Langfang Xinming Cable Machinery Industry Co.,Ltd

Langfang,Hebei, China

• MOQ 1 Set(s)
• color sky blue and yellow

1. Application the device is mainly used in cored wire insulation or cable jacket extrusion. 2. Technical parameters 1) production scope: the diameter of the conductor: φ1.2mm – φ8mm finished diameter size: 1.2-16mm 2) extrusion capacity: max 80kg/hr 3) motor power: 15kw (frequency conversion) 4) heating power: 16kw (three section heating with air cooler) 5) center height of the machine: 1000 mm 6) pay-off spool specification: diameter 630mm (pn 400-630mm) 7) take-up spool specification: diameter 630mm (double spool)

• MOQ 1 Set(s)

2.1 monofilament diameter: copper : 1.3-5mm aluminum: 1.7-5mm steel: 1.0-5mm 2.2 diameter after stranding: 3-15mm 2.3 host rotary speed: 500rpm 2.4 capstan diameter: pn 1500 double wheel 2.5 output speed: 17-165m/min 2.6 pitch of stranding: 34-330mm 2.7 pay-off bobbin size of the out-host one: 500mm 2.8 pay-off bobbin size of the host: 500 mm 2.9 take-up bobbin size: 800-1600mm 2.10 main motor power: 30kw (ac).
