Ajay Industrial Corporation Ltd.

Sahibabad, Ghaziabad, Uttar Pradesh

We bring forth the finest quality Spray Popup in the market. The Fixed Spray Popup offered by us is Available in 90°, 180°, 270°, 360° fixed spray patterns low as well as high discharge rate. It is also designed for providing nozzle flow adjustment. Further, we are reckoned as one of the distinguished Lawn Care Spray Popup Manufacturers in India.

Features Precise Discharge Spray Nozzles :Female threaded precise spray nozzles made of UV stabilized High Impact ABS Engineering Plastics. Available in 90°, 180°, 270°, 360° fixed spray patterns having low as well as high discharge rates. Also available variable arc Nozzles. Designed to provide nozzle flow adjustment. Also available pop up fogger and bubbler. Piston Stroke :Available in 2â and 4â, 6â and 12â (with side in let) pop up stroke lengths. Bottom Inlet :½â BSP Bottom Inlet is standard in all models. Wiper Seal :Specially designed wiper seal made of good quality synthetic rubber. Protects piston from and debris. Holds retract spring in place. Stainless Steel Arc Adjustment Screw :Provide with stainless steel arc adjusting screw for ease or arc adjustment. Cap :Buttress threaded cap are provided for firm holding of cap of the body against high water pressures. Large threads prevent cross threading during fitment. Single Piece Filter Screen :Filter screen made of good quality Engineering Plastics having large filtration area of prevent any debris from entering the nozzle so as to give good quality and reliable spray pattern. Retract Spring :Corrosion resistant Stainless Steel retract spring insures a positive retraction of the piston during close down of water supply. Ratchet Adjustment :Ratchet adjustment provided for easy alignment of the spray pattern in the field. Made of good quality wear resistant plastic materials to ensure a long operational life. Anti Drain Valve :All models are provided with anti drain valve to eliminate lowhead drainage & puddling.

We provide high end Gear Pop-Up Sprinkler that is used for efficient irrigation. We are one of the choicest Gear Drive Sprinkler Manufacturers in India. Our Gear Pop-Up Sprinklers have "Point and Shoot" arc adjustment without any tool. The smooth impeller gear drive of the sprinkler gives uniform water in all direction. Furthermore, we are also counted among the chief Gear Drive Pop-Up Sprinkler Suppliers.

Dimensions : 3/4 IPS Height : 7-5/8" ( 19.4 cm) Pop - up Height : 4" (10.2 cm) Features :

• Gear Drive : An impeller actuates the gear train, providing a smooth, steady, rate of rotation necessary for highly uniform watering. A sealed, lubricant packed drive housing provides long-life performance.
• Quiet Operation
• Field Changeable Nozzles : A set of nine nozzles is provided with each sprinkler. User can change in seconds to match precipitation rates and adapt performance to site conditions.
• Impeller Flow Regulator : The "automatic adjusting stator" correctly matches the volume of flow required at the impeller with the nozzle selected.
• Nozzle Lift Socket : Socket is provided in top of cover for lifting flow tube. Lifting tools are included in earch carton of sprinklers.
• Ready CheckTM Valve : 2 - Position check valve in the bottom of the removeable strainer is standard. Ready CheckTM is easily reversed in the field to the "check" position. Valve opens against f2 ft./hd. of water.
• Large Flow Tube : Streamlined flow tube design permits lower pressure loss through sprinkler, allows for optimum nozzle performance.
• Strainer : Large area screen protects nozzle from debris with minimum restriction in flow.
• Range Adjustment : Stainless steel screw retains nozzle and diffuses stream for optimum range control.
• Part-Circle. Arc Adjust Ring : Exclusive arc adjusting on nozzle flow tube permits quick adjustment of arc size from 40 degree to 360 degree. Sprinkler may be adjusted while water is on or off.
• Arc Dwell : A momentary "dwell" at each end of the part-circle arc provides full coverage along borders.
• Safety Clutch : "Slip" clutch protects gear train from damage if vandal should turn flow tube during operation. Clutch can also be used for arc relocation during installation.
• Full Wiper Seal : The pressure activated wiper seal on the Turbo 3 prevents debris from entering the sprinkler. This feature allows the sprinkler to be set at grade. Wiper seal and a strong, stainless steel spring assure positive head retraction.
• VRS Rubber Cover : "Vandal-resistant safety" cover is standard on all springlers. "Pos-i-lock"TM retainer prevents cover removal.
• Threaded Cover : Screw-on cover permtis easy access to all internal parts without removing sprinkler from point of connection.

