Nominal torque Mnom Nm 0.2 . 200

Accuracy class % Mnom 0.25

Relative repeatability error in unchanged mounting position b % Mnom 0.05

Rated range of supply voltage VDC 12 . 28

Current consumption mA 50

Output signal V 5

Electrical connection Cable, 1 m with free strands

Reference temperature Tref C 23

Rated temperature range C 5 . 45

Operating temperature range C 0 . 60

Storage temperature range C -10 . 70

Temperature effect on zero signal TK0 % Mnom/10 K 0.4

Temperature effect on characteristic value TKC % Mnom/10 K 0.2

Maximum operating torque MG (static) % Mnom 150

Torque limit Mmax (static) % Mnom 200

Breaking torque MB (static) % Mnom >300

Permissible oscillation stress when subjected to torque Mdf % Mnom 70 (peak-to-peak)

Level of protection IP50

The force sensor range of Lorenz Messtechnik GmbH includes compressive force sensors, tension force sensors, tension / compression force sensors.
