Security Alarms & Devices

Our offered Product range includes Moon LED Ceiling Lights, INTERIO UP DOWN, Ultra Slim Panel, LIVA and PLATO ZOOM.

We are leading supplier of this product.

Power Factor >0.95
IP Rating 44
OUTER SIZE (MM) 150x150
CUT OUT SIZE (MM) 125x125
HOUSING DIE - CAST ALUMINIUM
LENS / DIFFUSER HIGH TRANSMISSION PS
REFLECTOR N/A
SURFACE FINISH WHITE POWDER COATED
THERMAL MANAGEMENT
HEAT SINK MATERIAL ALUMINIUM
COOLING TECHNIQUE PASSIVE
OPTICAL SYSTEM
BEAM ANGLE 120
ILLUMINATION MODE INDIRECT LIGHTING
SWIVEL NO
LIGHT TECHNOLOGY
LED FITTED EDISON
LED FLUX 95 LUMENS / WATT
DELIVERED LUMENS 1080 /1130 /1150
CCT (K) 3000 / 4000 / 6000
CRI (Ra) 80
LED LIFE 30, 000 HRS
UGR 20
ELECTRICAL SYSTEM
INPUT VOLTAGE 110 TO 270 V
INPUT POWER 12W
THD <15%
CONTROL GEAR MOUNTING REMOTE
DRIVER PROTECTION OVP, Short Circuit, SURGE
DIMMING / EMERGENCY KIT /SENSOR OPTION/AL
APPLICATION AREAS Home, Office buildings, Retail, Industrial buildings, Supermarkets, Hospitality, liberary

We are leading supplier of this product.

Power Factor >0.97
IP Rating 44
OUTER SIZE (MM) 130
CUT OUT SIZE (MM) 115x65
HOUSING DIE - CAST ALUMINIUM
LENS / DIFFUSER HIGH TRANSMISSION PS
REFLECTOR N/A
SURFACE FINISH WHITE POWDER COATED
THERMAL MANAGEMENT
HEAT SINK MATERIAL ALUMINIUM
COOLING TECHNIQUE PASSIVE
OPTICAL SYSTEM
BEAM ANGLE 120
ILLUMINATION MODE INDIRECT LIGHTING
SWIVEL NO
LIGHT TECHNOLOGY
LED FITTED EDISON
LED FLUX 105 LUMENS / WATT
DELIVERED LUMENS 1140 /1180 / 1200
CCT (K) 3000 / 4000 / 6000
CRI (Ra) 80
LED LIFE 30, 000 HRS
UGR 20
ELECTRICAL SYSTEM
INPUT VOLTAGE 110 TO 270 V
INPUT POWER 10W
THD <10%
CONTROL GEAR MOUNTING REMOTE
DRIVER PROTECTION OVP, Short Circuit, SURGE
DIMMING / EMERGENCY KIT /SENSOR OPTION/AL
APPLICATION AREAS Home, Office buildings, Retail, Sports facilities, Studio, Stage, Supermarkets, liberary

Power Factor >0.97
IP Rating 20
OUTER SIZE (MM) 110x110
CUT OUT SIZE (MM) 90x90x95
HOUSING DIE - CAST ALUMINIUM
LENS / DIFFUSER Tempered Glass
REFLECTOR PC high purity metallised
SURFACE FINISH IVORY/WHITE POWDER COATED
THERMAL MANAGEMENT
HEAT SINK MATERIAL ALUMINIUM
COOLING TECHNIQUE PASSIVE
OPTICAL SYSTEM
BEAM ANGLE 20, 40
ILLUMINATION MODE DIRECT LIGHTING
SWIVEL YES
LIGHT TECHNOLOGY
LED FITTED BRIDGELUX
LED FLUX 110 LUMENS / WATT
DELIVERED LUMENS 1560 /1620 /1650
CCT (K) 3000 / 4000 / 6000
CRI (Ra) 90
LED LIFE 30, 000 HRS
UGR 18
ELECTRICAL SYSTEM
INPUT VOLTAGE 110 TO 270 V
INPUT POWER 15W
THD <10%
CONTROL GEAR MOUNTING REMOTE
DRIVER PROTECTION OVP, Short Circuit, SURGE
DIMMING / EMERGENCY KIT /SENSOR OPTION/AL
APPLICATION AREAS Home, Office buildings, Retail, Sports facilities, Studio, Stage, Supermarkets, liberary
PACKAGING
PACKING QTY 30
GROSS WEIGHT 21.3
CARTOON SIZE (LXBXH) 27 x 17.2 x 14

Power Factor >0.97
IP Rating 20
OUTER SIZE (MM) 210x110
CUT OUT SIZE (MM) 190x90x115
HOUSING DIE - CAST ALUMINIUM
LENS / DIFFUSER Tempered Glass
REFLECTOR PC high purity metallised
SURFACE FINISH IVORY/WHITE POWDER COATED
THERMAL MANAGEMENT
HEAT SINK MATERIAL ALUMINIUM
COOLING TECHNIQUE PASSIVE
OPTICAL SYSTEM
BEAM ANGLE 20, 40
ILLUMINATION MODE DIRECT LIGHTING
SWIVEL YES
LIGHT TECHNOLOGY
LED FITTED BRIDGELUX
LED FLUX 110 LUMENS / WATT
DELIVERED LUMENS 3120 /3240 /3300
CCT (K) 3000 / 4000 / 6000
CRI (Ra) 90
LED LIFE 30, 000 HRS
UGR 18
ELECTRICAL SYSTEM
INPUT VOLTAGE 110 TO 270 V
INPUT POWER 2X15W
THD <10%
CONTROL GEAR MOUNTING REMOTE
DRIVER PROTECTION OVP, Short Circuit, SURGE
DIMMING / EMERGENCY KIT /SENSOR OPTION/AL
APPLICATION AREAS Home, Office buildings, Retail, Sports facilities, Studio, Stage, Supermarkets, liberary
PACKAGING
PACKING QTY 15
GROSS WEIGHT 19.2
CARTOON SIZE (LXBXH) 27 x 17.2 x 14
