Dongguan Yuebosi Electronics Techology Co. Ltd.

Dongguan, Guangdong, China

We are offering high pressure spray nozzle. afd high pressure spray nozzle ybsco's fd series high pressure anti-drop fine fog nozzles have guide vane inserted and have a anti-drop equipment. Under the pressure of 20-70kg(290psi-1015psi), the liquid flows in a high speed forming a centrifugal vortex in the vanes, then spray the fine droplets from the orifice. This kind of nozzle can be used in artificial fog, disinfection, cooling, humidifying etc. As the wide use in artificial fog industry, it's also called artificial fog nozzle, cooling fog nozzle. material of nozzle's body : brass brass coated with nickel and stainless steelmaterial of nozzle's tip: stainless steel, ceramic and ruby. features:1. Without air's supplementary, system device is simple. 2. Fog's droplets' diameter ranges from 3-70um, and spray fully. 3. Energy and water saving, low cost and good effects. 4. Non-blocking and anti-drop. 5. Nozzle tip uses wear-resistant materials, and service life is 2.5 times of similar nozzle. applicationhumidifying in textile workshopcooling and disinfection in farmmaking man-made fog landscapefresh vegetables in the supermarketcoolinghumidifying in electronic industryenvironmental and dedusting humidifying in workshop

We are offering stainless steel spiral nozzle. Stainless steel spiral nozzlespiral nozzle is also called desulphurization nozzle and non-block nozzle, large flow-rate nozzle, and dust removal nozzle. Theory of the spiral nozzlethe spiral nozzle produced a series of concentric cone jet type. Same with the axial nozzle the exit and entrance of the spiral nozzle also in the same central axis. While, there are no fine tuning blade inside of the spiral nozzle compared with the axial nozzle. The difference is that the spiral nozzle itself was designed into a shape of spiral which diameter shrinking constantly. This kind of design can cut the flow of the liquid into two or more concentric spiral rings. One meter below the nozzle, the jet model on the section was composed by one or more concentric rings. the size of the droplet formed by the spiral nozzle is similarly with the size of tangential nozzle of hollow cone jet type. While, the operating pressure of the spiral nozzle is higher than the hollow cone jet type. When facing with the same pressure the spiral nozzle is more suitable than the axial nozzle in a situation of higher liquid flow rate. after tangent and collision with the shrinking spiral the liquid (or slurry) would be changed into very small droplets which will jet out and form into mist. The streamline designed from the entrance to the exit in the nozzle's cavity would make the modulus of the obstacle into the lowest. The spiral nozzle was suit for various kinds of works in numerous industries such as chemical industry, environment protection, electricity and textile etc. The spiral nozzle is more widely used especially in the desulfurization and dust removal. At the same time, the spiral nozzle has been accepted by many users in the industry by it's characters like easy fogging, against block and it's resistance of durability and corrosion. Yuebosi electronic technology co., ltd.'s 316l stainless steel nozzle performance characteristic: 1. 316l stainless steel nozzle (spjt) is a kind of solid cone-shape or the hollow cone-shape atomization nozzle, 2. the jet angle scope can be 60 degrees - 170 degrees, generally 120 degrees. under 3 palestinian pressures, the liquid discharge rate scope is from 5.5 l/min to 4140l/min, 3. widely applies in the haze desulphurization, dust removal, exhaust gas processing, wastewater disposal, the fireproofing, fire fighting, spraying cleaning and other fields. 4. these compact nozzles have smooth flow paths, which can minimize the liquid blocking, so that the liquid in the pipeline of a given size reaches the maximum flow. 5. 316 l stainless steel spiral nozzle can be installed or updated in the majority of the pipeline system. 6. there are npt or bspt (male) threads nozzles available, 316 l stainless steel spiral nozzle generally for inch male thread specification, it can connect with threaded adapters to be female thread, if you need special processing, please contact yuebosi electronic technology co. Ltd sellers. 7. usually, 1/4 inch to 4-inch nozzles can be separately made of various materials, such as brass, 316 l stainless steel castings, pvdf, 95 ceramic, silicon carbide, teflon ptfe or pvc. And 316l stainless steel castings, pvc, 95 ceramics, silicon carbide stock a large number. We promise that conventional products can be shipped freely. If the nozzles applied to the special areas, relevant material nozzles also can be supplied. 8. users can choose any kind of 316l stainless steel nozzles voluntarily from our company. There are mirror polish processing nozzle and the sand blasting nozzles available, both of which are completely meet the national environmental protection standard. Application scope: exhaust gas desulfurization; gas cooling; evaporative cooling; washing and bleaching shower; dust removal, fire-fighting. Representative application1. Power plant, burning coal project desulfurization and denitration. 2. Air purification, air cooling and defoaming. 3. Evaporation, cooling, and dust controlling. 4. Wetting air by dust removing spray--environment protect. 5. Pre-treatment requires for non-blocking spray. 6. Air cooling. 7. Exhaust gas cleaning. 8. Fire fighting, fireproof. 9. Steel and iron/ petrochemical industry dustproof application.

We are offering wind jet nozzle for drying. design features :the wind jet nozzle can be of high momentum, fan-shape compressed air. It is made of stainless steel, designed for the cooling, drying and blowing applications for the conveyor, the air inflow control instrument panel and handheld devices; a fixed row of nozzles can provide an effective air curtain. Its interior aerodynamic design effectively reduces the air resistance during operating time, ensuring that the wind jet nozzle reduces noise and air consumption while gaining high momentum force. the f013 wind jet nozzle adopts the double-row hole design, both the upper and lower row with 8 cylindrical holes. The nozzle inhales the ambient air, doubling the exhaled air volume, most suitable for water removal; it can reduce air consumption and adopts the quiet environmentally-friendly design. the f013 nozzle uses stainless steel for casting molding, with a v groove processed with line cutting, a small hole discharged by the spark discharge pore (the normal hole aperture is 0.8mm or 1.0mm; the aperture can be adjusted according to customers' requirements). The maximum working pressure of the f013 nozzle is 50 bars.

We are offering plastic quick dismantle spray nozzle. plastic quick dismantle of spray nozzle of the design are novelty, the nozzle body and spray-head can without effort of the rapid separation. plastic quick dismantle of spray nozzle were used respectively to glass fiber reinforced polypropylene ( including fiber 25%), carbon fiber reinforced polypropylene ( including fiber 40%) and pvdf, the feature is high strength, wear resistance and resistance to chemical corrosion advantages by the way , glass fiber reinforced polypropylene of the most high temperature heat is 82 degree, carbon fiber reinforced polypropylene of the most high temperature heat is 120 degree.pvdf of the most high temperature heat is 148 degree under the pressure of the 7kgmaterial; pvdf f4 pp ppr ss pvcflow rate;0.5 to 10 barspray angle ; 40 to 70 degreespray patterns; full cone or hollow coneflow distribution; standand convex distributionthread size;; 1/4 1/8 3/8thread standand ; bspt/npt
