Starred-river (hangzhou) Machinery Co., Ltd Srarred-river Transmission

Zhejiang, China

• MOQ 2 piece
• REDAS YOU LIKE

Product introduction For SR geared moors, the boxes are cast prcisely by high stell material and pricesed at processing center; The gears are made of high-quality alloy steel, are treated with surface hardening and gear ground; And the key parts are imported. The whole geraed motors are small in volume, with great load-carrying capacity, steady running, low noise and high efficiency. SR geared motor have reached the advance level, can replace the same kind of products imported. Equipment method: 1. Various motors can be equipped 2. Direct connection motor or double-shaft motor 3. Foot installment or flange installment Technique parameter: 1. Power: 0.12 KW~200 KW 2. Torque: 200 N. M~50000 N. M 3. Ratio: 5~33000 Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe Dimension tolerances Shaft heights H less than250mm Diameter tolerance of hollow shaft D�ISOH7 Flange centering shoulder tolerance B-ISOH7 Diameter tolerances D less than50mm H more than250mm D more than50mm Center holes of shaft terminal More than13-16mm---M5 More than 16-21mm---M6 More than 21-24mm---M8 More than 24-30mm---M10 More than 30-38mm---M12 More than 38-50mm---M16 More than 50-85mm---M20 More than 85-130mm---M24 More than 130mm---M30 Helical-bevel geared motors are avaliable in the following mounting methods: Foot installation B5 flange installation with hollow shaft B5flange installation with splined hollow shaft Footinstallation with hollow shaft B5 flange installation with hollow shaft and shrink disc Foot installation with spined hollow shaft Installation of hollow shaft(with countertorque arm) Installation of splined hollow shaft(with countertorque arm) Foot installation with hollow shaft and shrink disc Installation of hollow shaft and shrink disc(with countertorque arm) B5 flange installation B14 flange installation with hollow shaft B14 flange installation with splined hollow shaft B14 flange installation with hollow shaft and shrink disc

• MOQ 2 piece
• RED AS YOU LIKE

Product Description Gear box features: For SR gear box, the housing is cast precisely by high steel material and processed at pricessing center; The gears are made of high-quality alloy steel, are treated with surface hardening and gear ground; And the key parts are imported. The whole gear box is small in volume, with great load-carrying capacity, steady running, low noise and high efficiency. SR gear box has reached the advance international level, can replace the same kind of products imported, and can be used widely in over ten fields, such as metallurgy, mine, machine, energy, transportation, water conservancy, chemical industry, light industyry, printing package, pharmacy, food, textile, building, building material, matter flowing, environmental protection. 1. High modularization design: May equip with various motor or other power input conveniently. Same machine type may equip with various power motor. It is easy to realize the combination and junction between every machine type. 2. Transmission ratio: Fine division, wide scope. The combined machine type may form very large transmission ratio, i. E. Output very low rotary speed. 3. Form of installation: The position to be installed is not limited. 4. High strength, compact: The box body is made of high strength cast iron. Gear and gear shaft adapts the gas carbonization, quenching and fine grinding process, therefore the bearing capacity of unit volume is high. 5. Long life: Under the condition of correct type chosen (including choosing suitable operation parameters) normal operation and maintenance, the life of main parts of speed reducer (except wearing parts) should not be less than 20000 hours. The wearing parts include lubricating oil, oil seal and bearing. 6. Low noise: Because main parts of speed reducer are processed, assembled and tested critically, therefore the noise of speed reducer is low; 7. Parallel axis -bevel wheel speed-down motor Equipment method: 1. Foot installment, flange installment 2. Various of motors or double shafts can be equipped Technique parameter: 1. Power: 0.12 KW~160 KW 2. Torque: 85 N. M~18000 N. M 3. Ratio: 1. 4~28000 More Product Features HS Code: 84834090 Trademark: Starred-River Model NO.: SR82 Standard: IEC standard Productivity: 3000 PCS/Month Origin: China Packing: Wooden Box Mounting ways Exporting countres: North America South America Eastern Europe Southeast Asia Africa Oceania Mid East Eastern Asia Western Europe Central America Northern Europe Southern Europe workshop show

• chinese red as you want

Product Description 8000 series Cycloid pinwheel reducer is a speed reducing device taking use of planetary driving principle, engaged by cycloidal pinwheel, with advanced design and novel structure. The reducer can be widely used in the speed reducing mechanism of various driving machinery, e. G.: Craning, transportation, mining, metallurgy, petrochemical, textile, printing and dyeing, light industry, food, pharmacy, rubber, plastic, packing, road-building, environmental and grain-oil machinery, etc. Product: 1. Series of X, B series of parts of machine, Chemical Industrial Department 2. Series of B series of JXJ and series of mini WB Equipment method: 1. Foot installment, flange installment 2. Various of motors or double shafts can be equipped. Technique parameter: 1. Power: 0.04 KW ~ 75 KW 2. Ratio: Single-stage 9 ~ 87 Double-stage 121 ~ 7569 Exporting countres: North America South America Eastern Europe Southeast Asia Africa Oceania Mid East Eastern Asia Western Europe Central America Northern Europe Southern Europe

• chinese red as you want

Product Description NGW-S planetary gera reducers with horizontal right-angle between input and outputshaft, which is characterized by compact dimensions, light weight, easy assembling, high load bearing and good appearance include 2-stage and 3-stage series. (China Machinery Industry Ministry Standard JB3723-84) It is mainly used in metallurgy, mine, hosit, transportation, chemical, building andlight industry. Its application condition are as follows: The speed of high-speed shaft shall be no more than 1500 rpm. The peripheral velocity of gears shall be no more than 15m/s. for straight gear, and not more than 20m/s for bevel gear. The ambient in positive and negative directions (positve and clockwise is better). Working environmental temperature is -40~+45°c, if it is lower than 0°c, before starting one shall preheat the lubricant to be more than 10°c.

