed Through flow control valve.8. Double acting Hydraulic Cylinders for all operation.9. Multi indexing Facility10.Automatic Blade Breakage sensor.11. Electric control panel with PLC&HMI12.Hydraulic Blade Tension13.Wheel support Bearing Unit

Avail from us, high performing Fully Automatic Bandsaw Machine, Automatic Band Saw Machine that is manufactured from quality components. These Fully Automatic Bandsaw Machines are perfect for same length cutting and bundle cutting of metals in different sizes and shapes. We are Fully Automatic Bandsaw Machine Supplier and offer Fully Automatic Bandsaw Machine at competitive price. We have become a noteworthy name among prominent Automatic Band Saw Machine Manufacturers as we bring forth qualitative range of Fully Automatic Bandsaw Machines at very affordable rates for our esteemed clients. We are a reliable Automatic Band Saw Machine Manufacturer. All the machines, offered by us, are fabricated with top quality raw materials that are obtained from the most reliable vendors of the domain. Thus, they are sturdy and durable. Known For

• Reliable performance
• High precision
• Longer working life
• Sturdy construction

Available In

• Models from 260 mm to 1500 mm capacity

We are offering Automatic Bandsaw Machine, high performing fully automatic bandsaw machine that is manufactured from quality components. These fully automatic bandsaw machines are perfect for same length cutting and bundle cutting of metals in different sizes and shapes. We offer fully automatic bandsaw machine at competitive price.

Being a customer focused organization, we are engaged in manufacturing and supplying technologically advancedAutomatic Bandsaw Machine. The experts we have employed use high quality components and advanced technology to manufacture the offered machines. Besides, our logistics personnel timely deliver these machines at clients'' destination using easy modes of shipment.

We are a paramount organization that is engaged in manufacturing and supplying finest quality band saw machines. These machines are manufactured by our expert professionals employing advanced technology following industry standards & norms. Furthermore, customers can avail our range in variegated specifications at industry leading prices.

our organization is counted amongst the most distinguished manufacturers and suppliers of finest qualityFully Automatic Bandsaw Machine. Our engineers do not compromise with quality and make sure that excellent quality components and spare parts are used in the manufacturing process. These machines are appreciated by clients for their optimum quality and performance.

We are offering automatic machine. Avail from us, high performing automatic bandsaw machine that is manufactured from quality components. These fully automatic bandsaw machines are perfect for same length cutting and bundle cutting of metals in different sizes and shapes. We offer fully automatic bandsaw machine at competitive price. known forreliable performancehigh precisionlonger working lifesturdy construction available inmodels from 175 mm to 1000 mm capacity.

The company has cemented its presence among the trusted manufacturers and suppliers of horizontal bandsaw machines. Our horizontal bandsaw machines are manufactured in conformity set industrial norms using excellent quality components and the latest technology. We ensure that the machines reach the buyers in immaculate quality packaging options. Buyers are free to place bulk orders of the machines with us and we ensure their timely execution.

features :

technologically advanced high performance low maintenance cost model available from 260 mm to 1500mm cutting capacity.

We are a coveted organization that is engaged in manufacturing and supplying superior qualityDouble Column Band Saw Machines.The spare parts and components used for manufacturing are sourced from most trusted and reliable vendors of the market. TheseDouble Column Band Saw Machinesare widely acknowledged for their easy operations and minimal maintenance.
