Shandong Chencan Machinery Co. Ltd.

Dezhou, Shandong, China

• MOQ 1 Set(s)

We are offering tool changer cnc router. product specifications /features technical parameter working size: 1300mm*2500mm*200mm working speed: 35m/min spindle power: 3.5kw, air-cooled spindle speed: 18000r/min motor and driver: stepper working command:g code, hpgl, uoo, mmg, plt dust collect function: yes diameter of cutter: ï�3.175mm-ï�12.7mm package:2.15*3.15*1.85m fetures: 1. Tool chaner cnc engraving machine is designed for manufacturers who require high production and automatic tool changer function 2. X y axes adopt rack and pinion transmission, z adopts ball-screw 3. Well compatibility: cad/dam designing software e.g. Type 3, artcam, castmate, ucancam, alphacam, etc. 4. Has the function of re-carving after break point and power failureã�� 5. Weihong ncstuidoã�� applicable industries: processing various kinds of moulds and furniture such as door, window, cabinet, craft wooden door, screen

• MOQ 1 Set(s)

We are offering wood and styrofoam mold syntec cnc router. product specifications /features detailed product description: area:1200x2500x600mm; 4.5kw water-cooled spindle; package size:2.2x3.7x2.3m ; meet ce and iso stantard; delivery:10 days. technical parameter: x, y and z working size: 1200*2500*600mm x, y structure: rack and pinion, gear drive taiwan pmi square guide rails (25mm) z structure: ball screw, 25mm taiwan pmi square guide rails (25mm) spindle: 4.5kw, water-cooled diameter of cutter: �3.175-�16mm spindle speed: 24000r/min working voltage: ac380v 3-phase motor and driver: stepper command: g code, hpgl, u00, mmg, plt controller: syntec software: artcam / type3 working table: with fixing clamps and aluminium table coated with solid pvc weight: 1700kg package size: 2200*3660*2300mm

• MOQ 1 Set(s)

We are offering cnc wood router. appliable industries: wood processing: processing of various furniture such as door, window, cabinet, craft wooden door, screen and so on. advertisement: engraving and cutting various labels and number plate. art craft: engraving characters of any languagages and grafics on gifts and souvenirs. applicable materials: wood, aluminum board, plastic, density board, wave board, pvc, acrylic, crystal glass, light marble and other nonmetal materials and light metal naterials. processing effect: our cnc router is widely used for cutting, milling, drilling, engraving various shade vulture, relief, etc

• MOQ 1 Set(s)

We are offering advertising cnc router. It has two functions of plane carving and cylinder engraving product specifications /features 1. Applicable area: this machine can be used for stone, brass and al processing, mold manufacturing, wood processing, craft manufacturing, indoor decoration cutting, sign and mark manufacturing, acrylic board processing, as well as stamp and pcb drilling. 2. Main parameter 1) machine body: welded seamless thick square tube 2) working dimensions(x x y x z): 1200 x 1200 x 200mm 3) body dimensions: 700 x 1000 4) max. Feeding height: 200mm 5) cutting thickness of material.

• MOQ 1 Set(s)

We are offering stone engraving cnc router. product specifications /features detailed product description: spindle power: 4.5kw water-cooled spindle speed: 24000 r/min diameter of collet: 3.175-15.6mm working speed: 35m/min x y transmission: rack and pinion transmission z transmission: ballscrew transmision motor: stepper command language: g code, hpgl, u00, mmg, plt control system: dsp handle with usb software: artcam / type3 applications and characters: special for stone/marble/granite/glass working 1.applicable industries:wood, stone, advertisement, art craft, printing and packaging business, leather clothing, mould, product id, etc;cutting and engraving characters of any languages and graphics; 2.applicable materials:wood, advertisement material, stone, art craft process, metal and nonmetal material; 3.lathe bed welded with thick channel steels and square tubes;processed by high temperature tempering treatment and vibrating stress relief(vsr)to reduce residual stress; 4.be compatible several cad / cam designing software of type3, artcam, castmate, wentai, etc; 5.lubricate components automatically;be convenient to maintain the machine; 6.recover carving point after break or disconnecting power, and has the function of forecasting process time. 7.used for embossment, shadow engraving, openworking carving, cutting, graphic sculpture, milling, etc.

• MOQ 1 Set(s)

We are offering multi-head cnc router. product specifications /features detailed product description: multi-head cnc router can finishe the workload of four machines with in the same time as I has six spindles, higher efficiency. standard features: 1. Heavy mode lath body, welded by thick hard steel, to make sure the machine�s high stability, precision and efficiency working. Bistratal side panel, to make sure the gantry�s high supporting power. 2.three axes adopt taiwan hiwin high precision linear orbit; x and y axes adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts ball screw, with high precision. 3. Two spindles can work at the same time, also can work independently. The machine can finish the workload of two machines within the same time as it has tow spindles. So the machine saves working time cost and investment for you and brings you with high efficiency. 4. Well compatibility: cad/cam designing software e. G. Type 3/ artcam/ castmate/ wentai etc. 5. Has the function of re-carving after break point and power failure. Has the function of forecasting process time. 6. Closed tank chain. 7. Adopting advanced dsp system with usb connection, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources. 8. Perfect oil-inject system makes maintenance much easier. 9. Has duct-collect function. It will clean up the carving residuum and make the operations tidier and more convenient. 10. Fumigation-free wooden case.

• MOQ 1 Set(s)

We are offering cnc router for wood. product specifications /features brand name: chencan model number cc-m1325a cnc or not cn: c condition: new certificate: ce, iso9001-2008 gross weight: 1400kgs net weight: 1300kgs packing case size: 2150*3150*1900mm accuracy: within 0.1mm max. Idling speed: 35m/min work-holding: by suction or clamp cooling mode: air-cooled dust-collect function: yes working mode: stepper features: 1. Three axes adopt hiwin high precision square orbit; x and y axes adopt rack and pinion transmission, fast working, high efficiency and low cost; z axis adopts germany-made ball- screw, high precision and long life time. 2. Well compatibility: cad/dam designing software e. G. Type 3/artcam/castmate/wentai etc. 3. Has the function of re-carving after break point and power failure. 4. Adopting advanced dsp system with usb interface, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources. 5. Vacuum table with 6 vacuum zones, which can adsorb different size materials. It is also convenient for the user to fix the materials by clamp. 6. Perfect lubricating system makes maintenance much easier.
