Min. Order (MOQ)
1 Set(s)
-
Brand Name
deyuan
We are offering external fire fighting system. Driven by:diesel engine. The fire pump and engine will be installed on a common base. Consisting of:1) fire pump:2 setstype: horizontal, single stage, centrifugal pump duty specified capacity: 600 m3h total head: 130 m l.c. speed: 2100 rpmpower absorbed : 273.6 kw (seawater) efficiency: 80% discharge : top, dn200 pn 25 suction: end, dn250 pn 16 direction of rotation: cw (viewing from driver end)materials of construction casing: nodular cast iron impeller: bronze shaft : stainless steel aisi 316 packing: soft packed 2diesel engine:2 sets engine model:tbd234v8, china type:4 cycle, 8 cylinder, electrical start, 24vdcrating type:heavy duty rated engine power:323kw @ 2100 rpm direction of rotation:ccw (viewing from driver end) 3 high flexible coupling mounted between pto of diesel engine and pumpfinal model to be selected by maker. &&&&&&:275n ce approval inflatable life jacket co2 fire extinguishing systemmarine horizontalvertical oil fired boilermarine air compressormarine centrifugal pump marine hydraulic steering gear hydraulic capstantunnel thrusterbow thruster.
Additional Information:
Payment Terms :
L/C, T/T
Packaging Details : wooden case
Delivery Time : 7days
Guangdong, China