• MOQ 1 Piece
• chinese red as you want

NGW planetary gear speed recucer can be used in metallurgy, mine, chemical engineering, coal, building materials, light industry, petroleum, and other general machinery. 1. The maximum speed of high speed shaft should be no larger than 1500r/min; 2. The peripheral speed of gear should be no larger than10m/s; 3. The ambient temperature is -40~+45°C. This speed reducer can be run at clockwise and counterclockwise direction. Technique parameter: Specffications Scope of velocity rate Rotation of input-shaft(rpm) Input power(KW) Output torque(N.m) Double-stage NGW-S42~NGW-S122 11.2~80 750~1500 2.33~563.6 1910~49714 Three-stage NGW-S73~NGW-S123 56~500 750~1500 1.5~199.5 7820~68310 Exporting countres: North America South America Eastern Europe Southeast Asia Africa Oceania Mid East Eastern Asia Western Europe Central America Northern Europe Southern Europe

• MOQ 2 piece
• chinese redas you like

Gear box features: For SR geared moors, the boxes are cast prcisely by high stell material and pricesed at processing center; The gears are made of high-quality alloy steel, are treated with surface hardening and gear ground; And the key parts are imported. The whole geraed motors are small in volume, with great load-carrying capacity, steady running, low noise and high efficiency. SR geared motor have reached the advance level, can replace the same kind of products imported. Equipment method: 1. Various motors can be equipped 2. Direct connection motor or double-shaft motor 3. Foot installment or flange installment Technique parameter: 1. Power: 0.12 KW~200 KW 2. Torque: 200 N. M~50000 N. M 3. Ratio: 5~33000 More Product Features Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

• chinese red as you want

We offer cavex worm gearedreducer(al-alloy box). production introduce sr box worm reducer in aluminum alloy is made by starred-river with european technology. Its structure, outline and installation dimensions as well as preformance are same with that of european products, they are interchangeable, and the materials and machining process are advanced internationally. The product is featured by: merits of product 1. Low noise and temperature rise. 2. High bearing capability, smooth running and long service life. 3. Compact structure, small volume, light weight, beautiful shape and easy to install. 4. Can run continuously under server environment, and has a good reliability. technique parameter: 1. Power: 0.12 kw ~ 7.5 kw 2. Torque: 2.6 n. M ~ 1070 n. M 3. Ratio: 7.5 ~ 100 about us sr reducers can be widely used for speed-reducing driving for various machinery in petrochemical industry, machinery, grain, oil, food and forage machinery, light industry, textile, surger refining, pharmacy, leather industry, environmental and traffic & transportation, etc., they are the speed reducers that are used the most used the most widely at present in various production lines in european countries. exporting countres: north america south america eastern europe southeast asia africa oceania mid east eastern asia western europe central america northern europe southern europe

• MOQ 2 piece
• chinese red as you like

Product Description Gear box features: For SR gear box, the housing is cast precisely by high steel material and processed at pricessing center; The gears are made of high-quality alloy steel, are treated with surface hardening and gear ground; And the key parts are imported. The whole gear box is small in volume, with great load-carrying capacity, steady running, low noise and high efficiency. SR gear box has reached the advance international level, can replace the same kind of products imported, and can be used widely in over ten fields, such as metallurgy, mine, machine, energy, transportation, water conservancy, chemical industry, light industyry, printing package, pharmacy, food, textile, building, building material, matter flowing, environmental protection. 1. High modularization design: May equip with various motor or other power input conveniently. Same machine type may equip with various power motor. It is easy to realize the combination and junction between every machine type. 2. Transmission ratio: Fine division, wide scope. The combined machine type may form very large transmission ratio, i. E. Output very low rotary speed. 3. Form of installation: The position to be installed is not limited. 4. High strength, compact: The box body is made of high strength cast iron. Gear and gear shaft adapts the gas carbonization, quenching and fine grinding process, therefore the bearing capacity of unit volume is high. 5. Long life: Under the condition of correct type chosen (including choosing suitable operation parameters) normal operation and maintenance, the life of main parts of speed reducer (except wearing parts) should not be less than 20000 hours. The wearing parts include lubricating oil, oil seal and bearing. 6. Low noise: Because main parts of speed reducer are processed, assembled and tested critically, therefore the noise of speed reducer is low; 7. Parallel axis -bevel wheel speed-down motor Equipment method: 1. Foot installment, flange installment 2. Various of motors or double shafts can be equipped Technique parameter: 1. Power: 0.12 KW~160 KW 2. Torque: 85 N. M~18000 N. M 3. Ratio: 1. 4~28000 More Product Features HS Code: 84834090 Trademark: Starred-River Model NO.: SR82 Standard: IEC standard Productivity: 3000 PCS/Month Origin: China Packing: Wooden Box