Construction :High-strength, non-corrosive plastics and metals are used throughout this sprinkler to ensure long-life performance int he commercial or residential enrironment. Options :

• Non-potabel Alert Cover (add "N" suffix to part number)
• Vandal cover Lock (XVT3). Cover is designed to accept optional vandal screw to lock cover to body.

Accessories :Nozzle / Arc Tool (T3ST) : Nozzle changing and arc adjustment are both quick and easy with the T3St.

K50A, 60A, 70A, 80A SERIES IMPACT DRIVE ROTARY POP-UP SPRINKLERS Full or Part CircleThese long range rotary sprinklers are recommended for golf courses, parks, athletic fields and other large turf areas. Heavy duty construction ensures long life and trouble free service. Features

• Impact Drive actuated by nozzle stream and a recoil torsion spring.
• Anti-Backsplash Arm eliminates wasted water. Redirects sidesplash into the main stream. Standard on a all part circle models PK50A and PK60A full circle.
• The PK50AF and PK60AF utilize a single, high performance brass nozzle. The PK 70AF and PK80AF incorporate dual brass nozzling utilizing the secondary (small) nozzle to actuate the impact torsion drive, thereby assuring uniformity of large area coverage.
• Part Circle Models have a single, high performance brass nozzle.
• Trip Collars on all part circle models adjust the arc of coverage from 5°-355° with detents every 7-1/2° to retain arc selected.
• Screwdriver Adjustment of Stainless Steel Arm Torsion Spring Through cover to "fine-tune" sprinkler while in operation or "off" positions.
• All Internal Components are easilty removable from above ground as an integral assembly.
• Diffuser Pins for distance control and stream break up are standard on all part circle sprinklers. Full circles have specially designed nozzling to ensure close-in coverage.
• Free Turning Coves swivel under surface loads, thereby preventing sprinkler damage.
• Large Water Channels reduce pressure loss, improving sprinkler efficiency and performance.
• Check Valve prevents unsightly puddling caused by lateral line drainage at low heads. The check valve also minimizes damage to pipe, fitting and sprinklers caused by high velocity surging in empty lines. Valve opens against 15 ft/hd. (4.5 m/hd.) of water.

Construction

• New, "extra strength, " high impact engineering grade plastic housing. Molded-in brass inserts provide positive threading for stainless steel retainer bolts.
• O-Ring Seal under retainer gland makes field reassembly easier and provides sealing action superior to a gasket.
• Covers Are Die Cast Aluminum with green epoxy finish
• Internal Sprinkler Assembly is fabricated brass, stainless steel, cast bronze and non-corrosive plastics.
• Each Sprinkler is Factory Tested and calibrated at its rated intermediate operating range.

Options

• Rubber Cover - Green (XR58A) or Black (XR58BL), full molded rubber cover with rubber housing ring; allows sprinklers to be set flush to grade. Cover has center plug for access to cover screws and arm spring adjustment.
• Vandal Resistant Cover Screws (XV58) Special Tool required for removal.

PK50AF (FULL CIRCLE) Maximum Recommended Operating Pressure As Noted

PK50AP (PART CIRCLE) Maximum Recommended Operating Pressure As Noted

PK60AF (FULL CIRCLE) Maximum Recommended Operating Pressure As Noted

PK60AP (PART CIRCLE) Maximum Recommended Operating Pressure As Noted
